Update WhatsApp Flow
Update WhatsApp Flow

PUT https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/flows/:flowId

This endpoint is used to update an existing WhatsApp Flow. The flow must be in draft state.

WhatsApp Flows are interactive experiences that businesses can use to collect information from customers through WhatsApp conversations. This endpoint allows you to update flow properties including name, categories, flow JSON definition, endpoint URI, and application ID.

At least one property must be present in the request body.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

flowId stringrequired
Flow identifier

Body

Request body for updating a WhatsApp Flow. At least one property must be present.

namestring
Flow name

Example: Example Flow - Updated

categoriesstring[]
Flow categories

Possible values: [SIGN_UP, SIGN_IN, APPOINTMENT_BOOKING, LEAD_GENERATION, CONTACT_US, CUSTOMER_SUPPORT, SURVEY, OTHER]

Example: ["OTHER"]

publishboolean
Whether to publish the flow immediately

Default value: false

Example: false

flowJsonstring
Flow JSON definition as a string

Example: {"version":"5.0","screens":[{"id":"WELCOME_SCREEN","layout":{"type":"SingleColumnLayout","children":[{"type":"TextHeading","text":"Hello World!"},{"type":"Footer","label":"Complete","on-click-action":{"name":"complete","payload":{}}}]},"title":"Welcome","terminal":true,"success":true,"data":{}}]}

cloneFlowIdstring
Optional flow ID to clone from. If provided, the flow will be updated with content from the specified flow.

Example: 1145805540595505

endPointUristring<uri>
Optional endpoint URI for the flow. This is the URL that will receive flow completion data.

Example: https://example.com/webhook/flow-completion

applicationIdstring
Application ID associated with the flow

Example: 123456789

Flow updated successfully

Schema

idstring
Created flow ID

Example: 866937862658913

successboolean
Indicates if the operation was successful

Example: true

validationErrors object[]

List of validation errors (only present if there are errors in the flow JSON)

Array [

errorstring
Error code

Example: INVALID_PROPERTY_VALUE

errorTypestring
Type of error

Example: FLOW_JSON_ERROR

messagestring
Error message

Example: Invalid value found for property 'type'.

lineStartinteger
Starting line number of the error

Example: 1

lineEndinteger
Ending line number of the error

Example: 1

columnStartinteger
Starting column number of the error

Example: 84

columnEndinteger
Ending column number of the error

Example: 92

pointers object[]

Array of error pointers

Array [

lineStartinteger
Example: 1

lineEndinteger
Example: 1

columnStartinteger
Example: 84

columnEndinteger
Example: 92

pathstring
Path to the property with the error

Example: screens[0].layout.children[0].children[0].type

]

]

{ "id":"866937862658913", "success":true, "validationErrors":[ { "error":"INVALID_PROPERTY_VALUE", "errorType":"FLOW_JSON_ERROR", "message":"Invalid value found for property 'type'.", "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "pointers":[ { "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "path":"screens[0].layout.children[0].children[0].type" } ] } ] }

Flow updated with validation errors

{ "id":"866937862658913", "success":true, "validationErrors":[ { "error":"INVALID_PROPERTY_VALUE", "errorType":"FLOW_JSON_ERROR", "message":"Invalid value found for property 'type'.", "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "pointers":[ { "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "path":"screens[0].layout.children[0].children[0].type" } ] } ] }

Flow updated successfully without errors

{ "id":"866937862658913", "success":true }

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/update-whatsapp-flow · 8x8 CPaaS Developer Docs. Synced for support deflection.
Submit WhatsApp Direct Send Sample
Submit WhatsApp Direct Send Sample

POST https://chatapps.8x8.com/api/v1/whatsapp/subaccounts/:subAccountId/channels/:channelId/directSend/sample

This endpoint is used to submit a sample of a WhatsApp Direct Send message to Meta for review and classification.

Direct Send auto-creates WhatsApp templates on the fly and matches incoming messages against them. Submitting sample messages will ensure that the messages you send through Direct Send are accurately classified and transformed into templates that are useful for your use cases.

The response indicates whether the sample was processed successfully and the category Meta assigned to it. Possible categories are UTILITY, MARKETING, and AUTHENTICATION.

Samples can be of two types:

text — a plain text body.

interactive — an interactive message with a call-to-action URL (cta_url) or reply buttons (button).

Request

Path Parameters

subAccountId stringrequired
Sub-account identifier

channelId stringrequired
Channel identifier

Bodyrequired

Sample message to submit to Meta for review.

typestringrequired
Sample type. Must be either text or interactive.

Possible values: [text, interactive]

Example: interactive

text object

Required when type is text.

bodystringrequired
The text body of the sample message. Must not be empty.

Example: Hello! This is a sample message.

interactive object

Required when type is interactive.

typestringrequired
Interactive type. Must be either cta_url (call-to-action URL) or button (reply buttons).

Possible values: [cta_url, button]

Example: cta_url

header object

Optional header for the interactive message.

typestringrequired
Header type. Only text is supported.

Possible values: [text]

Example: text

textstringrequired
Header text. Must not exceed 60 characters.

Possible values: <= 60 characters

Example: Welcome

body objectrequired

Body of the interactive message.

textstringrequired
Body text. Must not be empty and must not exceed 1024 characters.

Possible values: <= 1024 characters

Example: Tap the button below to visit our store.

footer object

Optional footer for the interactive message.

textstringrequired
Footer text. Must not exceed 60 characters.

Possible values: <= 60 characters

Example: Powered by 8x8

action objectrequired

Action object. The required fields depend on the interactive.type:

For cta_url, name must be cta_url and parameters is required.

For button, buttons is required.

namestring
Required when interactive.type is cta_url. Must be cta_url.

Possible values: [cta_url]

Example: cta_url

parameters object

Required when interactive.type is cta_url.

display_textstringrequired
Text displayed on the call-to-action button. Must not be empty.

Example: Visit store

urlstring<uri>required
Destination URL for the call-to-action. Must be a valid http or https URL.

Example: https://example.com/store

buttons object[]

Required when interactive.type is button. Must contain at most 10 reply buttons.

Possible values: <= 10

Array [

typestringrequired
Button type. Only reply is supported.

Possible values: [reply]

Example: reply

reply objectrequired

idstringrequired
Unique identifier for the button. Must not be empty.

Example: btn-yes

titlestringrequired
Button label. Must not be empty and must not exceed 20 characters.

Possible values: <= 20 characters

Example: Yes

]

Sample submitted successfully

Schema

successboolean
Indicates whether the sample was accepted by Meta.

Example: true

categorystring
Category assigned by Meta to the submitted sample.

Possible values: [UTILITY, MARKETING, AUTHENTICATION]

Example: UTILITY

{ "success":true, "category":"UTILITY" }

Sample accepted and categorized

{ "success":true, "category":"UTILITY" }

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/submit-whatsapp-direct-send-sample · 8x8 CPaaS Developer Docs. Synced for support deflection.
Remove WhatsApp template
Remove WhatsApp template

DELETE https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/templates/:templateName

This endpoint is used to remove an existing WhatsApp message template.

WhatsApp Message Templates are message formats for common reusable messages a business may want to send. Businesses must use Message Templates for sending notifications to customers. Any message sent outside the 24h customer service window, needs to be a template message, to be delivered. Advertising, marketing, or promotional messages are not permitted.

Request

Path Parameters

accountId stringrequired

channelId stringrequired

templateName stringrequired

Schema

object

{}

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/remove-wa-template · 8x8 CPaaS Developer Docs. Synced for support deflection.
Publish WhatsApp Flow
Publish WhatsApp Flow

POST https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/flows/:flowId/publish

This endpoint is used to publish a WhatsApp Flow.

Publishing a flow makes it available for use in WhatsApp conversations. Once published, the flow can be sent to customers through WhatsApp messages(Template message and Interactive messages). A flow must be in DRAFT status and pass all validations before it can be published.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

flowId stringrequired
Flow identifier

Flow published successfully. No response body is returned.

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/publish-whatsapp-flow · 8x8 CPaaS Developer Docs. Synced for support deflection.
Preview WhatsApp Flow
Preview WhatsApp Flow

GET https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/flows/:flowId/preview

This endpoint is used to generate a preview URL for a WhatsApp Flow.

The preview allows you to visualize and interact with your flow before publishing it. You can force regeneration of the preview by setting the refresh query parameter to true.

For interactive previews with custom parameters, you can add query parameters to the generated preview URL. For a list of supported query parameters, refer to the 'Visualizing and interacting with your Flow using the Web Preview' section of the WhatsApp Flows API documentation.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

flowId stringrequired
Flow identifier

Query Parameters

refresh boolean
Set to true to force Meta to regenerate the preview. Defaults to false.

Default value: false

Preview URL generated successfully

Schema

idstring
Flow ID

Example: 833178916081311

preview_urlstring<uri>
URL to access the flow preview. You can add query parameters to this URL for interactive previews.

Example: https://business.facebook.com/wa/manage/flows/833178916081311/preview/?token=0836260f-9b1e-4a78-b02b-aaad5c173278

expires_atstring<date-time>
Expiration timestamp of the preview URL in ISO 8601 format

Example: 2025-12-13T05:49:59+0000

{ "id":"833178916081311", "preview_url":"https://business.facebook.com/wa/manage/flows/833178916081311/preview/?token=0836260f-9b1e-4a78-b02b-aaad5c173278", "expires_at":"2025-12-13T05:49:59+0000" }

Preview URL generated

{ "id":"833178916081311", "preview_url":"https://business.facebook.com/wa/manage/flows/833178916081311/preview/?token=0836260f-9b1e-4a78-b02b-aaad5c173278", "expires_at":"2025-12-13T05:49:59+0000" }

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/preview-whatsapp-flow · 8x8 CPaaS Developer Docs. Synced for support deflection.
Get WhatsApp templates
Get WhatsApp templates

GET https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/templates

This endpoint is used to get your registered WhatsApp message template and their approval status.

WhatsApp Message Templates are message formats for common reusable messages a business may want to send. Businesses must use Message Templates for sending notifications to customers. Any message sent outside the 24h customer service window, needs to be a template message, to be delivered. Advertising, marketing, or promotional messages are not permitted.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

Schema

templates object[]

Array [

channelIdstring<uuid>
Channel ID

Example: ec36a867-3dd4-e911-814a-02d85f55fce8

channelNamestring
Channel User-friendly name

Possible values: <= 36 characters

Example: My WhatsApp Instance

templateNamestring
Template name

Possible values: <= 200 characters

Example: test1

languagestring
Template languate code

Possible values: <= 5 characters

Example: en_US

languageNamestring
User-friendly language name

Example: English (US)

components object[]

Template components

Array [

typestringrequired
Component type

Possible values: [HEADER, BODY, FOOTER, BUTTONS]

Default value: BODY

formatstring
Component type. Required for HEADER component type.

Possible values: [Text, Image, Video, Document, Location]

Example: Image

textstring
Component text. Required for BODY and FOOTER types

Example: You can pickup your delivery at {{1}}

buttons object[]

Array [

typestringrequired
Button type

Possible values: [PHONE_NUMBER, URL, QUICK_REPLY, OTP, COPY_CODE, FLOW, VOICE_CALL]

textstringrequired
The text to be displayed on the button (except VOICE_CALL, where it is optional).

Possible values: non-empty and <= 20 characters

phoneNumberstring
Required for type "PHONE_NUMBER".

The phone number that will be called on clicking the button.

countrystring
Optional country code of phone number (ISO 3166-1 alpha-2). Required if the phone number in the national format.

Possible values: >= 2 characters and <= 2 characters

Example: US

urlstring<uri>
Required for type "URL".

The URL that will be visited on clicking the button Variables can be used to create dynamic links.

Example: https://website.com/{{1}}

examplestring[]
To help WhatsApp moderators during the review and approval process, you can include example data. This can help WhatsApp understand what kind of message you plan to send and showcase the customer experience.

For example, you could include an image that could represent a customer's profile picture to personalize the experience.

Make sure these are examples and do not include any confidential or personal information.

flowIdstring
Required for type "FLOW".

The ID of the WhatsApp Flow to launch when the button is clicked.

Example: 859504979861628

flowActionstring
Optional for type "FLOW".

The action to perform when launching the flow. Defaults to "navigate" if not provided.

Possible values: [navigate, data_exchange]

Default value: navigate

Example: navigate

navigateScreenstring
Optional for type "FLOW".

The screen ID to navigate to when launching the flow. Used when flowAction is "navigate". Defaults to "FIRST_ENTRY_SCREEN" if not provided.

Default value: FIRST_ENTRY_SCREEN

Example: RECOMMEND

ttlMinutesinteger
Optional property for type "VOICE_CALL" only.

The time-to-live in minutes for the voice call button. If provided, must be between 1440 mins (1 day) and 43200 mins (30 days), inclusive.

Possible values: >= 1440 and <= 43200

Example: 1440

]

example object

Example data provided for the template

headerTextstring[]
Header text examples

bodyTextstring[]
Body text examples

headerHandlestring[]
Header images, docs or videos examples

]

categorystring
template category enumeration

Example: UTILITY

categoryNamestring
User-friendly category name

Example: Utility

statusstring
Template status enumeration

Example: APPROVED

statusNamestring
User-friendly status name

Example: Approved

createdAtstring<date-time>
Template creation timestamp

Example: 2019-08-26T04:50:47.38Z

updatedAtstring<date-time>
Template last update timestamp

Example: 2019-09-26T04:50:47.38Z

]

{ "templates":[ { "channelId":"ec36a867-3dd4-e911-814a-02d85f55fce8", "channelName":"My WhatsApp Instance", "templateName":"test1", "language":"en_US", "languageName":"English (US)", "components":[ { "type":"BODY", "format":"Image", "text":"You can pickup your delivery at {{1}}", "buttons":[ { "type":"PHONE_NUMBER", "text":"string", "phoneNumber":"string", "country":"US", "url":"https://website.com/{{1}}", "example":[ "string" ], "flowId":"859504979861628", "flowAction":"navigate", "navigateScreen":"RECOMMEND", "ttlMinutes":1440 } ], "example":{ "headerText":[ "string" ], "bodyText":[ "string" ], "headerHandle":[ "string" ] } } ], "category":"UTILITY", "categoryName":"Utility", "status":"APPROVED", "statusName":"Approved", "createdAt":"2019-08-26T04:50:47.38Z", "updatedAt":"2019-09-26T04:50:47.38Z" } ] }

{ "templates":[ { "channelId":"ec36a867-3dd4-e911-814a-02d85f55fce8", "channelName":"My WhatsApp instance", "templateName":"ticket_created", "language":"en", "languageName":"English", "components":[ { "type":"BODY", "text":"Hi, your booking have been confirmed. Here is your new booking information {{1}}" } ], "category":"UTILITY", "categoryName":"Utility", "status":"APPROVED", "statusName":"Approved", "createdAt":"2019-11-19T07:51:38.09Z", "updatedAt":"2019-11-28T02:16:42.82Z" }, { "channelId":"ec36a867-3dd4-e911-814a-02d85f55fce8", "channelName":"My WhatsApp instance", "templateName":"ticket_closed", "language":"en", "languageName":"English", "components":[ { "type":"HEADER", "format":"Image" }, { "type":"BODY", "text":"Your ticket {{1}} was closed." }, { "type":"FOOTER", "text":"Support Team" } ], "category":"UTILITY", "categoryName":"Utility", "status":"APPROVED", "statusName":"Approved", "createdAt":"2019-11-14T07:17:57.16Z", "updatedAt":"2019-11-28T02:16:42.82Z" } ] }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/get-whatsapp-templates · 8x8 CPaaS Developer Docs. Synced for support deflection.
Get WhatsApp Flows
Get WhatsApp Flows

GET https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/flows

This endpoint is used to retrieve the list of WhatsApp Flows and their status for the channel.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

Query Parameters

limit integer
Possible values: >= 1 and <= 1000

Maximum number of flows to return

Default value: 100

Successful response

Schema

flows object[]

Array [

idstring
Flow ID

Example: 1145805540595505

namestring
Flow name

Example: Loan Collection

statusstring
Flow status

Possible values: [DRAFT, PUBLISHED, DEPRECATED]

Example: DRAFT

]

{ "flows":[ { "id":"1145805540595505", "name":"Loan Collection", "status":"DRAFT" } ] }

{ "flows":[ { "id":"1145805540595505", "name":"Loan Collection", "status":"DRAFT" }, { "id":"802610292468882", "name":"2025-10-08T15:17:51.241+08:00", "status":"PUBLISHED" } ] }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/get-whatsapp-flows · 8x8 CPaaS Developer Docs. Synced for support deflection.
Get WhatsApp Flow details
Get WhatsApp Flow details

GET https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/flows/:flowId

This endpoint is used to retrieve details of a specific WhatsApp Flow.

WhatsApp Flows are interactive experiences that businesses can use to collect information from customers through WhatsApp conversations. This endpoint returns comprehensive information about a flow including its current status, validation errors, and flow JSON URL.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

flowId stringrequired
Flow identifier

Flow details retrieved successfully

Schema

flowIdstring
Flow ID

Example: 822625023859371

flowJsonUrlstring<uri>
URL to download the flow JSON definition

Example: https://mmg.whatsapp.net/m1/v/t24/An-a1LjKk34-zpvJMd&_nc_sid=471

namestring
Flow name

Example: Example flow

statusstring
Flow status

Possible values: [DRAFT, PUBLISHED, DEPRECATED]

Example: DRAFT

categoriesstring[]
Flow categories

Possible values: [SIGN_UP, SIGN_IN, APPOINTMENT_BOOKING, LEAD_GENERATION, CONTACT_US, CUSTOMER_SUPPORT, SURVEY, OTHER]

Example: ["OTHER"]

validationErrors object[]

List of validation errors (only present if there are errors in the flow JSON)

Array [

errorstring
Error code

Example: INVALID_PROPERTY_VALUE

errorTypestring
Type of error

Example: FLOW_JSON_ERROR

messagestring
Error message

Example: Invalid value found for property 'type'.

lineStartinteger
Starting line number of the error

Example: 1

lineEndinteger
Ending line number of the error

Example: 1

columnStartinteger
Starting column number of the error

Example: 84

columnEndinteger
Ending column number of the error

Example: 92

pointers object[]

Array of error pointers

Array [

lineStartinteger
Example: 1

lineEndinteger
Example: 1

columnStartinteger
Example: 84

columnEndinteger
Example: 92

pathstring
Path to the property with the error

Example: screens[0].layout.children[0].children[0].type

]

]

{ "flowId":"822625023859371", "flowJsonUrl":"https://mmg.whatsapp.net/m1/v/t24/An-a1LjKk34-zpvJMd&_nc_sid=471", "name":"Example flow", "status":"DRAFT", "categories":[ "OTHER" ], "validationErrors":[ { "error":"INVALID_PROPERTY_VALUE", "errorType":"FLOW_JSON_ERROR", "message":"Invalid value found for property 'type'.", "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "pointers":[ { "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "path":"screens[0].layout.children[0].children[0].type" } ] } ] }

Flow with validation errors

{ "flowId":"822625023859371", "flowJsonUrl":"https://mmg.whatsapp.net/m1/v/t24/An-a1LjKk34-zpvJMd&_nc_sid=471", "name":"Example flow", "status":"DRAFT", "categories":[ "OTHER" ], "validationErrors":[ { "error":"INVALID_PROPERTY_VALUE", "errorType":"FLOW_JSON_ERROR", "message":"Invalid value found for property 'type'.", "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "pointers":[ { "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "path":"screens[0].layout.children[0].children[0].type" } ] } ] }

Flow without errors

{ "flowId":"822625023859371", "flowJsonUrl":"https://mmg.whatsapp.net/m1/v/t24/An-a1LjKk34-zpvJMd&_nc_sid=471", "name":"Example flow", "status":"PUBLISHED", "categories":[ "OTHER" ] }

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/get-whatsapp-flow-details · 8x8 CPaaS Developer Docs. Synced for support deflection.
Retrieve message details
Retrieve message details

GET https://chatapps.8x8.com/api/v1/subaccounts/:subAccountId/messages/:umid

This resource can be used to query message details like delivery status using the UMID of the message. You need to specify the sub account id and the umid of the message in place of {subAccountId} and {umid} respectively. umid is the unique identifier (in the form of a uuid) you received when you submitted the message to the api.

API Rate Limiting

To protect the platform from being overloaded and maintain a high quality of service to all customers, we enforce API rate limits for this API endpoint.

The limit is set to 1 request/second per subaccount.

To safeguard your privacy, sensitive data such as message content and phone numbers are masked by default. Access to this information can be requested by contacting our support team.

Request

Path Parameters

subAccountId stringrequired
Possible values: >= 3 characters and <= 50 characters, Value must match regular expression ^[A-Za-z0-9\-._&]{3,50}$

You must replace {subAccountId} with the subaccountid that you want to use. By default this is generated once you signed up with a new account at https://connect.8x8.com.

umid stringrequired
Unique message Id, generated by 8x8 API.

The success response returned with the message details of the message specified by the umid. Since channel fallback is supported, a single message umid may have multiple message details records depending on the number of channels attempted.

Schema

data object[]required

Array [

umidstringrequired
Unique message ID automatically generated by 8x8.

Example: dec02e44-c76f-4a0a-b69f-6ac2a4386eb9

subAccountIdstringrequired
Sub account id with which the message is associated with.

channelstringrequired
Name of the channel used to send the message. Possible values are SMS, WhatsApp, RCS, Viber, Line, Facebook, WeChat, Zalo or Kakao.

Example: WhatsApp

channelIdstringrequired
Unique channel identifier. This property uniquely identifies the channel used to send the message when multiple channels of the same type are associated with one sub account.

Example: 8e4d1303-5754-e911-8154-020897df5459

directionstringrequired
Direction of the message. Possible values are

outbound: Mobile terminated.

inbound: Mobile originated.

Example: outbound

countrystring
Two-letter ISO 3166 country code associated with the message.

Example: SG

status objectrequired

Delivery status of the message. Status contains the following information.

statestring
General status of the message. Possible values are

unknown: Status is not known. This is an exceptional/intermediate status.

queued: The request is accepted and queued for processing

failed: The request has been rejected by the api and will not be processed.

sent: The message has been sent to the operator and we have not received an acknowledgment yet.

delivered: Message has been delivered to destination and we have received confirmation from the operator.

undelivered: We have received a delivery receipt from the operator that the message was not delivered.

read: Message was delivered and read.

ok: Operation was successful

error: An error occurred during operation

Example: delivered

detailstring

delivered_to_operator: The message has been delivered to the operator. Associated with delivered state

delivered_to_recipient: The message has been delivered to the recipient. Associated with delivered state.

rejected_by_operator: The message has been rejected by the operator. Associated with undelivered status.

undelivered_to_recipient: The message has been delivered but rejected by the target device. Associated with undelivered state.

Example: delivered_to_carrier

errorCodeinteger
Error code for the operation

errorMessagestring
Description of the error.

Example: Invalid message length

timestampstring<date-time>
Date and time when the status was observed expressed in ISO 8601 format.

Example: 2020-06-17T04:17:21.06Z

user object

Information about the user the message is associated with.

msisdnstring
Phone number (obfuscated to protect sensitive information) expressed in E.164 international format.

Example: +63922110xxxx

channelUserIdstring
Channel user identifier (obfuscated to protect sensitive data).

contentTypestringrequired
Content type of the message. Possible values are Text, Audio, Video, Image, Location, File, Carousel, List, Buttons or Template.

Example: Text

contentstring
Message content (obfuscated to protect sensitive information).

Example: **MASKED**

createdAtstringrequired
Date and time the message was submitted to the api expressed in ISO 8601 format.

Example: 2020-06-17T04:17:21.06Z

clientMessageIdstring
Client message identifier.

clientBatchIdstring
Client batch identifier.

batchIdstring
Universaly unique batch identifier (UUID).

Example: c9c01382-38bf-4e27-8962-ae0684ab56c3

stepintegerrequired
Indicates the attempt on which the channel was used. For instance, a message delivery may be failed via Viber and a fallback channel like WhatsApp may be attempted next. In this case, step 1 will contain message details for Viber and step 2 will contain the message details for WhatsApp.

Example: 1

]

{ "data":[ { "umid":"dec02e44-c76f-4a0a-b69f-6ac2a4386eb9", "subAccountId":"string", "channel":"WhatsApp", "channelId":"8e4d1303-5754-e911-8154-020897df5459", "direction":"outbound", "country":"SG", "status":{ "state":"delivered", "detail":"delivered_to_carrier", "errorCode":0, "errorMessage":"Invalid message length", "timestamp":"2020-06-17T04:17:21.06Z" }, "user":{ "msisdn":"+63922110xxxx", "channelUserId":"string" }, "contentType":"Text", "content":"**MASKED**", "createdAt":"2020-06-17T04:17:21.06Z", "clientMessageId":"string", "clientBatchId":"string", "batchId":"c9c01382-38bf-4e27-8962-ae0684ab56c3", "step":1 } ] }

{ "data":[ { "umid":"dec02e44-c76f-4a0a-b69f-6ac2a4386eb9", "subAccountId":"sub_account_id", "channel":"WhatsApp", "channelId":"904d1303-5754-e911-8154-020897df5459", "direction":"Outbound", "status":{ "state":"read", "timestamp":"2020-06-17T04:25:21.06Z" }, "contentType":"Text", "createdAt":"2020-06-17T04:15:21.06Z", "step":2, "country":"SG", "user":{ "msisdn":"+63922110xxxx" }, "content":"**MASKED**", "clientMessageId":"client message id", "clientBatchId":"client batch id", "batchId":"c9c01382-38bf-4e27-8962-ae0684ab56c3" } ] }

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

The entity doesn't exist

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":4018, "message":"Invalid jobId", "errorId":"aa400d4b-fffe-ea11-8277-00155d4ff7ed", "timestamp":"2020-09-25T07:18:22.78Z" }

Rate limiting quota exceeded error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":429, "message":"Quota exceeded. Please try again in 1 second(s).", "errorId":"c8a41b47-57bf-ea11-8273-00155d466a31", "timestamp":"2020-07-06T07:07:00.30Z" }
Source: https://developer.8x8.com/connect/reference/get-chatapps-message-details · 8x8 CPaaS Developer Docs. Synced for support deflection.
Delete WhatsApp Flow
Delete WhatsApp Flow

DELETE https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/flows/:flowId

This endpoint is used to delete a WhatsApp Flow.

Only flows that are not published can be deleted. If a flow has been published, it cannot be deleted and the API will return an error. This operation is permanent and cannot be undone.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

flowId stringrequired
Flow identifier

Flow deleted successfully. No response body is returned.

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/delete-whatsapp-flow · 8x8 CPaaS Developer Docs. Synced for support deflection.
Deprecate WhatsApp Flow
Deprecate WhatsApp Flow

POST https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/flows/:flowId/deprecate

This endpoint is used to deprecate a WhatsApp Flow.

Deprecating a flow marks it as no longer recommended for use, but keeps it accessible for existing integrations. This allows you to phase out a flow gracefully without breaking active implementations. Once deprecated, the flow status will be updated to reflect its deprecated state.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

flowId stringrequired
Flow identifier

Flow deprecated successfully. No response body is returned.

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/deprecate-whatsapp-flow · 8x8 CPaaS Developer Docs. Synced for support deflection.
Create WhatsApp Flow
Create WhatsApp Flow

POST https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/flows

This endpoint is used to create a new WhatsApp Flow.

WhatsApp Flows are interactive experiences that businesses can use to collect information from customers through WhatsApp conversations. Flows provide a structured way to guide users through multi-step processes like booking appointments, collecting feedback, or processing orders.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

Body

Request body for creating a WhatsApp Flow

namestringrequired
Flow name

Example: Example Flow

categoriesstring[]required
Flow categories

Possible values: [SIGN_UP, SIGN_IN, APPOINTMENT_BOOKING, LEAD_GENERATION, CONTACT_US, CUSTOMER_SUPPORT, SURVEY, OTHER]

Example: ["OTHER"]

publishboolean
Whether to publish the flow immediately

Default value: false

Example: false

flowJsonstring
Flow JSON definition as a string

Example: {"version":"5.0","screens":[{"id":"WELCOME_SCREEN","layout":{"type":"SingleColumnLayout","children":[{"type":"TextHeading","text":"Hello World"},{"type":"Footer","label":"Complete","on-click-action":{"name":"complete","payload":{}}}]},"title":"Welcome","terminal":true,"success":true,"data":{}}]}

cloneFlowIdstring
Optional flow ID to clone from. If provided, the new flow will be created as a copy of the specified flow.

Example: 1145805540595505

endPointUristring<uri>
Optional endpoint URI for the flow. This is the URL that will receive flow completion data.

Example: https://example.com/webhook/flow-completion

Flow created successfully

Schema

idstring
Created flow ID

Example: 866937862658913

successboolean
Indicates if the operation was successful

Example: true

validationErrors object[]

List of validation errors (only present if there are errors in the flow JSON)

Array [

errorstring
Error code

Example: INVALID_PROPERTY_VALUE

errorTypestring
Type of error

Example: FLOW_JSON_ERROR

messagestring
Error message

Example: Invalid value found for property 'type'.

lineStartinteger
Starting line number of the error

Example: 1

lineEndinteger
Ending line number of the error

Example: 1

columnStartinteger
Starting column number of the error

Example: 84

columnEndinteger
Ending column number of the error

Example: 92

pointers object[]

Array of error pointers

Array [

lineStartinteger
Example: 1

lineEndinteger
Example: 1

columnStartinteger
Example: 84

columnEndinteger
Example: 92

pathstring
Path to the property with the error

Example: screens[0].layout.children[0].children[0].type

]

]

{ "id":"866937862658913", "success":true, "validationErrors":[ { "error":"INVALID_PROPERTY_VALUE", "errorType":"FLOW_JSON_ERROR", "message":"Invalid value found for property 'type'.", "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "pointers":[ { "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "path":"screens[0].layout.children[0].children[0].type" } ] } ] }

Flow created with validation errors

{ "id":"866937862658913", "success":true, "validationErrors":[ { "error":"INVALID_PROPERTY_VALUE", "errorType":"FLOW_JSON_ERROR", "message":"Invalid value found for property 'type'.", "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "pointers":[ { "lineStart":1, "lineEnd":1, "columnStart":84, "columnEnd":92, "path":"screens[0].layout.children[0].children[0].type" } ] } ] }

Flow created successfully without errors

{ "id":"866937862658913", "success":true }

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/create-whatsapp-flow · 8x8 CPaaS Developer Docs. Synced for support deflection.
Cancel batch of scheduled message
Cancel batch of scheduled message

DELETE https://chatapps.8x8.com/api/v1/subaccounts/:subAccountId/messages/batch/:batchId

Sending a DELETE request on this this endpoint allows to cancel a batch of scheduled messages that has not been sent yet.

This method should be used to cancel a batch of scheduled messages sent by previously submitting a POST request to either the "many" or "many compact" endpoint.

To cancel a batch of scheduled messages, use its batchId to target it.

URL

In the original POST request used to schedule the batch of messages, you used a specific subaccountid and the API responded with a batchID.

You need to use both as path parameters in order to send your DELETE request successfully as shown below: https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages/batch/{batchId}

You must replace {subAccountId} and {batchId} in the URL above with the subaccountid you used to schedule the messages in the first place and the batchId you got in response.

Request

Path Parameters

subAccountId stringrequired
Possible values: >= 3 characters and <= 50 characters, Value must match regular expression ^[A-Za-z0-9\-._&]{3,50}$

You must replace {subAccountId} with the subaccountid that you want to use. By default this is generated once you signed up with a new account at https://connect.8x8.com.

batchId stringrequired

Schema

cancelledCountinteger
Number of cancelled messages

{ "cancelledCount":0 }

{ "cancelledCount":10 }

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/cancel-many-chat-apps-messages · 8x8 CPaaS Developer Docs. Synced for support deflection.
Add WhatsApp template
Add WhatsApp template

POST https://chatapps.8x8.com/api/v1/accounts/:accountId/channels/:channelId/templates

This endpoint is used to register new WhatsApp message template.

Please note that special html entities should be unescaped.

WhatsApp Message Templates are message formats for common reusable messages a business may want to send. Businesses must use Message Templates for sending notifications to customers. Any message sent outside the 24h customer service window, needs to be a template message, to be delivered. Advertising, marketing, or promotional messages are not permitted.

Request

Path Parameters

accountId stringrequired
Possible values: >= 32 characters and <= 36 characters, Value must match regular expression ^[0-9A-Fa-f]{8}[-]?(?:[0-9A-Fa-f]{4}[-]?){3}[0-9A-Fa-f]{12}$

You must replace {accountId} with the accountid that you want to use.

channelId stringrequired
Channel identifier

Body

languagestringrequired
Template language code

Example: en_US

namestringrequired
Template name

Example: ticket_update_en_US

categorystringrequired
Template category.

Templates containing a VOICE_CALL button are only allowed in MARKETING or UTILITY categories.

Example: UTILITY

components object[]required

Registered template components

Array [

typestringrequired
Component type

Possible values: [HEADER, BODY, FOOTER, BUTTONS, CAROUSEL, CALL_PERMISSION_REQUEST]

Default value: BODY

formatstring
Component type. Required for HEADER component type.
Note: Gifs are currently only available for Marketing Messages API for WhatsApp.

Possible values: [Text, Image, Gif, Video, Document, Location]

Example: Image

textstring
Component text. Required for BODY and FOOTER types

Example: You can pickup your delivery at {{1}}

buttons object[]

Array [

typestringrequired
Button type

Possible values: [PHONE_NUMBER, URL, QUICK_REPLY, OTP, COPY_CODE, FLOW, VOICE_CALL]

textstringrequired
The text to be displayed on the button (except VOICE_CALL, where it is optional).

Possible values: non-empty and <= 20 characters

phoneNumberstring
Required for type "PHONE_NUMBER".

The phone number that will be called on clicking the button.

countrystring
Optional country code of phone number (ISO 3166-1 alpha-2). Required if the phone number in the national format.

Possible values: >= 2 characters and <= 2 characters

Example: US

urlstring<uri>
Required for type "URL".

The URL that will be visited on clicking the button Variables can be used to create dynamic links.

Example: https://website.com/{{1}}

examplestring[]
To help WhatsApp moderators during the review and approval process, you can include example data. This can help WhatsApp understand what kind of message you plan to send and showcase the customer experience.

For example, you could include an image that could represent a customer's profile picture to personalize the experience.

Make sure these are examples and do not include any confidential or personal information.

flowIdstring
Required for type "FLOW".

The ID of the WhatsApp Flow to launch when the button is clicked.

Example: 859504979861628

flowActionstring
Optional for type "FLOW".

The action to perform when launching the flow. Defaults to "navigate" if not provided.

Possible values: [navigate, data_exchange]

Default value: navigate

Example: navigate

navigateScreenstring
Optional for type "FLOW".

The screen ID to navigate to when launching the flow. Used when flowAction is "navigate". Defaults to "FIRST_ENTRY_SCREEN" if not provided.

Default value: FIRST_ENTRY_SCREEN

Example: RECOMMEND

ttlMinutesinteger
Optional property for type "VOICE_CALL" only.

The time-to-live in minutes for the voice call button. If provided, must be between 1440 mins (1 day) and 43200 mins (30 days), inclusive.

Possible values: >= 1440 and <= 43200

Example: 1440

]

examplesstring[]
To help WhatsApp moderators during the review and approval process, you can include example data. This can help WhatsApp understand what kind of message you plan to send and showcase the customer experience.

For example, you could include an image that could represent a customer's profile picture to personalize the experience.

Make sure these are examples and do not include any confidential or personal information.

add_security_recommendationboolean
Only for BODY component with AUTHENTICATION template category

code_expiration_minutesinteger
Only for FOOTER component with AUTHENTICATION template category

Default value: 5

cards object[]

Required only for CAROUSEL type. You can create up to 10 cards.

Array [

typestringrequired
Component type

Possible values: [HEADER, BODY, BUTTONS]

Default value: BODY

formatstring
Component type. Required for HEADER component type.

Possible values: [Image, Video]

Example: Image

textstring
Component text. Required for BODY and FOOTER types

Example: You can pickup your delivery at {{1}}

buttons object[]

Array [

typestringrequired
Button type

Possible values: [PHONE_NUMBER, URL, QUICK_REPLY, OTP, COPY_CODE]

textstringrequired
The text to be displayed on the button.

Possible values: non-empty and <= 20 characters

phoneNumberstring
Required for type "PHONE_NUMBER".

The phone number that will be called on clicking the button.

countrystring
Optional country code of phone number (ISO 3166-1 alpha-2). Required if the phone number in the national format.

Possible values: >= 2 characters and <= 2 characters

Example: US

urlstring<uri>
Required for type "URL".

The URL that will be visited on clicking the button Variables can be used to create dynamic links.

Example: https://website.com/{{1}}

examplestring[]
To help WhatsApp moderators during the review and approval process, you can include example data. This can help WhatsApp understand what kind of message you plan to send and showcase the customer experience.

For example, you could include an image that could represent a customer's profile picture to personalize the experience.

Make sure these are examples and do not include any confidential or personal information.

]

examplesstring[]
To help WhatsApp moderators during the review and approval process, you can include example data. This can help WhatsApp understand what kind of message you plan to send and showcase the customer experience.

For example, you could include an image that could represent a customer's profile picture to personalize the experience.

Make sure these are examples and do not include any confidential or personal information.

]

]

allow_category_changeboolean
set to true to allow whatsapp to automatically assign a category. If omitted, the template may be rejected due to mis-categorization.

Default value: true

Example: false

message_send_ttl_secondsinteger
Custom time-to-live (TTL) for message delivery in seconds. If a message cannot be delivered within this time, it will be dropped.
Valid ranges: Authentication templates (30-900 seconds or -1 for 30 days), Utility templates (30-43200 seconds or -1 for 30 days), Marketing templates (43200-2592000 seconds).
Default TTL: Authentication=10 minutes (600 seconds), Utility/Marketing=30 days.

Example: 300

Schema

object

{}

Bad request error response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1002, "message":"Invalid MSISDN format (not E.164 international number)", "errorId":"b4478860-b76c-e811-814e-022a35cc1c71", "timestamp":"2018-08-04T09:25:40.9235752+00:00" }

Request was not authenticated response

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":1200, "message":"Request was not authenticated properly", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-08-02T09:42:38.8988997+00:00" }

Template name cannot be reused within 30 days of deletion

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":3060, "message":"New Indonesian content can't be added while the existing Indonesian content is being deleted. Try again in 4 weeks or consider creating a new message template.", "errorId":"a1b2c3d4-e5f6-7890-abcd-ef1234567890", "timestamp":"2024-02-16T10:30:00.00Z" }

Internal server error

Schema

codeintegerrequired
Error code

messagestring
Error description

errorIdstring<uuid>required
Unique id of error. You can use it as reference when sending enquiries to 8x8 support

timestampstring<date-time>required
Data and time of the error occurence

{ "code":1001, "message":"Provided subAccountId doesn't belongs to your account", "errorId":"91b106f0-c0da-4aba-a43a-7af9c5893a80", "timestamp":"2017-04-19T02:31:19.4297387+00:00" }

{ "code":2000, "message":"Internal server error", "errorId":"db9dced4-3534-4d86-9d18-6b448af0d621", "timestamp":"2018-07-02T09:42:38.8988997+00:00" }
Source: https://developer.8x8.com/connect/reference/add-whatsapp-template · 8x8 CPaaS Developer Docs. Synced for support deflection.
WhatsApp Webhooks Reference
WhatsApp Webhooks Reference

Webhooks enable real-time, event-driven communication between the 8x8 platform and your application. When specific events occur (such as receiving a message, delivery confirmation, or template status change), 8x8 sends an HTTP POST request to your configured webhook URL with event details in JSON format.

Configuration

You can configure your webhook URLs in the 8x8 Connect portal under Webhooks.

Key Requirements:

Your webhook endpoint must be publicly accessible via HTTPS

Your server should respond with HTTP 200 within 5 seconds

Failed webhook deliveries will be retried with exponential backoff

Inbound Messages

Fires when a user sends a message to your WhatsApp number. This is the primary webhook for enabling two-way chat and building conversational applications.

Event Type: inbound_message_received

Use Cases:

Respond to customer inquiries automatically

Trigger workflows based on user input

Route messages to appropriate agents or systems

Process button/list selections from interactive messages

Inbound Message Types

The inbound message webhook structure varies based on the message type. Below are examples for the most common types.

Text Message

Sample JSON Payload:

{ "namespace":"ChatApps", "eventType":"inbound_message_received", "description":"ChatApps inbound message", "payload":{ "umid":"<UNIQUE_MESSAGE_ID>", "subAccountId":"<SUBACCOUNT_ID>", "timestamp":"2025-12-02T07:05:51Z", "user":{ "msisdn":"+15551234567", "channelUserId":"15551234567", "name":"<USER_NAME>" }, "recipient":{ "channel":"whatsapp", "channelId":"<CHANNEL_ID>" }, "type":"Text", "content":{ "text":"Hello" } } }

Key Fields:

type: "Text"

content.text: The text message content sent by the user

Media Message (Image, Video, Audio, Document)

Sample JSON Payload (Image):

{ "namespace":"ChatApps", "eventType":"inbound_message_received", "description":"ChatApps inbound message", "payload":{ "umid":"<UNIQUE_MESSAGE_ID>", "subAccountId":"<SUBACCOUNT_ID>", "timestamp":"2025-12-02T07:07:19Z", "user":{ "msisdn":"+15551234567", "channelUserId":"15551234567", "name":"<USER_NAME>" }, "recipient":{ "channel":"whatsapp", "channelId":"<CHANNEL_ID>" }, "type":"Image", "content":{ "url":"<MEDIA_FILE_URL>" } } }

Key Fields:

type: Message type - "Image", "Video", "Audio", "Document"

content.url: Pre-signed URL to download the media file (expires after 24 hours)

Media Type Values:

Image: Customer sent a photo

Video: Customer sent a video

Audio: Customer sent a voice message or audio file

Document: Customer sent a document (PDF, Word, Excel, etc.)

Interactive Message (Button Reply)

When a user responds to an interactive button or list, the payload includes the interactive response details.

Sample JSON Payload:

{ "namespace":"ChatApps", "eventType":"inbound_message_received", "description":"ChatApps inbound message", "payload":{ "umid":"<UNIQUE_MESSAGE_ID>", "subAccountId":"<SUBACCOUNT_ID>", "timestamp":"2025-12-02T06:58:50Z", "user":{ "msisdn":"+15551234567", "channelUserId":"15551234567", "name":"<USER_NAME>" }, "recipient":{ "channel":"whatsapp", "channelId":"<CHANNEL_ID>" }, "type":"Interactive", "content":{ "interactive":{ "type":"button_reply", "button_reply":{ "id":"option-2", "title":"FAQ" } } }, "replyToUmid":"<ORIGINAL_MESSAGE_UMID>" } }

Key Fields:

type: "Interactive"

content.interactive.type: "button_reply" or "list_reply"

content.interactive.button_reply.id: The button ID you defined

content.interactive.button_reply.title: The button text the user saw

replyToUmid: The UMID of your original interactive message

Interactive Response Types:

button_reply: User tapped a quick-reply button

list_reply: User selected an item from an interactive list

Flow Submission (nfmReply)

When a user completes a WhatsApp Flow, the submission is delivered as a special type of interactive message.

Sample JSON Payload:

{ "namespace":"ChatApps", "eventType":"inbound_message_received", "description":"ChatApps inbound message", "payload":{ "umid":"abc123-def456-ghi789", "subAccountId":"your-subaccount-id", "timestamp":"2026-01-15T10:30:00.000Z", "user":{ "msisdn":"+15551234567", "channelUserId":"15551234567" }, "recipient":{ "channel":"whatsapp", "channelId":"your-channel-id" }, "type":"Interactive", "content":{ "interactive":{ "type":"nfmReply", "nfmReply":{ "responseJson":"{\"customer_name\":\"Jane Smith\",\"email\":\"jane@example.com\",\"feedback\":\"Excellent service!\",\"flow_token\":\"<FLOW_TOKEN>\"}" } } } } }

Key Fields:

type: "Interactive"

content.interactive.type: "nfmReply" (indicates a Flow submission)

content.interactive.nfmReply.responseJson: JSON string containing the submitted form data

Parsing Flow Submissions:

The responseJson field contains a stringified JSON object. Always parse it before processing:

// Extract the response JSON string const responseJsonString = payload.content.interactive.nfmReply.responseJson; // Parse to object const submissionData =JSON.parse(responseJsonString); // Access submitted fields console.log(submissionData.customer_name);// "Jane Smith" console.log(submissionData.email);// "jane@example.com" console.log(submissionData.feedback);// "Excellent service!"

Important:

Always validate and sanitize submission data before processing

Store umid and flow_token for traceability

Respond with a confirmation message within seconds

Handle JSON parsing errors gracefully

See: WhatsApp Flows API - Webhook Integration for complete Flow submission handling guidance and examples.

Common Fields (All Message Types)

These fields appear in every inbound message webhook:

umid: Unique message identifier for this inbound message

subAccountId: Your subaccount identifier

timestamp: ISO 8601 timestamp when message was received

user.msisdn: Customer's phone number (E.164 format)

user.channelUserId: Customer's WhatsApp ID (phone without +)

user.name: Customer's WhatsApp display name (if available)

recipient.channel: Always "whatsapp"

recipient.channelId: Your WhatsApp channel (phone number) ID

type: Message type determines content structure

replyToUmid: Present if customer replied to a specific message

Outbound Delivery Receipts

Fires when the status of an outbound message changes. Status updates include sent, delivered, read, and failure states. Read receipt checks continue for up to 10 days after message delivery.

Event Type: outbound_message_status_changed

Use Cases:

Track message delivery success rates

Retry failed messages

Measure customer engagement (read receipts)

Update CRM systems with delivery status

Possible Status States:

sent: Message successfully sent to WhatsApp

delivered: Message delivered to recipient's device

read: Recipient opened and read the message

undelivered: Message failed to deliver

Sample JSON Payload (Delivered):

{ "namespace":"ChatApps", "eventType":"outbound_message_status_changed", "description":"ChatApps outbound message delivery receipt", "payload":{ "umid":"<UNIQUE_MESSAGE_ID>", "subAccountId":"<SUBACCOUNT_ID>", "channel":"whatsapp", "user":{ "msisdn":"+6512345678", "channelUserId":"6512345678" }, "status":{ "state":"delivered", "detail":"delivered_to_recipient", "timestamp":"2025-05-05T09:15:57.00Z" } } }

Sample JSON Payload (Read):

{ "namespace":"ChatApps", "eventType":"outbound_message_status_changed", "description":"ChatApps outbound message delivery receipt", "payload":{ "umid":"<UNIQUE_MESSAGE_ID>", "subAccountId":"<SUBACCOUNT_ID>", "channel":"whatsApp", "user":{ "msisdn":"+6512345678", "channelUserId":"6512345678" }, "status":{ "state":"read", "timestamp":"2025-05-17T06:27:52.45Z" } } }

Sample JSON Payload (Undelivered):

{ "namespace":"ChatApps", "eventType":"outbound_message_status_changed", "description":"ChatApps outbound message delivery receipt", "payload":{ "umid":"<UNIQUE_MESSAGE_ID>", "subAccountId":"<SUBACCOUNT_ID>", "channel":"whatsapp", "user":{ "msisdn":"+6512345678", "channelUserId":"+6512345678" }, "status":{ "state":"undelivered", "detail":"rejected_by_operator", "timestamp":"2016-01-01T00:00:00Z", "errorCode":15, "errorMessage":"Invalid destination" } } }

Key Fields:

umid: Unique message identifier matching your original send request

status.state: Current delivery state

status.detail: Additional context about the status

errorCode & errorMessage: Present only for failed messages

Template Status Updates

Fires when your template's approval status changes. Meta reviews all templates before they can be used, and this webhook notifies you of approval, rejection, pausing, or disabling.

Event Type: template_status_update

Use Cases:

Monitor template approval workflow

Alert team when templates are rejected

Track when templates are paused due to quality issues

Automate template resubmission after fixing issues

Possible Status Values:

APPROVED: Template approved and ready to send

REJECTED: Template failed review (check reason field)

PENDING: Under Meta review (up to 24 hours)

PAUSED: Temporarily disabled due to quality score

DISABLED: Permanently disabled after multiple pauses

Sample JSON Payload (Status Update - Rejected):

{ "eventId":"0f88f5c4-fae7-4dcf-8ff2-b2990133edea", "timestamp":"2025-01-01T00:00:00.00Z", "provider":"WhatsApp", "businessAccountId":"<BusinessAccountId>", "accountId":"<AccountId>", "eventType":"template_status_update", "eventDetails":{ "templateId":"<TEMPLATE_ID>", "templateName":"<TEMPLATE_NAME>", "templateLanguage":"<TEMPLATE_LANGUAGE>", "meta":{ "status":"REJECTED", "reason":"INCORRECT_CATEGORY" } } }

Common Rejection Reasons:

INCORRECT_CATEGORY: Template submitted in wrong category (e.g., promotional content in UTILITY)

INVALID_FORMAT: Parameter formatting issues or missing samples

ABUSIVE_CONTENT: Violates Meta's content policies

SCAM: Appears to be fraudulent or misleading

Key Fields:

templateName & templateLanguage: Identifies which template changed

meta.status: New status value

meta.reason: Rejection reason (present only when status is REJECTED)

Template Quality Updates

Fires when Meta updates the quality score for your template based on user feedback (blocks, reports). Quality scores affect whether templates get paused or disabled.

Event Type: template_quality_update

Use Cases:

Monitor template performance in real-time

Alert teams when quality degrades

Pause campaigns using low-quality templates

Correlate quality changes with campaign timing

Quality Score Values:

GREEN (High): Good user feedback, no issues

YELLOW (Medium): Some negative feedback, monitor closely

RED (Low): Poor feedback, template may be auto-paused

UNKNOWN: New template with insufficient data

Sample JSON Payload (Quality Update):

{ "eventId":"0f88f5c4-fae7-4dcf-8ff2-b2990133edea", "timestamp":"2025-01-01T00:00:00.00Z", "provider":"WhatsApp", "businessAccountId":"<BusinessAccountId>", "accountId":"<AccountId>", "eventType":"template_quality_update", "eventDetails":{ "templateId":"<TEMPLATE_ID>", "templateName":"<TEMPLATE_NAME>", "templateLanguage":"<TEMPLATE_LANGUAGE>", "meta":{ "previousQualityScore":"UNKNOWN", "newQualityScore":"GREEN" } } }

Key Fields:

meta.previousQualityScore: Previous quality rating

meta.newQualityScore: Updated quality rating

Quality-Based Pausing:

1st RED score: Paused for 3 hours

2nd RED score: Paused for 6 hours

3rd RED score: Permanently disabled

Phone Number Quality & Messaging Limit Updates

Fires when your phone number's quality rating changes or when Meta adjusts your account's messaging tier limits based on sending patterns and quality.

Event Type: phone_number_quality_update

Use Cases:

Monitor account health and reputation

Track messaging limit increases as you scale

Alert on limit downgrades due to quality issues

Plan capacity based on current tier

Messaging Tier Limits:

TIER_250: 250 unique users per 24 hours (new accounts)

TIER_1K: 1,000 unique users per 24 hours

TIER_10K: 10,000 unique users per 24 hours

TIER_100K: 100,000 unique users per 24 hours

UNLIMITED: No daily limit

Sample JSON Payload (Messaging Limit Upgrade):

{ "eventId":"0f88f5c4-fae7-4dcf-8ff2-b2990133edea", "timestamp":"2025-01-01T00:00:00.00Z", "provider":"WhatsApp", "businessAccountId":"<BusinessAccountId>", "accountId":"<AccountId>", "eventType":"phone_number_quality_update", "eventDetails":{ "displayPhoneNumber":"15550783881", "meta":{ "event":"UPGRADE", "currentLimit":"TIER_10K", "oldLimit":"TIER_1K" } } }

Sample JSON Payload (Quality Downgrade):

{ "eventId":"0f88f5c4-fae7-4dcf-8ff2-b2990133edea", "timestamp":"2025-01-01T00:00:00.00Z", "provider":"WhatsApp", "businessAccountId":"<BusinessAccountId>", "accountId":"<AccountId>", "eventType":"phone_number_quality_update", "eventDetails":{ "displayPhoneNumber":"15550783881", "meta":{ "event":"FLAGGED", "reason":"QUALITY_DECREASE" } } }

Key Fields:

displayPhoneNumber: Which phone number is affected

meta.event: Type of change (UPGRADE, DOWNGRADE, FLAGGED)

meta.currentLimit & meta.oldLimit: Tier change for limit updates

meta.reason: Reason for quality flags

Event Types:

UPGRADE: Messaging limit increased (good sending history)

DOWNGRADE: Messaging limit decreased (quality issues)

FLAGGED: Phone number quality issue detected

Webhook Security Best Practices

Verify Webhook Origin

Always verify that webhook requests come from 8x8:

IP Whitelisting: Configure your firewall to accept webhooks only from 8x8's IP ranges

Signature Verification: Check the X-8x8-Signature header (if provided)

HTTPS Only: Never accept webhooks over unencrypted HTTP

Handle Retries Gracefully

8x8 retries failed webhooks with exponential backoff:

Make your webhook endpoint idempotent (safe to call multiple times)

Use the umid or eventId to deduplicate events

Return HTTP 200 quickly, then process asynchronously

Error Handling

// Example webhook handler (Node.js/Express) app.post('/webhooks/whatsapp',async(req, res)=>{ // Return 200 immediately res.status(200).send('OK'); // Process asynchronously try{ const event = req.body; awaitprocessWebhook(event); }catch(error){ console.error('Webhook processing failed:', error); // Log for manual review, don't fail the request } });

Testing Webhooks

Local Development

Use tools like ngrok to expose your local server for webhook testing:

ngrok http 3000 # Use the generated HTTPS URL in webhook configuration

Webhook Logs

The 8x8 Connect portal provides webhook delivery logs:

View recent webhook attempts

See response codes and timing

Retry failed deliveries manually

Related Resources

WhatsApp over 8x8 API - Main API guide

Operations, Monitoring & Troubleshooting - Error handling and debugging

Governance, Security & Compliance - Security best practices
Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-webhooks · 8x8 CPaaS Developer Docs. Synced for support deflection.
WhatsApp over 8x8 API
WhatsApp over 8x8 API

This guide provides the technical foundation for integrating the 8x8 Messaging App API for WhatsApp into your applications, CRMs, and backend systems. While the 8x8 Connect portal is ideal for managing campaigns and support, the API provides the power and flexibility for full automation and custom workflows.

Authentication

All API requests are authenticated using a Bearer Token. Include an Authorization header with every API request, using the API Key generated from the 8x8 Connect portal.

Header Format:

Authorization: Bearer YOUR_API_KEY

Generate API Keys:

You can generate and manage your API keys in the 8x8 Connect portal under API keys.

Security Best Practices:

Store API keys securely in environment variables (never hardcode)

Rotate keys regularly

Use IP whitelisting for additional security (configure in portal)

Business-initiated Conversations: Templates

Templates are pre-approved message formats required to start a conversation with a customer. Using templates via the API is a two-step process:

Create the template (registers with Meta for approval)

Send the template (delivers to customers after approval)

These are two different API calls with different endpoints and requirements.

Why Templates Are Required

WhatsApp requires templates for business-initiated messages to:

Prevent spam and maintain platform quality

Ensure messages follow Meta's content policies

Provide consistent user experience

Support multiple languages with standardized formats

Key Concept: You cannot send freeform messages to initiate a conversation. You must start with an approved template. Once the customer replies, a 24-hour window opens for freeform messaging.

Creating a Template via API

Creating a template registers it with a specific WhatsApp Channel (phone number) and submits it to Meta for approval. Approval typically takes up to 24 hours.

Endpoint:

POST https://chatapps.8x8.com/api/v1/accounts/{accountId}/channels/{channelId}/templates

Path Parameters:

{accountId}: Your main 8x8 Account ID

{channelId}: The specific WhatsApp Channel ID (phone number) for this template

Template Categories:

You must specify one of three categories:

UTILITY: Account updates, order status, appointments (non-promotional)

MARKETING: Promotional offers, new products, retargeting

AUTHENTICATION: One-time passcodes (OTP) for verification only

Standard Example (Marketing Template with Image Header & Buttons):

This payload creates a MARKETING template with an image header, a variable in the body, a footer, and two buttons (one URL button with a variable and one Quick Reply).

View JSON

{ "language":"en_US", "name":"marketing_image_template_demo", "category":"MARKETING", "components":[ { "type":"HEADER", "format":"image", "examples":[ "https://chatapps.8x8.com/files/991c9667f7644584acf91aa8dd9fba60.png?token=..." ] }, { "type":"BODY", "text":"Hi {{1}}, ready to elevate your customer communications? Discover the power of 8x8 CPaaS.", "examples":[ "Tony" ] }, { "type":"FOOTER", "text":"Powered by 8x8" }, { "type":"BUTTONS", "buttons":[ { "type":"URL", "text":"Discover all channels", "url":"https://cpaas.8x8.com/en/products/{{1}}", "examples":[ "omnichannel-messaging" ] }, { "type":"quick_reply", "text":"Talk to Sales" } ] } ] }

Key Fields:

language: Template language code (e.g., en_US, es_MX)

name: Unique identifier (lowercase, underscores only)

category: Template category (affects approval and usage rules)

components: Array of component objects (BODY required, HEADER/FOOTER/BUTTONS optional)

Component Constraints:

Header media (IMAGE, VIDEO, DOCUMENT) can be uploaded via Upload Media API or self-hosted

Each parameter ({{1}}, {{2}}) requires sample values in examples array

Button text limited to 25 characters, URL limited to 2000 characters

For detailed component specifications (character limits, format requirements, button types), see:

Template Components Reference - Complete technical specifications

For more template examples (authentication OTP, videos, carousels, locations, etc.), see:

Template Message API Library - All template type examples

Sending a Template Message via API

Once a template is approved (status: APPROVED), you can send it to customers to initiate conversations.

Endpoint:

POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages

Path Parameters:

{subAccountId}: The Subaccount ID that owns the channel

Standard Example (Sending the Marketing Template Above):

This payload sends the marketing template we created above, providing actual values for the header image, body variable, and button URL parameter.

View JSON

{ "user":{ "msisdn":"+15551234567" }, "type":"template", "content":{ "template":{ "language":"en_US", "name":"marketing_image_template_demo", "components":[ { "type":"header", "parameters":[ { "type":"image", "url":"https://chatapps.8x8.com/files/991c9667f7644584acf91aa8dd9fba60.png?token=..." } ] }, { "type":"body", "parameters":[ { "type":"text", "text":"Jason" } ] }, { "type":"button", "index":"0", "subType":"url", "parameters":[ { "type":"text", "text":"omnichannel-messaging" } ] } ] } } }

Key Concepts:

Parameter order must match template variables: {{1}}, {{2}}, {{3}}

Use the exact name and language from your approved template

Header media requires url parameter pointing to uploaded file

Button parameters use index to specify which button (0-based)

Footer component is not included in send payload (static text from template)

For complete send examples (all template types with exact payload structures), see:

Template Message API Library - All template type examples

User-initiated Conversations: Interactive Messages

Once a customer replies to your template or messages you first, a 24-hour customer service window opens. During this window, you can send freeform, interactive messages without templates.

Why Interactive Messages Matter

Interactive messages enable:

Rich, dynamic conversations without waiting for template approval

Buttons and lists for user selection (better UX than free text)

Media sharing (images, videos, documents, locations)

Immediate responses within the 24-hour window

Key Concept: Interactive messages can ONLY be sent within the 24-hour window. To start a new conversation after the window expires, you must send a template.

Sending Interactive Messages via API

All interactive message types use the same endpoint as template messages, but with different type and content structures.

Endpoint:

POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages

Message Types Available:

Text: Simple text messages

Media: Images, videos, audio, documents

Location: Share coordinates and addresses

Interactive Buttons: Up to 3 quick-reply buttons

Interactive Lists: Up to 10 menu items in a scrollable list

CTA Buttons: Call-to-action buttons (URL or phone)

Product Messages: Catalog integration for e-commerce

For complete payload examples for all message types, see: Interactive Message API Library

Example: Interactive Buttons

Interactive buttons are the most common interactive message type. Send a message with up to 3 quick-reply buttons. When the user taps a button, you receive the button's title as a text reply via webhook.

View JSON

{ "user":{ "msisdn":"+15551234567" }, "type":"interactive", "content":{ "interactive":{ "type":"button", "body":{ "text":"Is your issue resolved?" }, "action":{ "buttons":[ { "type":"reply", "reply":{ "id":"yes-1", "title":"Yes" } }, { "type":"reply", "reply":{ "id":"no-1", "title":"No" } } ] } } } }

When to Use: Yes/no questions, multiple choice selections, quick feedback

Webhook Response: When the user taps a button, your webhook receives:

View JSON

{ "namespace":"ChatApps", "eventType":"inbound_message_received", "description":"ChatApps inbound message", "payload":{ "umid":"<UNIQUE_MESSAGE_ID>", "subAccountId":"<SUBACCOUNT_ID>", "timestamp":"2025-12-02T06:58:50Z", "user":{ "msisdn":"+15551234567", "channelUserId":"15551234567", "name":"<USER_NAME>" }, "recipient":{ "channel":"whatsapp", "channelId":"<CHANNEL_ID>" }, "type":"Interactive", "content":{ "interactive":{ "type":"button_reply", "button_reply":{ "id":"yes-1", "title":"Yes" } } }, "replyToUmid":"<ORIGINAL_MESSAGE_UMID>" } }

Key Fields:

type: "Interactive" (not "Text")

content.interactive.type: "button_reply"

content.interactive.button_reply.id: The button ID you defined ("yes-1")

content.interactive.button_reply.title: The button text displayed to user ("Yes")

For complete webhook documentation, see: Webhooks Reference - Inbound Messages

Receiving Messages & Delivery Status: Webhooks

To build two-way conversations and track message delivery, configure webhooks. Webhooks are HTTP POST requests that 8x8 sends to your server when events occur.

Key Webhook Types:

Inbound Messages: Customer replies and messages

Delivery Receipts: Message delivery, read, and failure status

Template Status: Approval, rejection, quality changes

Messaging Limits: Account tier upgrades and quality flags

Configuration:

Set up webhook URLs in the 8x8 Connect portal under Webhooks.

Example: Receiving a Customer Reply

When a customer sends a text message, 8x8 posts to your webhook:

{ "namespace":"ChatApps", "eventType":"inbound_message_received", "payload":{ "umid":"9e09ac86-bd74-5465-851d-1eb5a5fdbb9a", "subAccountId":"SubAccount-1", "timestamp":"2016-01-01T14:34:56.017Z", "user":{ "msisdn":"+12025550023" }, "type":"Text", "content":{ "text":"I need help with my order" } } }

Your Response:

Your server should:

Return HTTP 200 immediately

Process the message asynchronously

Send a reply using the Send Message API (if within 24-hour window)

For complete webhook documentation (all event types, payloads, security, and best practices), see:

Webhooks Reference - Complete webhook guide

File & Media Management

WhatsApp supports rich media (images, videos, documents, audio). You can either:

Host files on your own HTTPS server

Upload files to 8x8's media hosting service

Using 8x8 Media Hosting

Upload Endpoint:

POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/files

Upload Request (multipart/form-data):

curl -X POST "https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/files" \ -H "Authorization: Bearer YOUR_API_KEY" \ -F "file=@/path/to/image.jpg"

Response:

{ "status":"success", "data":{ "url":"https://chatapps.8x8.com/files/abc123def456.jpg?token=xyz789" } }

Using the URL in Messages:

Once uploaded, use the returned url in your message payloads:

{ "user":{ "msisdn":"+15551234567" }, "type":"Image", "content":{ "url":"https://chatapps.8x8.com/files/abc123def456.jpg?token=xyz789", "text":"Here is your order receipt" } }

Supported Media Types:

Images: JPEG, PNG (max 5MB)

Videos: MP4, 3GPP (max 16MB)

Audio: AAC, MP3, AMR, OGG (max 16MB)

Documents: PDF, DOCX, XLSX, etc. (max 100MB)

Alternative: Self-hosted Media

You can provide your own HTTPS URLs instead of uploading to 8x8:

{ "type":"Image", "content":{ "url":"https://yourdomain.com/images/product.jpg" } }

Requirements for self-hosted media:

Must be publicly accessible via HTTPS

Must not require authentication

Must return appropriate Content-Type headers

For detailed media management, see: Media Hosting & Management - Complete guide with best practices, security considerations, and troubleshooting

Next Steps

Now that you understand the core API concepts, explore these resources to build your integration:

API Reference Libraries:

Template Components Reference - Detailed component specifications (character limits, formats, constraints)

Template Message API Library - All template types with Create & Send payloads

Interactive Message API Library - All interactive message types

Webhooks Reference - Complete webhook event documentation

Implementation Guides:

Advanced Capabilities - Build conversational journeys with Automation Builder

Operations, Monitoring & Troubleshooting - Error handling and debugging

Governance, Security & Compliance - Security best practices and compliance rules

Conceptual Foundation:

Concepts & Fundamentals - Understand the 24-hour window, quality ratings, and limits

Message Types & Templates - Deep dive into template rules and components
Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-over-8x8-api · 8x8 CPaaS Developer Docs. Synced for support deflection.

Ensure reliable and fast media delivery in your WhatsApp messages by leveraging the 8x8 media hosting service. When you upload media files through the 8x8 API, they are automatically transferred to WhatsApp's media hosting infrastructure during message sending, guaranteeing optimal delivery performance and reliability.

Overview

The 8x8 platform provides a robust media management workflow that ensures your WhatsApp media messages are delivered reliably and efficiently:

Upload your media files to 8x8's temporary hosting via the Upload Media API
Reference the uploaded media URL in your WhatsApp message payloads
Automatic Transfer to WhatsApp's infrastructure happens during message sending
Reliable Delivery is ensured through WhatsApp's optimized global CDN

This architecture eliminates common media delivery issues such as slow loading times, unreachable URLs, geographical restrictions, and authentication barriers.

Why Use 8x8 Media Hosting?

Reliability Benefits:

Guaranteed Delivery: Media is transferred directly to WhatsApp's infrastructure, eliminating third-party hosting dependencies
No Authentication Issues: Bypasses authentication requirements that can block WhatsApp from fetching externally hosted media
Geographical Optimization: WhatsApp's global CDN ensures fast delivery regardless of recipient location
Consistent Performance: Avoids slow or unreliable third-party hosting that can cause message failures

Operational Benefits:

Simplified Architecture: No need to maintain public-facing media hosting infrastructure
No CDN Required: Eliminates the need for your own Content Delivery Network
Security: Temporary hosting ensures media is only accessible during the message creation process
Scalability: Handles high-volume campaigns without infrastructure concerns

Supported Media Types & Limits

WhatsApp supports multiple media types through the 8x8 platform. Each type has specific format requirements and file size limitations imposed by Meta.

Media Type Specifications

Media Type	Supported Formats	Maximum File Size	Common Uses
Image	JPEG (`.jpeg`, `.jpg`) PNG (`.png`)	5 MB	Product images, promotional graphics, QR codes, infographics, receipts
Video	MP4 (`.mp4`) 3GP (`.3gp`)	16 MB	Product demos, tutorials, promotional videos, short clips
Document	PDF (`.pdf`) Word (`.doc`, `.docx`) Excel (`.xls`, `.xlsx`) PowerPoint (`.ppt`, `.pptx`) Text (`.txt`)	100 MB	Invoices, contracts, receipts, product catalogs, user manuals, reports
Audio	AAC (`.aac`) M4A (`.m4a`) AMR (`.amr`) MP3 (`.mp3`) OGG (`.ogg`) OPUS (`.opus`)	16 MB	Voice messages, audio instructions, music clips, podcasts

📘 Format Compatibility

For a complete list of supported content types across all messaging channels, see the Supported Messaging Apps Content Types reference.

Media Quality Recommendations

While WhatsApp allows files up to the maximum sizes listed above, following these recommendations will ensure optimal delivery performance:

Images: Keep under 1 MB for fastest loading; use PNG format for graphics with transparency, JPEG for photos
Videos: Compress to under 10 MB when possible; use H.264 codec for maximum compatibility
Documents: Optimize PDFs (compress images within PDFs) to reduce file size
Audio: Use AAC or MP3 format with appropriate bitrate (128-192 kbps for voice, 256+ kbps for music)

Recommended Image Dimensions:

Template Headers: 1200 x 630 pixels (1.9:1 ratio)
Interactive Messages: 1080 x 1080 pixels (1:1 ratio) or 1200 x 630 pixels (1.9:1 ratio)
Carousel Cards: 1080 x 1080 pixels (1:1 ratio)

Uploading Media Files

Use the Upload Media API to upload files to 8x8's temporary hosting service. Once uploaded, you'll receive a response containing the file name and token that can be used to construct the media URL.

Upload Media API

Endpoint:

POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/files

Authentication:

Authorization: Bearer YOUR_API_KEY

Request Format:

Content-Type: multipart/form-data
Body: File upload with key file

Upload Example

curl -X POST "https://chatapps.8x8.com/api/v1/subaccounts/YOUR_SUBACCOUNT_ID/files" \
  -H "Authorization: Bearer YOUR_API_KEY" \
  -F "file=@/path/to/your/image.png"

Upload Response

When the upload succeeds, you'll receive a response containing the file name and token:

Response Body:

{
"fileName":"f041c4fa554941b2acba0191859707b9.png",
"token":"CfDJ8LwbBIzqYzxMo4VXraj4E8np2JMuXKnwMWzzWnhfPTnXEo7eCgiy7XIhp0HrdaHCbfusvZ0b29r0Txo86-zi4iXaPAXoE7JChY3sRqIbT-Aa0lNyAq_vAW-DhlbKRMcCR3cmBhPGf_cVOSpSKhGvvzujy5LpFfQu-DLtRI4oM3WUlEilCmLqm10eWyPCC5bhKA"
}

Response Headers:

content-type: application/json; charset=utf-8
location: /files/f041c4fa554941b2acba0191859707b9.png?token=CfDJ8LwbBIzqYzxMo4VXraj4E8np2JMuXKnwMWzzWnhfPTnXEo7eCgiy7XIhp0HrdaHCbfusvZ0b29r0Txo86-zi4iXaPAXoE7JChY3sRqIbT-Aa0lNyAq_vAW-DhlbKRMcCR3cmBhPGf_cVOSpSKhGvvzujy5LpFfQu-DLtRI4oM3WUlEilCmLqm10eWyPCC5bhKA
cache-control: no-store,no-cache

Response Fields:

fileName: The generated filename (UUID-based) for your uploaded file
token: Authentication token required to access the file

Important Headers:

location: The relative path to access your uploaded file (includes both filename and token)

⚠️ Constructing the Media URL

To use the uploaded media in your messages, construct the full URL by combining the base URL with the fileName and token:
https://chatapps.8x8.com/files/{fileName}?token={token}
Example:
https://chatapps.8x8.com/files/f041c4fa554941b2acba0191859707b9.png?token=CfDJ8LwbBIzqYzxMo4VXraj4E8np2JMuXKnwMWzzWnhfPTnXEo7eCgiy7XIhp0HrdaHCbfusvZ0b29r0Txo86-zi4iXaPAXoE7JChY3sRqIbT-Aa0lNyAq_vAW-DhlbKRMcCR3cmBhPGf_cVOSpSKhGvvzujy5LpFfQu-DLtRI4oM3WUlEilCmLqm10eWyPCC5bhKA

Retrieving Media Files

You can retrieve previously uploaded media files using the information from the upload response. The location header provides the complete path including the filename and token.

Get Media API

Endpoint:

GET https://chatapps.8x8.com/files/:fileName?token=YOUR_TOKEN

Authentication:

The token query parameter (from the upload response) serves as authentication
No Bearer token header required

Get Media Example

curl -X GET "https://chatapps.8x8.com/files/f041c4fa554941b2acba0191859707b9.png?token=CfDJ8LwbBIzqYzxMo4VXraj4E8np2JMuXKnwMWzzWnhfPTnXEo7eCgiy7XIhp0HrdaHCbfusvZ0b29r0Txo86-zi4iXaPAXoE7JChY3sRqIbT-Aa0lNyAq_vAW-DhlbKRMcCR3cmBhPGf_cVOSpSKhGvvzujy5LpFfQu-DLtRI4oM3WUlEilCmLqm10eWyPCC5bhKA" \
  --output downloaded-image.png

💡 Quick Access

You can also paste the complete URL (with token) directly into your browser's address bar to download or view the file.

Media Upload Best Practices

1. Optimize Before Upload

Images:

Compress images using tools like TinyPNG, Squoosh, or ImageOptim
Target file size: < 500 KB for templates, < 1 MB for all images
Use JPEG for photographs, PNG for graphics with transparency
Resize to recommended dimensions (1200x630 or 1080x1080)

Videos:

Use H.264 codec with AAC audio for maximum compatibility
Compress to target bitrate: 1-2 Mbps for standard quality
Keep duration under 30 seconds for marketing content
Test playback on mobile devices before uploading

Documents:

Compress PDF files using PDF optimization tools
Remove unnecessary embedded fonts and images
Consider splitting large documents into smaller files
Test document rendering on mobile devices

Audio:

Use AAC or MP3 format
Set appropriate bitrate: 64-96 kbps for voice, 128-192 kbps for music
Normalize audio levels to prevent volume inconsistencies
Keep duration reasonable (under 2 minutes for most use cases)

2. Validate Media Before Upload

Create a validation checklist before uploading:

File format matches WhatsApp's supported types
File size is under the maximum limit
Media quality is acceptable for the use case
File is not corrupted (test by opening locally)
Image dimensions are appropriate for WhatsApp display
Video/audio is playable without special codecs
Document renders correctly on mobile devices

3. Implement Error Handling

Always implement proper error handling for media uploads. Common errors include file size exceeding limits, unsupported formats, or network issues. Implement retry logic with exponential backoff for transient failures.

4. Store Media Information

After successful upload:

Save the fileName returned in the response
Save the token for accessing the file
Construct and store the complete URL for use in messages
Associate URLs with your campaigns or message templates
Implement backup strategy for critical media assets

Troubleshooting Media Issues

Upload Failures

Issue: Upload request returns an error

Common Causes & Solutions:

Error	Cause	Solution
413 Payload Too Large	File exceeds maximum size limit	Compress or resize the file to meet size requirements
415 Unsupported Media Type	File format not supported	Convert to a supported format (JPEG/PNG for images, MP4 for videos, etc.)
401 Unauthorized	Invalid or expired API key	Verify your API key and ensure it's valid and active
400 Bad Request	Malformed request or missing file	Check request format and ensure file is included with key `file`
500 Internal Server Error	Server-side issue or corrupted file	Retry the upload; if persists, verify file is not corrupted

Media Not Displaying in Messages

Issue: Uploaded media doesn't display when message is sent

Troubleshooting Steps:

Verify URL Format
- Ensure you're using the complete URL: https://chatapps.8x8.com/files/{fileName}?token={token}
- Check for any URL encoding issues or truncation
- Confirm both fileName and token are included
Test Media Access
- Try opening the media URL in a web browser
- Confirm the media displays/downloads correctly
- Verify the token is still valid
Check File Format
- Verify the file format matches WhatsApp's requirements
- Ensure MIME type is correct for the media type
- Test with a different file if issues persist
Validate Message Payload
- Review the JSON structure for syntax errors
- Confirm media URL is in the correct parameter location
- Check that template component types match (e.g., "type": "image" for image media)

Slow Upload Performance

Issue: Media uploads taking longer than expected

Solutions:

Compress Files First
- Reduce file size before uploading (especially important for videos and high-res images)
- Use appropriate compression tools for each media type
Check Network Connection
- Verify stable internet connection with adequate upload bandwidth
- Consider using a wired connection for large file uploads
Implement Retry Logic
- Set appropriate timeout values for large media uploads
- Use exponential backoff for failed uploads

Related Resources

Message Types & Templates - Creating templates with media headers
Template Message API Library - Template message examples with media
Interactive Message API Library - Session message examples with media
Supported Messaging Apps Content Types - Complete media format reference
Developer Tools - API key management and testing tools

❗️ Need Help?

Contact your account manager or 8x8 Support for assistance with:

Media upload issues or errors

Understanding media retention policies

Optimizing media for specific use cases

Best practices for your specific industry or use case

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-media-hosting · 8x8 CPaaS Developer Docs. Synced for support deflection.

WhatsApp in 8x8 Connect
WhatsApp in 8x8 Connect

Beyond the API, the 8x8 Connect portal offers three powerful, ready-to-use solutions to manage your WhatsApp communications. This section provides an overview of how to use Campaigns for bulk messaging, 8x8 Converse for agent-based support, and the Automation Builder for creating no-code workflows.

Campaigns (formerly MCS) with WhatsApp

The Campaigns tool in 8x8 Connect allows you to send high-volume, template-based WhatsApp messages to a list of your customers. This is ideal for marketing announcements, proactive notifications, and re-engagement campaigns.

How to Send WhatsApp Messages using Campaigns

Sending WhatsApp Messages through Campaigns follows a simple, step-by-step process in the portal:

Select Channel: Navigate to Campaigns from the main menu, click "Create a new campaign", and select "Messaging Apps".

Choose Sender: Select the Subaccount and to specify the WhatsApp Channel you want to send from.

Add Recipients: Upload your customer list. You can:

Upload a file (.csv, .txt, .xlsx) containing phone numbers and data for personalization.

Manually type in numbers.

Select contacts from your saved Contact Groups.

Map Fields: If you upload a file, you will map your columns to system fields (like Mobile) or custom fields (like FirstName) that can be used as variables.

Compose Message:

Select Template or Compose Message: You have two options for your message content:

Use a WhatsApp Template: Select an approved WhatsApp Template from the list. This is mandatory if you are initiating a conversation or contacting users outside the 24-hour customer service window.

Variable Mapping: If your template has variables (e.g., {{1}}), you can map them to the custom fields from your uploaded file (e.g., map {{1}} to your FirstName column).

Media Replacement: If your template includes a media header (image, video, document), you can specify the media to be used. You can either provide a publicly accessible Media URL or use the direct file upload option to have 8x8 host the media.

Compose a Text Message: You can write a freeform text message. This option will only be delivered to recipients who are within the 24-hour customer service window (i.e., they have messaged you in the last 24 hours).

Media Optimization: All media (from URLs or direct uploads) is automatically processed and optimized by Meta's media hosting. This ensures fast, reliable delivery without you needing to manage resource availability.

Review and Send: Name your campaign, review the details, and choose to send it immediately or schedule it for a later time.

WhatsApp in 8x8 Converse (Agent Experience)

8x8 Converse is a chat-based customer service platform that allows your support agents to manage two-way conversations with customers across multiple channels, including WhatsApp.

How it Works

When a customer sends a WhatsApp message to your business phone number, 8x8 Converse can automatically route that message as a "ticket" to the correct agent or support queue.

Unified Inbox: Agents see all customer conversations, whether from WhatsApp, SMS, or other channels, in a single, unified inbox.

Two-Way Chat: Agents can reply to customers directly from the Converse portal. Because these are user-initiated replies, agents can send freeform (non-template) messages, including text and media, within the 24-hour customer service window.

Ticket Management: Conversations are managed as tickets with statuses like New, Open, Pending, or Resolved, allowing for a structured support workflow.

Advanced Queuing: As an administrator, you can configure queues to automatically route incoming WhatsApp messages to specific agents based on rules, such as:

Channel-based queueing: Send all messages from a specific WhatsApp number to a dedicated team.

Country-based queueing: Route messages from specific country codes to agents who speak the local language.

Customer group-based queueing: Route messages from "VIP" customers (managed in your 8x8 Contacts) to a priority queue.

WhatsApp in 8x8 Automation Builder

The 8x8 Automation Builder is a visual, no-code tool in the 8x8 Connect portal that lets you create powerful, automated communication workflows. WhatsApp is a fully integrated channel in the Automation Builder.

How it Works

You can create workflows that are triggered by incoming WhatsApp messages or perform actions like sending WhatsApp messages.

Common Use Cases:

Chatbots & Menus: Create an automated chatbot that is triggered by an inbound WhatsApp message. You can send a menu ("Press 1 for support, Press 2 for hours") and use the Branch and Wait For Reply steps to guide the user.

Opt-Out Handling: Automatically listen for keywords like "STOP" on your WhatsApp number. When a user sends "STOP," you can trigger a workflow that calls an API to add them to a "do-not-contact" list and sends a confirmation message.

External System Integration: Connect WhatsApp to other business tools. For example, you can build a workflow that:

Receives a WhatsApp message (e.g., "Schedule appointment").

Uses the HTTP Request step to check your Google Calendar for an open slot.

Sends a WhatsApp message back to the user with the available times.

Waits for their reply.

Sends another HTTP Request to book the appointment in your system.
Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-in-8x8-connect · 8x8 CPaaS Developer Docs. Synced for support deflection.
The 8x8 WhatsApp Business Platform
The 8x8 WhatsApp Business Platform

Welcome to the 8x8 Integration for the WhatsApp Business Platform! This documentation guides you through using 8x8's communication tools to connect with your customers on WhatsApp.

Why Use WhatsApp for Business?

WhatsApp offers a unique opportunity for businesses to engage customers where they are most active. With over 2 billion monthly active users globally and over 200 million businesses utilizing the platform, this massive scale provides:

Unparalleled Reach: Connect directly with billions of engaged users on their preferred messaging channel.

Rich Communication: Go beyond simple text with images, videos, documents, interactive buttons, product catalogs, and more.

Personalized Engagement: Build direct, trusted relationships through one-on-one conversations and timely notifications.

Improved Customer Experience: Offer support, send alerts, facilitate transactions, and run marketing campaigns within a familiar and convenient interface.

What is the 8x8 Integration for WhatsApp Business Platform?

8x8 provides a seamless, reliable solution for businesses to connect with customers effortlessly on WhatsApp. Our integration is powered by the official Meta WhatsApp Business Platform (Cloud API) and made easily accessible through 8x8's robust 8x8 Connect platform.

8x8 Connect acts as your central hub, simplifying how you use WhatsApp for business by providing two primary methods:

Via the 8x8 Connect Portal: An intuitive, all-in-one web interface for managing your account, sending messages manually or in bulk (by using the Campaigns), managing templates, viewing analytics, and configuring settings.

Via the 8x8 Messaging App API: A powerful, developer-focused API for integrating WhatsApp messaging directly into your own applications, CRM, or backend systems to automate communication workflows.

Essentially, 8x8 provides the tools (both UI and API) and infrastructure to easily manage and scale your customer interactions on WhatsApp.

Key Capabilities

Send All Message Types: Engage customers with business-initiated Template Messages (for notifications, OTPs, and marketing) and respond with Interactive Messages (including text, media, buttons, and lists).

Manage Templates: Create, submit, and manage your WhatsApp templates directly through the 8x8 Connect portal or via the API.

Integrate Your Tools: Connect WhatsApp to your CRM and support desks, with support for Zendesk, Salesforce, Zapier, and Workato.

Handle Two-Way Conversations: Receive and respond to customer messages in real-time using webhooks or through agent tools like 8x8 Converse.

Where to Start

To help you find the information you need, we have organized this documentation by your primary goal.

For All Users (Start Here) We recommend starting with the fundamentals. These concepts are essential for understanding how the platform works.

See: Business-Initiated Conversations (Outbound)

See: User-Initiated Conversations (Inbound)

For Business Users & Marketers Learn how to use the 8x8 Connect portal to manage your presence, create templates, and run campaigns without writing code.

See: Getting Started with WhatsApp (Portal-first)

See: Campaigns (formerly MCS) with WhatsApp

For Developers & Integrators Dive into the API documentation to build custom integrations, send messages programmatically, and manage webhooks.

See: Authentication

See: Business-initiated Conversations: Templates

See: User-initiated Conversations: Interactive Messages

For Developers Building Interactive Experiences Learn how to collect structured data using WhatsApp Flows - guided forms that run inside WhatsApp conversations.

See: WhatsApp Flows - Create, send, and manage interactive forms for data collection

See: Flow Examples Library - Industry-specific implementations with complete payloads
Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-hub · 8x8 CPaaS Developer Docs. Synced for support deflection.

WhatsApp Flows in 8x8 Connect

This guide walks you through creating, testing, and deploying WhatsApp Flows using the visual, no-code interface in the 8x8 Connect portal. Perfect for business users, marketers, and anyone who prefers a UI-based approach over API integration.

Overview

The 8x8 Connect UI provides a complete visual environment for Flow management:

No coding required - Build Flows with JSON editor and live preview
Live preview - Test Flows interactively before publishing
Template integration - Create templates with Flow buttons
Campaign management - Send Flows to customer segments
Response viewing - See all submissions in a table view
Export capabilities - Download Flow JSON for version control

Prerequisites:

Access to 8x8 Connect
Active WhatsApp Channel
Appropriate user permissions

Accessing WhatsApp Flows

Steps:

Log into 8x8 Connect
Navigate to Messaging Apps > WhatsApp flows at https://connect.8x8.com/chat/flows
View existing flows with status indicators:
- Draft - Editable, not yet published
- Published - Live and available for use (immutable)
- Deprecated - No longer recommended for new messages
Use the search bar to find specific flows by name

Flow Management Actions

Click the ⋮ menu on any Flow to access:

Edit - Modify Flow JSON (Draft flows only)
Preview - Test flow experience in browser before publishing
View responses - See all customer submissions with filtering and export options
Export flow JSON - Download JSON for backup or API use
Delete - Remove flow (Draft flows only, not in use by templates)

Creating a New Flow

Step 1: Create Flow

Navigate to https://connect.8x8.com/chat/flows/create or click + Create a WhatsApp Flow button
Fill in Flow details:
- Channel ID: Select your WhatsApp Business Account
- Flow name: Descriptive name for internal reference (e.g., "Home Service Appointment Booking")
Build your Flow JSON using one of these methods:

Option A: Use Meta's Playground

Visit WhatsApp Flows Playground
Design flow visually with drag-and-drop interface
Export JSON and copy into the editor
Note: This is a one-way tool - you can export from playground to JSON, but cannot import JSON back into the playground

Option B: Use Example JSON

Browse Flow Examples for industry-specific templates
Copy JSON from the example that matches your use case
Customize field names, labels, and validation rules

Option C: Write Custom JSON

Refer to the Component Reference
Build JSON structure following WhatsApp Flows schema (version 7.3)
Use the inline editor with syntax highlighting

Live Preview: See real-time rendering on the right panel
Click Run to test the flow interactively in a mobile-sized preview

Step 2: Preview and Test

The preview interface allows you to:

See full-screen mobile preview of your Flow
Navigate through all screens as a user would
Test form validations and required fields
Verify conditional logic and navigation paths
Check data flow between screens

Testing checklist:

All screens render correctly on mobile layout
Required fields enforce validation
Navigation buttons work as expected
Terminal screen submits data properly
All text fits in mobile view without truncation
Images and icons load correctly

Step 3: Publish Flow

Important: Once published, the Flow becomes live and cannot be edited. This is a Meta/WhatsApp restriction to ensure consistency for users.

To make changes after publishing:

Edit the existing flow (this creates a new draft version)
Copy the modified JSON
Create a new flow with the updated JSON
Publish the new version
Update your templates to reference the new Flow ID
Optionally deprecate the old version

Click Publish when you're confident the Flow is ready for production use.

Using Flows with Templates

Create Template with Flow Button

Templates allow you to initiate conversations with Flow buttons. This is the most common way to send Flows.

Navigate to Templates section in 8x8 Connect
Click Create new template
Enter template details:
- Template name: Unique identifier (lowercase, underscores, e.g., appointment_booking_v1)
- Category: Select UTILITY for transactional/service Flows (appointments, feedback, customer service) or MARKETING for promotional Flows (offers, campaigns). Choose the appropriate category to avoid template rejection.
- Language: Select primary language
Compose template body:
- Add body text describing the Flow purpose
- Optional: Use variables like {{1}} for personalization
- Optional: Add footer text for additional context
Add Flow Button:
- In Buttons section, click Add button
- Select Flow button type
- Choose your published flow from the dropdown
- Set button label (e.g., "Schedule now", "Book appointment", "Share feedback")
- Note: Maximum 25 characters for button text
Submit for WhatsApp approval
Wait for approval (typically 24-48 hours)

Template Approval Tips:

Use clear, professional language in template body
Avoid promotional content in UTILITY templates
Match button text to template content
Test with example values before submitting

Send Template via Campaign

Once your template is approved, send it to customers via Campaigns:

Select Channel: Navigate to Campaigns from the main menu, click "Create a new campaign", and select "Messaging Apps"
Choose Sender: Select the Subaccount and specify the WhatsApp Channel you want to send from
Add Recipients: Upload your customer list. You can:
- Upload a file (.csv, .txt, .xlsx) containing phone numbers and data for personalization
- Manually type in numbers
- Select contacts from your saved Contact Groups
Map Fields: If you upload a file, map your columns to system fields (like Mobile) or custom fields (like FirstName) that can be used as variables
Compose Message:
- Select your approved WhatsApp Template with Flow button from the list
- Variable Mapping: If your template has variables (e.g., {{1}}), map them to the custom fields from your uploaded file (e.g., map {{1}} to your FirstName column)
- Media Replacement: If your template includes a media header (image, video, document), you can specify the media to be used by providing a publicly accessible Media URL or using the direct file upload option
- Media Optimization: All media is automatically processed and optimized by Meta's media hosting for fast, reliable delivery
Review and Send: Name your campaign, review the details, and choose to send it immediately or schedule it for a later time

Campaign Best Practices:

Segment audiences for relevant flows (don't send all flows to everyone)
Schedule sends during business hours (higher completion rates)
A/B test different template body copy and button labels
Monitor completion rates in webhook analytics

Viewing and Managing Responses

Viewing Responses in 8x8 Connect

You can view all Flow submissions directly in the 8x8 Connect portal without setting up webhooks.

Important: Permission Required

Flow responses are only visible to users with log access permission in 8x8 Connect. Without this permission, response data will be masked and not visible. Contact your account administrator to request log access if needed.

To view Flow responses:

Navigate to Messaging Apps > WhatsApp flows at https://connect.8x8.com/chat/flows
Click on the Flow name to open its details
Click View responses or navigate to the responses tab
View submission data in a table format

Default Columns (Always Present):

Date Submitted: Timestamp when the user completed the Flow
Phone Number: Customer's WhatsApp number

Dynamic Columns (Based on Your Flow): The table also displays columns for each field collected in your Flow. For example:

If your Flow collects "Name", "Email", "Preferred Date" - these will appear as columns
If your Flow collects "Order Number", "Return Reason", "Resolution Type" - these will appear as columns
Column names match the field names defined in your Flow JSON

Additional Column:

Action: Click View details to see the complete submission with all form fields

Features:

Filter responses by date range and channel
Export responses to CSV for analysis (first 1,000 responses displayed in UI, use Export button to download all responses)
View details for individual submissions to see complete form data

Use Cases:

Manual review of customer submissions
Quality assurance and testing
Data analysis and reporting without code
Customer support lookups
Export data for offline analysis or integration with other tools

Configuring Webhooks for Automated Processing

While the portal provides manual response viewing, webhooks enable automated processing and integration with your systems.

Webhook Setup

In 8x8 Connect, navigate to Messaging Apps > Webhooks
Click Add webhook endpoint
Enter your endpoint URL (must be HTTPS)
Select event types:
- inbound_message_received (required for Flow submissions)
- Optionally select other events (delivery status, etc.)
Save configuration

Webhook Requirements:

Must respond with 200 OK within 5 seconds
Must use HTTPS (not HTTP)
Must handle duplicate submissions (idempotency)
Should process asynchronously after acknowledgment

For complete webhook setup and submission handling: WhatsApp Webhooks Documentation

For webhook payload structure and processing code: API Reference - Webhook Integration

Testing Your Flows

Testing Checklist

Complete these steps to validate your Flow implementation:

Preview Flow: Open preview and test all screens and field validations
Test All Paths: Verify all navigation branches and conditional logic
Validate Required Fields: Confirm required field enforcement works
Test Validation Rules: Try invalid inputs (bad email, negative numbers)
Create Test Template: Create template with Flow button and submit for approval
Send to Test Number: Send Flow to your test WhatsApp number
Complete Flow: Fill out all fields and submit as a user would
Verify Portal Response: Check responses appear in 8x8 Connect portal
Verify Webhook (if configured): Confirm webhook receives nfmReply payload
Parse Data: Verify all submitted fields parse correctly from responseJson
Check Logs: Review 8x8 Connect portal logs for delivery status
Send Confirmation: Test automated response after submission
Test Error Cases: Verify webhook handles malformed submissions gracefully

Common Validation Errors

Error	Cause	Solution
`Invalid flowJson`	JSON not properly formatted or has syntax errors	Validate JSON structure; use online JSON validator before uploading
`Screen not found`	Navigation references non-existent screen ID	Check all screen IDs in routing match actual screen definitions
`Flow not published`	Attempting to send unpublished Flow	Publish Flow before sending; verify status is `PUBLISHED`
`Invalid flowId`	Wrong Flow ID or Flow deleted	Verify Flow ID from Flow list; check Flow wasn't accidentally deleted
`Button not visible`	Template not approved or button misconfigured	Check template approval status; verify button type is `FLOW`
`Cannot open Flow`	Flow deprecated or incorrect version	Ensure Flow status is `PUBLISHED`, not `DRAFT` or `DEPRECATED`

Testing with Preview

The preview interface is your primary testing tool:

Create or update your Flow in 8x8 Connect
Click Preview from the Flow actions menu
Interact with the Flow in the browser preview
Test all screens, navigation paths, and data entry
Verify submission payload structure (shown at the end)

Tip: Keep the preview open while iterating on your Flow JSON. Make edits, click Run to see changes immediately.

Troubleshooting

Common Issues

Symptom	Likely Cause	Solution
Flow button not visible in WhatsApp	Template not approved or button misconfigured	Verify template approval status in 8x8 Connect; check button definition matches Flow button syntax
Cannot open Flow when clicked	Flow not published or incorrect `flowId`	Publish Flow; verify `flowId` in template matches published Flow
Interactive message rejected	Sent outside 24-hour service window	Use Template message to re-open conversation window
Flow edit button disabled	Flow is published (immutable)	Create new Flow with modified JSON; update templates to new Flow ID
No responses showing in portal	Missing log access permission	Request log access permission from administrator
Preview shows old version	Browser cache or cached preview	Clear browser cache; refresh preview

Debugging Tips

1. Use Preview Extensively

Test every change in the preview before publishing. The preview shows exactly how users will see the Flow.

2. Check Flow Status

Verify Flow is in expected state:

Navigate to Messaging Apps > WhatsApp flows at https://connect.8x8.com/chat/flows
Confirm status shows Published (not Draft)
Check created/updated timestamps

3. Review Portal Logs

8x8 Connect provides detailed message logs:

Navigate to Logs in the portal
Filter by Channel ID and date range
Look for Flow message delivery status and errors

4. Test with Simple Flow First

Start with a minimal single-screen Flow before building complex multi-screen flows.

5. Verify Template Approval

Check template status in Templates section
Ensure Flow button is configured correctly
Confirm Flow ID matches published Flow

Next Steps

Continue Learning

Flow Component Reference - Learn about all available UI components
Flow Examples - See production-ready industry-specific examples
Best Practices & Governance - Design guidelines and security

For Developers

Flow API Reference - Programmatic Flow management
WhatsApp Webhooks - Complete webhook integration guide

Related Features

Template Message API - Send templates programmatically
8x8 Automation Builder - Combine Flows with conversational workflows

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-ui-guide · 8x8 CPaaS Developer Docs. Synced for support deflection.

Sales & Marketing Flow Examples

CPaaS Lead Generation

CPaaS Lead Generation Flow

Business Value: Capture qualified leads with structured data, showcase product features, enable multi-select interest tracking, and route leads to sales teams based on company size and use case.

Scenario: A potential customer is interested in a CPaaS (Communications Platform as a Service) solution. Instead of filling out a generic contact form, they complete a WhatsApp Flow that presents product features, collects company details, captures specific use case interests, and schedules a personalized demo. The system qualifies leads and routes to appropriate sales representatives.

Tools Used: Flow Configuration API + Messaging API + CRM integration + Demo scheduling system

Step 1: Create the Flow

Click to view Flow JSON Definition

This Flow showcases product features, collects company information, and schedules demos across 4 screens.

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows

{
"name":"CPaaS Lead Generation & Demo Booking",
"categories":["OTHER"],
"flowJson":"{\"version\":\"7.2\",\"routing_model\":{\"PRODUCT_SHOWCASE\":[\"COMPANY_INFO\"],\"COMPANY_INFO\":[\"USE_CASES\"],\"USE_CASES\":[\"SCHEDULE_DEMO\"],\"SCHEDULE_DEMO\":[]},\"screens\":[{\"id\":\"PRODUCT_SHOWCASE\",\"title\":\"8x8 Connect CPaaS\",\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Build powerful communication experiences\"},{\"type\":\"TextBody\",\"text\":\"8x8 Connect provides enterprise-grade APIs for SMS, WhatsApp, voice, and more. Trusted by thousands of businesses worldwide.\"},{\"type\":\"Form\",\"name\":\"product_form\",\"children\":[{\"type\":\"CheckboxGroup\",\"name\":\"interested_channels\",\"label\":\"Which channels interest you?\",\"required\":true,\"data-source\":[{\"id\":\"whatsapp\",\"title\":\"WhatsApp Business\",\"description\":\"Rich messaging with 2B+ users\"},{\"id\":\"sms\",\"title\":\"SMS\",\"description\":\"Global reach, 98% open rate\"},{\"id\":\"voice\",\"title\":\"Voice & SIP\",\"description\":\"Programmable voice calls\"},{\"id\":\"verify\",\"title\":\"Verification\",\"description\":\"OTP & 2FA authentication\"}]},{\"type\":\"RadioButtonsGroup\",\"name\":\"implementation_timeline\",\"label\":\"When do you plan to implement?\",\"required\":true,\"data-source\":[{\"id\":\"immediate\",\"title\":\"Immediately (0-30 days)\"},{\"id\":\"short_term\",\"title\":\"1-3 months\"},{\"id\":\"long_term\",\"title\":\"3-6 months\"},{\"id\":\"exploring\",\"title\":\"Just exploring\"}]},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"COMPANY_INFO\"},\"payload\":{\"interested_channels\":\"${form.interested_channels}\",\"implementation_timeline\":\"${form.implementation_timeline}\"}}}]}]}},{\"id\":\"COMPANY_INFO\",\"title\":\"Company Details\",\"data\":{\"interested_channels\":{\"type\":\"array\",\"items\":{\"type\":\"string\"},\"__example__\":[\"whatsapp\",\"sms\"]},\"implementation_timeline\":{\"type\":\"string\",\"__example__\":\"immediate\"}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Tell us about your company\"},{\"type\":\"Form\",\"name\":\"company_form\",\"children\":[{\"type\":\"TextInput\",\"name\":\"company_name\",\"label\":\"Company Name\",\"input-type\":\"text\",\"required\":true},{\"type\":\"TextInput\",\"name\":\"website\",\"label\":\"Company Website\",\"input-type\":\"text\",\"required\":false,\"helper-text\":\"Optional\"},{\"type\":\"Dropdown\",\"name\":\"company_size\",\"label\":\"Company Size\",\"required\":true,\"data-source\":[{\"id\":\"1-10\",\"title\":\"1-10 employees\"},{\"id\":\"11-50\",\"title\":\"11-50 employees\"},{\"id\":\"51-200\",\"title\":\"51-200 employees\"},{\"id\":\"201-500\",\"title\":\"201-500 employees\"},{\"id\":\"500+\",\"title\":\"500+ employees\"}]},{\"type\":\"Dropdown\",\"name\":\"industry\",\"label\":\"Industry\",\"required\":true,\"data-source\":[{\"id\":\"ecommerce\",\"title\":\"eCommerce/Retail\"},{\"id\":\"fintech\",\"title\":\"Financial Services/Fintech\"},{\"id\":\"healthcare\",\"title\":\"Healthcare\"},{\"id\":\"logistics\",\"title\":\"Logistics/Delivery\"},{\"id\":\"saas\",\"title\":\"SaaS/Technology\"},{\"id\":\"other\",\"title\":\"Other\"}]},{\"type\":\"TextInput\",\"name\":\"contact_name\",\"label\":\"Your Name\",\"input-type\":\"text\",\"required\":true},{\"type\":\"TextInput\",\"name\":\"job_title\",\"label\":\"Job Title\",\"input-type\":\"text\",\"required\":true},{\"type\":\"TextInput\",\"name\":\"email\",\"label\":\"Business Email\",\"input-type\":\"email\",\"required\":true},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"USE_CASES\"},\"payload\":{\"interested_channels\":\"${data.interested_channels}\",\"implementation_timeline\":\"${data.implementation_timeline}\",\"company_name\":\"${form.company_name}\",\"website\":\"${form.website}\",\"company_size\":\"${form.company_size}\",\"industry\":\"${form.industry}\",\"contact_name\":\"${form.contact_name}\",\"job_title\":\"${form.job_title}\",\"email\":\"${form.email}\"}}}]}]}},{\"id\":\"USE_CASES\",\"title\":\"Your Use Cases\",\"data\":{\"interested_channels\":{\"type\":\"array\",\"items\":{\"type\":\"string\"},\"__example__\":[\"whatsapp\",\"sms\"]},\"implementation_timeline\":{\"type\":\"string\",\"__example__\":\"immediate\"},\"company_name\":{\"type\":\"string\",\"__example__\":\"TechCorp\"},\"website\":{\"type\":\"string\",\"__example__\":\"techcorp.com\"},\"company_size\":{\"type\":\"string\",\"__example__\":\"51-200\"},\"industry\":{\"type\":\"string\",\"__example__\":\"saas\"},\"contact_name\":{\"type\":\"string\",\"__example__\":\"Sarah Johnson\"},\"job_title\":{\"type\":\"string\",\"__example__\":\"CTO\"},\"email\":{\"type\":\"string\",\"__example__\":\"sarah@techcorp.com\"}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"What are your main use cases?\"},{\"type\":\"TextBody\",\"text\":\"Select all that apply. This helps us tailor the demo to your needs.\"},{\"type\":\"Form\",\"name\":\"usecase_form\",\"children\":[{\"type\":\"CheckboxGroup\",\"name\":\"use_cases\",\"label\":\"Primary Use Cases\",\"required\":true,\"data-source\":[{\"id\":\"marketing\",\"title\":\"Marketing & Campaigns\",\"description\":\"Promotional messaging, drip campaigns\"},{\"id\":\"transactional\",\"title\":\"Transactional Messages\",\"description\":\"Order updates, confirmations, receipts\"},{\"id\":\"support\",\"title\":\"Customer Support\",\"description\":\"Service tickets, FAQs, chatbot\"},{\"id\":\"notifications\",\"title\":\"Notifications & Alerts\",\"description\":\"Reminders, status updates, alerts\"},{\"id\":\"authentication\",\"title\":\"Authentication\",\"description\":\"OTP, 2FA, login verification\"},{\"id\":\"conversational\",\"title\":\"Conversational Commerce\",\"description\":\"In-chat shopping, bookings, payments\"}]},{\"type\":\"Dropdown\",\"name\":\"monthly_volume\",\"label\":\"Expected Monthly Message Volume\",\"required\":true,\"data-source\":[{\"id\":\"0-10k\",\"title\":\"0 - 10,000\"},{\"id\":\"10k-50k\",\"title\":\"10,000 - 50,000\"},{\"id\":\"50k-100k\",\"title\":\"50,000 - 100,000\"},{\"id\":\"100k-500k\",\"title\":\"100,000 - 500,000\"},{\"id\":\"500k+\",\"title\":\"500,000+\"}]},{\"type\":\"TextArea\",\"name\":\"additional_requirements\",\"label\":\"Additional Requirements\",\"required\":false,\"max-length\":400,\"helper-text\":\"Any specific features or integrations you need?\"},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"SCHEDULE_DEMO\"},\"payload\":{\"interested_channels\":\"${data.interested_channels}\",\"implementation_timeline\":\"${data.implementation_timeline}\",\"company_name\":\"${data.company_name}\",\"website\":\"${data.website}\",\"company_size\":\"${data.company_size}\",\"industry\":\"${data.industry}\",\"contact_name\":\"${data.contact_name}\",\"job_title\":\"${data.job_title}\",\"email\":\"${data.email}\",\"use_cases\":\"${form.use_cases}\",\"monthly_volume\":\"${form.monthly_volume}\",\"additional_requirements\":\"${form.additional_requirements}\"}}}]}]}},{\"id\":\"SCHEDULE_DEMO\",\"title\":\"Schedule Demo\",\"terminal\":true,\"data\":{\"interested_channels\":{\"type\":\"array\",\"items\":{\"type\":\"string\"},\"__example__\":[\"whatsapp\",\"sms\"]},\"implementation_timeline\":{\"type\":\"string\",\"__example__\":\"immediate\"},\"company_name\":{\"type\":\"string\",\"__example__\":\"TechCorp\"},\"website\":{\"type\":\"string\",\"__example__\":\"techcorp.com\"},\"company_size\":{\"type\":\"string\",\"__example__\":\"51-200\"},\"industry\":{\"type\":\"string\",\"__example__\":\"saas\"},\"contact_name\":{\"type\":\"string\",\"__example__\":\"Sarah Johnson\"},\"job_title\":{\"type\":\"string\",\"__example__\":\"CTO\"},\"email\":{\"type\":\"string\",\"__example__\":\"sarah@techcorp.com\"},\"use_cases\":{\"type\":\"array\",\"items\":{\"type\":\"string\"},\"__example__\":[\"marketing\",\"transactional\",\"support\"]},\"monthly_volume\":{\"type\":\"string\",\"__example__\":\"50k-100k\"},\"additional_requirements\":{\"type\":\"string\",\"__example__\":\"Need Salesforce integration\"}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Book Your Personalized Demo\"},{\"type\":\"TextBody\",\"text\":\"Choose a time that works for you. Our solution engineer will prepare a custom demo based on your use cases.\"},{\"type\":\"Form\",\"name\":\"demo_form\",\"children\":[{\"type\":\"DatePicker\",\"name\":\"demo_date\",\"label\":\"Preferred Date\",\"required\":true,\"min-date\":\"2026-02-10\",\"max-date\":\"2026-03-10\",\"helper-text\":\"We'll confirm availability within 1 hour\"},{\"type\":\"Dropdown\",\"name\":\"demo_time\",\"label\":\"Preferred Time (Pacific Time)\",\"required\":true,\"data-source\":[{\"id\":\"0900\",\"title\":\"9:00 AM\"},{\"id\":\"1000\",\"title\":\"10:00 AM\"},{\"id\":\"1100\",\"title\":\"11:00 AM\"},{\"id\":\"1300\",\"title\":\"1:00 PM\"},{\"id\":\"1400\",\"title\":\"2:00 PM\"},{\"id\":\"1500\",\"title\":\"3:00 PM\"},{\"id\":\"1600\",\"title\":\"4:00 PM\"}]},{\"type\":\"Dropdown\",\"name\":\"demo_duration\",\"label\":\"Preferred Duration\",\"required\":true,\"data-source\":[{\"id\":\"30\",\"title\":\"30 minutes\"},{\"id\":\"60\",\"title\":\"1 hour\"}]},{\"type\":\"CheckboxGroup\",\"name\":\"demo_topics\",\"label\":\"Focus Areas for Demo\",\"required\":false,\"data-source\":[{\"id\":\"api_overview\",\"title\":\"API Overview & Capabilities\"},{\"id\":\"integration\",\"title\":\"Integration & Technical Setup\"},{\"id\":\"pricing\",\"title\":\"Pricing & ROI\"},{\"id\":\"compliance\",\"title\":\"Compliance & Security\"}]},{\"type\":\"RadioButtonsGroup\",\"name\":\"how_heard\",\"label\":\"How did you hear about us?\",\"required\":false,\"data-source\":[{\"id\":\"search\",\"title\":\"Google Search\"},{\"id\":\"referral\",\"title\":\"Referral\"},{\"id\":\"event\",\"title\":\"Event/Conference\"},{\"id\":\"social\",\"title\":\"Social Media\"},{\"id\":\"other\",\"title\":\"Other\"}]},{\"type\":\"Footer\",\"label\":\"Book Demo\",\"on-click-action\":{\"name\":\"complete\",\"payload\":{\"interested_channels\":\"${data.interested_channels}\",\"implementation_timeline\":\"${data.implementation_timeline}\",\"company_name\":\"${data.company_name}\",\"website\":\"${data.website}\",\"company_size\":\"${data.company_size}\",\"industry\":\"${data.industry}\",\"contact_name\":\"${data.contact_name}\",\"job_title\":\"${data.job_title}\",\"email\":\"${data.email}\",\"use_cases\":\"${data.use_cases}\",\"monthly_volume\":\"${data.monthly_volume}\",\"additional_requirements\":\"${data.additional_requirements}\",\"demo_date\":\"${form.demo_date}\",\"demo_time\":\"${form.demo_time}\",\"demo_duration\":\"${form.demo_duration}\",\"demo_topics\":\"${form.demo_topics}\",\"how_heard\":\"${form.how_heard}\"}}}]}]}}]}"
}

Response:

{
"id":"cpaas_lead_gen_flow_999",
"success":true
}

Step 2: Publish the Flow

Click to view Publish Flow Request

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows/cpaas_lead_gen_flow_999/publish

Response: 200 OK (no response body)

Step 3: Send the Flow (Interactive Message)

Click to view Send Interactive Flow Message

Endpoint: POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages

{
"user":{
"msisdn":"+15551234567"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"flow",
"header":{
"type":"text",
"text":"Explore 8x8 Connect CPaaS"
},
"body":{
"text":"Build powerful communication experiences with enterprise-grade WhatsApp, SMS, Voice, and Verification APIs. Trusted by thousands of businesses worldwide.\n\nBook a personalized demo to see how we can power your use case."
},
"action":{
"parameters":{
"flowId":"cpaas_lead_gen_flow_999",
"flowCta":"Get Started"
}
},
"footer":{
"text":"Free demo • No commitment"
}
}
}
}

Step 4: Handle the Submission

Click to view Webhook Payload (Flow Submission)

{
"namespace":"ChatApps",
"eventType":"inbound_message_received",
"payload":{
"umid":"lead-xyz-999",
"subAccountId":"your-subaccount-id",
"timestamp":"2026-02-10T16:00:00.000Z",
"user":{
"msisdn":"+15551234567",
"channelUserId":"15551234567"
},
"recipient":{
"channel":"whatsapp",
"channelId":"your-channel-id"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"nfmReply",
"nfmReply":{
"responseJson":"{\"interested_channels\":[\"whatsapp\",\"sms\",\"verify\"],\"implementation_timeline\":\"immediate\",\"company_name\":\"RetailCo\",\"website\":\"retailco.com\",\"company_size\":\"201-500\",\"industry\":\"ecommerce\",\"contact_name\":\"Michael Chen\",\"job_title\":\"VP of Engineering\",\"email\":\"michael@retailco.com\",\"use_cases\":[\"transactional\",\"notifications\",\"authentication\"],\"monthly_volume\":\"100k-500k\",\"additional_requirements\":\"Need Shopify integration and multi-region support\",\"demo_date\":\"2026-02-14\",\"demo_time\":\"1400\",\"demo_duration\":\"60\",\"demo_topics\":[\"api_overview\",\"integration\",\"compliance\"],\"how_heard\":\"referral\",\"flow_token\":\"<TOKEN>\"}"
}
}
}
}
}

Processing the Submission:

// Parse the Flow submission
const data =JSON.parse(payload.content.interactive.nfmReply.responseJson);
// Calculate lead score based on qualification criteria
const leadScore =calculateLeadScore({
companySize: data.company_size,
monthlyVolume: data.monthly_volume,
implementationTimeline: data.implementation_timeline,
industry: data.industry,
useCaseCount: data.use_cases.length
});
// Determine lead quality tier
let leadTier ='cold';
if(leadScore >=80) leadTier ='hot';
elseif(leadScore >=60) leadTier ='warm';
// Assign to sales rep based on territory, company size, and industry
const assignedSalesRep =awaitassignLeadToSalesRep({
companySize: data.company_size,
industry: data.industry,
monthlyVolume: data.monthly_volume,
leadScore: leadScore
});
// Create lead in CRM (Salesforce, HubSpot, etc.)
const crmLead =awaitcreateCRMLead({
// Contact Info
firstName: data.contact_name.split(' ')[0],
lastName: data.contact_name.split(' ').slice(1).join(' '),
email: data.email,
phone: payload.user.msisdn,
jobTitle: data.job_title,
// Company Info
companyName: data.company_name,
website: data.website,
companySize: data.company_size,
industry: data.industry,
// Qualification Data
interestedChannels: data.interested_channels,
useCases: data.use_cases,
monthlyVolume: data.monthly_volume,
implementationTimeline: data.implementation_timeline,
additionalRequirements: data.additional_requirements,
// Demo Preferences
requestedDemoDate: data.demo_date,
requestedDemoTime: data.demo_time,
demoDuration: data.demo_duration,
demoTopics: data.demo_topics||[],
// Lead Metadata
leadSource:'whatsapp_flow',
leadTier: leadTier,
leadScore: leadScore,
howHeard: data.how_heard,
assignedTo: assignedSalesRep.id,
createdAt:newDate()
});
// Check demo slot availability
const demoAvailable =awaitcheckDemoSlotAvailability({
salesRepId: assignedSalesRep.id,
requestedDate: data.demo_date,
requestedTime: data.demo_time,
duration: data.demo_duration
});
let demoConfirmed =false;
let confirmedDateTime =null;
if(demoAvailable){
// Book the demo
const demo =awaitbookDemo({
leadId: crmLead.id,
salesRepId: assignedSalesRep.id,
date: data.demo_date,
time: data.demo_time,
duration: data.demo_duration,
topics: data.demo_topics,
customerEmail: data.email,
customerPhone: payload.user.msisdn,
companyName: data.company_name,
useCases: data.use_cases,
requirements: data.additional_requirements
});
  demoConfirmed =true;
  confirmedDateTime =`${data.demo_date} at ${formatTime(data.demo_time)} PT`;
// Send calendar invite
awaitsendCalendarInvite({
to: data.email,
subject:`8x8 Connect Demo - ${data.company_name}`,
date: data.demo_date,
time: data.demo_time,
duration: data.demo_duration,
attendees:[data.email, assignedSalesRep.email],
meetingLink: demo.videoCallLink,
description:`Personalized demo of 8x8 Connect CPaaS\n\nFocus areas:\n${data.use_cases.join(', ')}\n\nYour Solution Engineer: ${assignedSalesRep.name}`
});
}else{
// Requested time not available - sales rep will reach out
awaitnotifySalesRepForManualScheduling({
salesRepId: assignedSalesRep.id,
leadId: crmLead.id,
requestedDate: data.demo_date,
requestedTime: data.demo_time,
contactName: data.contact_name,
contactEmail: data.email,
contactPhone: payload.user.msisdn
});
}
// Send confirmation message to lead
let confirmationMsg =`Thank you, ${data.contact_name}! 🎉\n\n`;
if(demoConfirmed){
  confirmationMsg +=`Your demo is confirmed for ${confirmedDateTime}.\n\n`;
  confirmationMsg +=`📧 Calendar invite sent to ${data.email}\n`;
  confirmationMsg +=`👤 Your Solution Engineer: ${assignedSalesRep.name}\n\n`;
  confirmationMsg +=`Demo Focus:\n`;
  confirmationMsg += data.use_cases.map(uc=>`• ${formatUseCase(uc)}`).join('\n');
  confirmationMsg +=`\n\nWe'll prepare a custom demo showcasing how 8x8 Connect can power your ${data.industry} use cases with ${data.monthly_volume} monthly messages.`;
}else{
  confirmationMsg +=`We've received your demo request for ${data.demo_date}.\n\n`;
  confirmationMsg +=`${assignedSalesRep.name} from our sales team will contact you within 1 hour to confirm the best time.\n\n`;
  confirmationMsg +=`📧 ${assignedSalesRep.email}\n`;
  confirmationMsg +=`📞 ${assignedSalesRep.phone}`;
}
confirmationMsg +=`\n\nIn the meantime, explore our documentation: developer.8x8.com\n\nQuestions? Reply here anytime.`;
awaitsendMessage(payload.user.msisdn,{
type:'text',
content:{text: confirmationMsg }
});
// Send internal notification to sales rep
awaitnotifySalesRep({
salesRepId: assignedSalesRep.id,
notification:{
type:'new_hot_lead',
leadId: crmLead.id,
leadTier: leadTier,
leadScore: leadScore,
companyName: data.company_name,
contactName: data.contact_name,
interestedChannels: data.interested_channels,
implementationTimeline: data.implementation_timeline,
monthlyVolume: data.monthly_volume,
demoScheduled: demoConfirmed,
demoDateTime: confirmedDateTime,
priority: leadScore >=80?'high':'medium'
}
});
// Trigger marketing automation workflows
awaittriggerMarketingAutomation({
leadId: crmLead.id,
email: data.email,
workflows:[
{type:'welcome_series',delay:'1_hour'},
{type:'technical_resources',condition:'if_demo_scheduled'},
{type:'case_studies',filter:`industry_${data.industry}`}
]
});
// Log for sales analytics
awaitlogLeadCapture({
leadId: crmLead.id,
source:'whatsapp_flow',
leadTier: leadTier,
leadScore: leadScore,
companySize: data.company_size,
industry: data.industry,
interestedChannels: data.interested_channels,
useCases: data.use_cases,
monthlyVolume: data.monthly_volume,
implementationTimeline: data.implementation_timeline,
demoScheduled: demoConfirmed,
assignedSalesRep: assignedSalesRep.id,
createdAt:newDate()
});

Helper Functions:

functioncalculateLeadScore(criteria){
let score =0;
// Company size scoring
const sizeScores ={
'1-10':10,
'11-50':20,
'51-200':40,
'201-500':60,
'500+':80
};
  score += sizeScores[criteria.companySize]||0;
// Volume scoring
const volumeScores ={
'0-10k':5,
'10k-50k':15,
'50k-100k':25,
'100k-500k':40,
'500k+':50
};
  score += volumeScores[criteria.monthlyVolume]||0;
// Timeline urgency
const timelineScores ={
'immediate':30,
'short_term':20,
'long_term':10,
'exploring':5
};
  score += timelineScores[criteria.implementationTimeline]||0;
// Multiple use cases indicate serious interest
  score +=Math.min(criteria.useCaseCount*5,20);
returnMath.min(score,100);
}
functionformatUseCase(useCaseId){
const labels ={
'marketing':'Marketing & Campaigns',
'transactional':'Transactional Messages',
'support':'Customer Support',
'notifications':'Notifications & Alerts',
'authentication':'Authentication',
'conversational':'Conversational Commerce'
};
return labels[useCaseId]|| useCaseId;
}
functionformatTime(timeSlot){
const hour =parseInt(timeSlot.substring(0,2));
const ampm = hour >=12?'PM':'AM';
const displayHour = hour >12? hour -12: hour;
return`${displayHour}:00 ${ampm}`;
}

Best Practices:

Lead Scoring: Automatically qualify leads based on company size, volume, and timeline
Smart Routing: Assign leads to sales reps by territory, industry expertise, or account size
Product Showcase: Use CheckboxGroup to let prospects select multiple areas of interest
Qualification Data: Collect company size, industry, and use cases to personalize demos
Demo Automation: Integrate with calendaring systems (Calendly, HubSpot Meetings) for instant booking
Multi-Channel Follow-up: Send confirmation via WhatsApp + email calendar invite
CRM Integration: Sync all lead data to Salesforce, HubSpot, or Pipedrive in real-time
Marketing Automation: Trigger nurture campaigns based on lead tier and interests
Analytics: Track conversion rates by channel interest, industry, and lead source
Speed to Lead: Notify sales reps immediately for hot leads (score >= 80)

Related Resources

WhatsApp Flows in 8x8 Connect - Complete guide for creating Flows using 8x8 Connect portal
WhatsApp Flows API Reference - API documentation for programmatic Flow management
All Flow Examples - Browse examples from other industries

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-examples-sales · 8x8 CPaaS Developer Docs. Synced for support deflection.

Retail & eCommerce Flow Examples

Product Return & Exchange

Product Return & Exchange Flow

Business Value: Automate returns processing, reduce support tickets by 40%, capture structured data for quality insights, and improve customer satisfaction.

Scenario: A customer wants to return or exchange a product. Instead of calling support or filling out web forms, they complete a WhatsApp Flow that collects order details, return reason, and resolution preference. Upon submission, your system validates the order, generates a return authorization, and sends the return label.

Tools Used: Flow Configuration API + Messaging API + Webhook handler

Step 1: Create the Flow

Click to view Flow JSON Definition

This Flow collects order information, return reason, and preferred resolution across 3 screens.

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows

{
"name":"Product Return & Exchange",
"categories":["OTHER"],
"flowJson":"{\"version\":\"7.2\",\"routing_model\":{\"ORDER_INFO\":[\"RETURN_DETAILS\"],\"RETURN_DETAILS\":[\"RESOLUTION\"],\"RESOLUTION\":[]},\"screens\":[{\"id\":\"ORDER_INFO\",\"title\":\"Return Request\",\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Find Your Order\"},{\"type\":\"TextBody\",\"text\":\"Please enter the details exactly as they appear in your confirmation email.\"},{\"type\":\"Form\",\"name\":\"order_form\",\"children\":[{\"type\":\"TextInput\",\"name\":\"order_number\",\"label\":\"Order Number\",\"input-type\":\"text\",\"required\":true,\"helper-text\":\"Example: ORD-12345\"},{\"type\":\"TextInput\",\"name\":\"item_name\",\"label\":\"Item Name\",\"input-type\":\"text\",\"required\":true,\"helper-text\":\"Product name and size\"},{\"type\":\"TextInput\",\"name\":\"customer_email\",\"label\":\"Email Address\",\"input-type\":\"email\",\"required\":true},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"RETURN_DETAILS\"},\"payload\":{\"order_number\":\"${form.order_number}\",\"item_name\":\"${form.item_name}\",\"customer_email\":\"${form.customer_email}\"}}}]}]}},{\"id\":\"RETURN_DETAILS\",\"title\":\"Return Reason\",\"data\":{\"order_number\":{\"type\":\"string\",\"__example__\":\"ORD-12345\"},\"item_name\":{\"type\":\"string\",\"__example__\":\"Denim Jacket\"},\"customer_email\":{\"type\":\"string\",\"__example__\":\"user@example.com\"}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"Form\",\"name\":\"details_form\",\"children\":[{\"type\":\"RadioButtonsGroup\",\"name\":\"return_reason\",\"label\":\"Reason for Return\",\"required\":true,\"data-source\":[{\"id\":\"wrong_size\",\"title\":\"Wrong Size\"},{\"id\":\"defective\",\"title\":\"Defective/Damaged\"},{\"id\":\"not_as_described\",\"title\":\"Not As Described\"},{\"id\":\"changed_mind\",\"title\":\"Changed My Mind\"}]},{\"type\":\"TextArea\",\"name\":\"additional_details\",\"label\":\"Additional Info\",\"required\":false,\"max-length\":500,\"helper-text\":\"Please provide more details (optional)\"},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"RESOLUTION\"},\"payload\":{\"order_number\":\"${data.order_number}\",\"item_name\":\"${data.item_name}\",\"customer_email\":\"${data.customer_email}\",\"return_reason\":\"${form.return_reason}\",\"additional_details\":\"${form.additional_details}\"}}}]}]}},{\"id\":\"RESOLUTION\",\"title\":\"Resolution\",\"terminal\":true,\"data\":{\"order_number\":{\"type\":\"string\",\"__example__\":\"ORD-12345\"},\"item_name\":{\"type\":\"string\",\"__example__\":\"Denim Jacket\"},\"customer_email\":{\"type\":\"string\",\"__example__\":\"user@example.com\"},\"return_reason\":{\"type\":\"string\",\"__example__\":\"wrong_size\"},\"additional_details\":{\"type\":\"string\",\"__example__\":\"Fits too tight\"}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Select Resolution\"},{\"type\":\"TextBody\",\"text\":\"How can we make this right? Please choose your preferred resolution method below.\"},{\"type\":\"Form\",\"name\":\"resolution_form\",\"children\":[{\"type\":\"RadioButtonsGroup\",\"name\":\"resolution_type\",\"label\":\"Preferred Solution\",\"required\":true,\"data-source\":[{\"id\":\"refund\",\"title\":\"Original Refund\"},{\"id\":\"exchange\",\"title\":\"Product Exchange\"},{\"id\":\"store_credit\",\"title\":\"Store Credit (+10%)\"}]},{\"type\":\"TextInput\",\"name\":\"exchange_pref\",\"label\":\"Exchange Item\",\"required\":false,\"helper-text\":\"Specify the new size or color\"},{\"type\":\"RadioButtonsGroup\",\"name\":\"contact_method\",\"label\":\"Contact Method\",\"required\":true,\"data-source\":[{\"id\":\"whatsapp\",\"title\":\"WhatsApp\"},{\"id\":\"email\",\"title\":\"Email\"}]},{\"type\":\"Footer\",\"label\":\"Submit Return\",\"on-click-action\":{\"name\":\"complete\",\"payload\":{\"order_number\":\"${data.order_number}\",\"item_name\":\"${data.item_name}\",\"customer_email\":\"${data.customer_email}\",\"return_reason\":\"${data.return_reason}\",\"additional_details\":\"${data.additional_details}\",\"resolution_type\":\"${form.resolution_type}\",\"exchange_pref\":\"${form.exchange_pref}\",\"contact_method\":\"${form.contact_method}\"}}}]}]}}]}"
}

Response:

{
"id":"1234567890123456",
"success":true
}

Step 2: Publish the Flow

Click to view Publish Flow Request

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows/1234567890123456/publish

Response: 200 OK (no response body)

Step 3: Send the Flow (Interactive Message)

This example uses an Interactive Flow message, sent within the 24-hour customer service window after the customer initiates a return request.

Click to view Send Interactive Flow Message

Endpoint: POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages

{
"user":{
"msisdn":"+15551234567"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"flow",
"header":{
"type":"text",
"text":"Return or Exchange"
},
"body":{
"text":"We're sorry your purchase didn't work out. Let's make it right. Complete this form to start your return or exchange."
},
"action":{
"parameters":{
"flowId":"1234567890123456",
"flowCta":"Start Return"
}
},
"footer":{
"text":"Takes less than 2 minutes"
}
}
}
}

Step 4: Handle the Submission

Click to view Webhook Payload (Flow Submission)

{
"namespace":"ChatApps",
"eventType":"inbound_message_received",
"payload":{
"umid":"abc-123-def-456",
"subAccountId":"your-subaccount-id",
"timestamp":"2026-01-20T14:30:00.000Z",
"user":{
"msisdn":"+15551234567",
"channelUserId":"15551234567"
},
"recipient":{
"channel":"whatsapp",
"channelId":"your-channel-id"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"nfmReply",
"nfmReply":{
"responseJson":"{\"order_number\":\"ORD-98765\",\"item_name\":\"Blue Denim Jacket - Size M\",\"customer_email\":\"customer@example.com\",\"return_reason\":\"wrong_size\",\"additional_details\":\"Fits too small, need size L\",\"resolution_type\":\"exchange\",\"exchange_pref\":\"Same item in size L\",\"contact_method\":\"whatsapp\",\"flow_token\":\"<TOKEN>\"}"
}
}
}
}
}

Processing the Submission:

// Parse the Flow submission
const data =JSON.parse(payload.content.interactive.nfmReply.responseJson);
// Validate order exists and is eligible for return
const order =awaitvalidateOrder(data.order_number, data.customer_email);
if(!order.exists){
awaitsendMessage(payload.user.msisdn,
"We couldn't find that order. Please check your order number and try again.");
return;
}
if(!order.eligibleForReturn){
awaitsendMessage(payload.user.msisdn,
"This order is outside the 30-day return window. Please contact support for assistance.");
return;
}
// Generate return authorization
const returnAuth =awaitcreateReturnAuthorization({
orderId: order.id,
itemName: data.item_name,
reason: data.return_reason,
additionalDetails: data.additional_details,
resolutionType: data.resolution_type,
exchangePreference: data.exchange_pref,
customerEmail: data.customer_email
});
// Generate and send return shipping label
const shippingLabel =awaitgenerateShippingLabel({
returnAuthNumber: returnAuth.number,
customerAddress: order.shippingAddress
});
// Send confirmation with return label
awaitsendMessage(payload.user.msisdn,{
type:"document",
document:{
link: shippingLabel.url,
filename:`Return_Label_${returnAuth.number}.pdf`
},
caption:`Return authorized! Return #${returnAuth.number}\n\nPrint this label and attach it to your package. Drop it off at any shipping location.\n\nYou'll receive your ${data.resolution_type==='refund'?'refund':'exchange'} within 5-7 business days after we receive your return.`
});
// Log for analytics and quality tracking
awaitlogReturnRequest({
returnReason: data.return_reason,
resolutionType: data.resolution_type,
itemSku: order.itemSku,
orderDate: order.createdAt
});

Best Practices:

Validate Immediately: Check order eligibility in real-time to prevent invalid returns
Return Window: Enforce your return policy (e.g., 30 days from delivery)
Fraud Prevention: Match email/phone to original order to prevent abuse
Quality Insights: Track return reasons by product/SKU to identify quality issues
Automation: Auto-approve simple returns (wrong size), flag complex ones (defective) for review
Customer Experience: Send return label immediately, provide tracking updates

Related Resources

WhatsApp Flows in 8x8 Connect - Complete guide for creating Flows using 8x8 Connect portal
WhatsApp Flows API Reference - API documentation for programmatic Flow management
All Flow Examples - Browse examples from other industries

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-examples-retail · 8x8 CPaaS Developer Docs. Synced for support deflection.

Healthcare Flow Examples

Appointment Scheduling

Appointment Scheduling Flow

Business Value: Reduce phone volume by 50%, eliminate scheduling errors with structured data collection, improve patient intake efficiency, and enable 24/7 appointment booking.

Scenario: A patient needs to schedule a medical appointment. Instead of waiting on hold or navigating complex web forms, they complete a WhatsApp Flow that collects appointment type, provider preference, insurance information, and available time slots. The system validates insurance eligibility and confirms appointments in real-time.

Tools Used: Flow Configuration API + Messaging API + EMR/Scheduling system integration

Step 1: Create the Flow

Click to view Flow JSON Definition

This Flow collects appointment details, patient information, and insurance details across 3 screens.

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows

{
"name":"Medical Appointment Scheduling",
"categories":["OTHER"],
"flowJson":"{\"version\":\"7.2\",\"routing_model\":{\"APPOINTMENT_TYPE\":[\"PATIENT_INFO\"],\"PATIENT_INFO\":[\"SCHEDULE\"],\"SCHEDULE\":[]},\"screens\":[{\"id\":\"APPOINTMENT_TYPE\",\"title\":\"Schedule Appointment\",\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"What brings you in?\"},{\"type\":\"TextBody\",\"text\":\"Select the type of appointment you need. We'll match you with the right provider.\"},{\"type\":\"Form\",\"name\":\"appointment_form\",\"children\":[{\"type\":\"RadioButtonsGroup\",\"name\":\"appointment_type\",\"label\":\"Appointment Type\",\"required\":true,\"data-source\":[{\"id\":\"annual_checkup\",\"title\":\"Annual Checkup/Physical\"},{\"id\":\"sick_visit\",\"title\":\"Sick Visit\"},{\"id\":\"follow_up\",\"title\":\"Follow-up Appointment\"},{\"id\":\"vaccination\",\"title\":\"Vaccination\"},{\"id\":\"specialist\",\"title\":\"Specialist Consultation\"}]},{\"type\":\"Dropdown\",\"name\":\"provider_preference\",\"label\":\"Provider Preference\",\"required\":false,\"data-source\":[{\"id\":\"any\",\"title\":\"Any Available Provider\"},{\"id\":\"dr_smith\",\"title\":\"Dr. Sarah Smith (Family Medicine)\"},{\"id\":\"dr_johnson\",\"title\":\"Dr. Michael Johnson (Internal Medicine)\"},{\"id\":\"dr_patel\",\"title\":\"Dr. Priya Patel (Pediatrics)\"}]},{\"type\":\"RadioButtonsGroup\",\"name\":\"visit_reason_category\",\"label\":\"Reason for Visit\",\"required\":true,\"data-source\":[{\"id\":\"preventive\",\"title\":\"Preventive Care\"},{\"id\":\"illness\",\"title\":\"Illness/Symptoms\"},{\"id\":\"chronic\",\"title\":\"Chronic Condition Management\"},{\"id\":\"other\",\"title\":\"Other\"}]},{\"type\":\"TextArea\",\"name\":\"visit_notes\",\"label\":\"Additional Details\",\"required\":false,\"max-length\":300,\"helper-text\":\"Briefly describe your symptoms or reason (optional)\"},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"PATIENT_INFO\"},\"payload\":{\"appointment_type\":\"${form.appointment_type}\",\"provider_preference\":\"${form.provider_preference}\",\"visit_reason_category\":\"${form.visit_reason_category}\",\"visit_notes\":\"${form.visit_notes}\"}}}]}]}},{\"id\":\"PATIENT_INFO\",\"title\":\"Patient Information\",\"data\":{\"appointment_type\":{\"type\":\"string\",\"__example__\":\"sick_visit\"},\"provider_preference\":{\"type\":\"string\",\"__example__\":\"any\"},\"visit_reason_category\":{\"type\":\"string\",\"__example__\":\"illness\"},\"visit_notes\":{\"type\":\"string\",\"__example__\":\"Persistent cough for 3 days\"}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Patient Details\"},{\"type\":\"Form\",\"name\":\"patient_form\",\"children\":[{\"type\":\"TextInput\",\"name\":\"patient_first_name\",\"label\":\"First Name\",\"input-type\":\"text\",\"required\":true},{\"type\":\"TextInput\",\"name\":\"patient_last_name\",\"label\":\"Last Name\",\"input-type\":\"text\",\"required\":true},{\"type\":\"DatePicker\",\"name\":\"date_of_birth\",\"label\":\"Date of Birth\",\"required\":true,\"min-date\":\"1920-01-01\",\"max-date\":\"2026-02-10\"},{\"type\":\"TextInput\",\"name\":\"patient_email\",\"label\":\"Email\",\"input-type\":\"email\",\"required\":true,\"helper-text\":\"For appointment reminders\"},{\"type\":\"RadioButtonsGroup\",\"name\":\"insurance_status\",\"label\":\"Insurance\",\"required\":true,\"data-source\":[{\"id\":\"insured\",\"title\":\"I have insurance\"},{\"id\":\"self_pay\",\"title\":\"Self-pay/No insurance\"}]},{\"type\":\"TextInput\",\"name\":\"insurance_provider\",\"label\":\"Insurance Provider\",\"input-type\":\"text\",\"required\":false,\"helper-text\":\"e.g., Blue Cross, Aetna, UnitedHealthcare\"},{\"type\":\"TextInput\",\"name\":\"member_id\",\"label\":\"Member ID\",\"input-type\":\"text\",\"required\":false},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"SCHEDULE\"},\"payload\":{\"appointment_type\":\"${data.appointment_type}\",\"provider_preference\":\"${data.provider_preference}\",\"visit_reason_category\":\"${data.visit_reason_category}\",\"visit_notes\":\"${data.visit_notes}\",\"patient_first_name\":\"${form.patient_first_name}\",\"patient_last_name\":\"${form.patient_last_name}\",\"date_of_birth\":\"${form.date_of_birth}\",\"patient_email\":\"${form.patient_email}\",\"insurance_status\":\"${form.insurance_status}\",\"insurance_provider\":\"${form.insurance_provider}\",\"member_id\":\"${form.member_id}\"}}}]}]}},{\"id\":\"SCHEDULE\",\"title\":\"Select Time\",\"terminal\":true,\"data\":{\"appointment_type\":{\"type\":\"string\",\"__example__\":\"sick_visit\"},\"provider_preference\":{\"type\":\"string\",\"__example__\":\"any\"},\"visit_reason_category\":{\"type\":\"string\",\"__example__\":\"illness\"},\"visit_notes\":{\"type\":\"string\",\"__example__\":\"Persistent cough for 3 days\"},\"patient_first_name\":{\"type\":\"string\",\"__example__\":\"John\"},\"patient_last_name\":{\"type\":\"string\",\"__example__\":\"Doe\"},\"date_of_birth\":{\"type\":\"string\",\"__example__\":\"1985-05-15\"},\"patient_email\":{\"type\":\"string\",\"__example__\":\"john@example.com\"},\"insurance_status\":{\"type\":\"string\",\"__example__\":\"insured\"},\"insurance_provider\":{\"type\":\"string\",\"__example__\":\"Blue Cross\"},\"member_id\":{\"type\":\"string\",\"__example__\":\"BC123456789\"}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Choose Your Appointment Time\"},{\"type\":\"Form\",\"name\":\"schedule_form\",\"children\":[{\"type\":\"DatePicker\",\"name\":\"appointment_date\",\"label\":\"Preferred Date\",\"required\":true,\"min-date\":\"2026-02-10\",\"max-date\":\"2026-04-10\",\"helper-text\":\"We have appointments available within 2 weeks\"},{\"type\":\"Dropdown\",\"name\":\"time_slot\",\"label\":\"Time Slot\",\"required\":true,\"data-source\":[{\"id\":\"0800\",\"title\":\"8:00 AM\"},{\"id\":\"0900\",\"title\":\"9:00 AM\"},{\"id\":\"1000\",\"title\":\"10:00 AM\"},{\"id\":\"1100\",\"title\":\"11:00 AM\"},{\"id\":\"1300\",\"title\":\"1:00 PM\"},{\"id\":\"1400\",\"title\":\"2:00 PM\"},{\"id\":\"1500\",\"title\":\"3:00 PM\"},{\"id\":\"1600\",\"title\":\"4:00 PM\"}]},{\"type\":\"RadioButtonsGroup\",\"name\":\"visit_type\",\"label\":\"Visit Type\",\"required\":true,\"data-source\":[{\"id\":\"in_person\",\"title\":\"In-Person Visit\"},{\"id\":\"telehealth\",\"title\":\"Telehealth (Video Call)\"}]},{\"type\":\"CheckboxGroup\",\"name\":\"contact_preferences\",\"label\":\"Reminder Preferences\",\"required\":false,\"data-source\":[{\"id\":\"whatsapp\",\"title\":\"WhatsApp\",\"enabled\":true},{\"id\":\"email\",\"title\":\"Email\"},{\"id\":\"sms\",\"title\":\"SMS\"}]},{\"type\":\"Footer\",\"label\":\"Book Appointment\",\"on-click-action\":{\"name\":\"complete\",\"payload\":{\"appointment_type\":\"${data.appointment_type}\",\"provider_preference\":\"${data.provider_preference}\",\"visit_reason_category\":\"${data.visit_reason_category}\",\"visit_notes\":\"${data.visit_notes}\",\"patient_first_name\":\"${data.patient_first_name}\",\"patient_last_name\":\"${data.patient_last_name}\",\"date_of_birth\":\"${data.date_of_birth}\",\"patient_email\":\"${data.patient_email}\",\"insurance_status\":\"${data.insurance_status}\",\"insurance_provider\":\"${data.insurance_provider}\",\"member_id\":\"${data.member_id}\",\"appointment_date\":\"${form.appointment_date}\",\"time_slot\":\"${form.time_slot}\",\"visit_type\":\"${form.visit_type}\",\"contact_preferences\":\"${form.contact_preferences}\"}}}]}]}}]}"
}

Response:

{
"id":"healthcare_appt_flow_789",
"success":true
}

Step 2: Publish the Flow

Click to view Publish Flow Request

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows/healthcare_appt_flow_789/publish

Response: 200 OK (no response body)

Step 3: Send the Flow (Interactive Message)

Click to view Send Interactive Flow Message

Endpoint: POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages

{
"user":{
"msisdn":"+15551234567"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"flow",
"header":{
"type":"text",
"text":"Schedule an Appointment"
},
"body":{
"text":"Book your medical appointment in minutes. In-person and telehealth options available. Same-day appointments often available for sick visits."
},
"action":{
"parameters":{
"flowId":"healthcare_appt_flow_789",
"flowCta":"Book Now"
}
},
"footer":{
"text":"Most insurance plans accepted"
}
}
}
}

Step 4: Handle the Submission

Click to view Webhook Payload (Flow Submission)

{
"namespace":"ChatApps",
"eventType":"inbound_message_received",
"payload":{
"umid":"health-xyz-789",
"subAccountId":"your-subaccount-id",
"timestamp":"2026-02-10T14:00:00.000Z",
"user":{
"msisdn":"+15551234567",
"channelUserId":"15551234567"
},
"recipient":{
"channel":"whatsapp",
"channelId":"your-channel-id"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"nfmReply",
"nfmReply":{
"responseJson":"{\"appointment_type\":\"sick_visit\",\"provider_preference\":\"dr_smith\",\"visit_reason_category\":\"illness\",\"visit_notes\":\"Persistent cough and fever for 3 days\",\"patient_first_name\":\"Emily\",\"patient_last_name\":\"Chen\",\"date_of_birth\":\"1992-08-22\",\"patient_email\":\"emily.chen@example.com\",\"insurance_status\":\"insured\",\"insurance_provider\":\"Blue Cross Blue Shield\",\"member_id\":\"BCBS987654321\",\"appointment_date\":\"2026-02-12\",\"time_slot\":\"1000\",\"visit_type\":\"in_person\",\"contact_preferences\":[\"whatsapp\",\"email\"],\"flow_token\":\"<TOKEN>\"}"
}
}
}
}
}

Processing the Submission:

// Parse the Flow submission
const data =JSON.parse(payload.content.interactive.nfmReply.responseJson);
// Check if patient exists in EMR system
let patientRecord =awaitfindPatient({
firstName: data.patient_first_name,
lastName: data.patient_last_name,
dateOfBirth: data.date_of_birth
});
// Create new patient record if doesn't exist
if(!patientRecord){
  patientRecord =awaitcreatePatient({
firstName: data.patient_first_name,
lastName: data.patient_last_name,
dateOfBirth: data.date_of_birth,
email: data.patient_email,
phone: payload.user.msisdn,
insuranceStatus: data.insurance_status,
insuranceProvider: data.insurance_provider,
memberId: data.member_id,
contactPreferences: data.contact_preferences||['whatsapp'],
source:'whatsapp_flow'
});
}
// Verify insurance eligibility (if applicable)
let insuranceVerified =true;
let copay =0;
if(data.insurance_status==='insured'&& data.member_id){
const insuranceCheck =awaitverifyInsurance({
provider: data.insurance_provider,
memberId: data.member_id,
serviceType: data.appointment_type,
patientDOB: data.date_of_birth
});
  insuranceVerified = insuranceCheck.active;
  copay = insuranceCheck.copay||0;
if(!insuranceVerified){
awaitsendMessage(payload.user.msisdn,{
type:'text',
content:{
text:`Hi ${data.patient_first_name}, we couldn't verify your insurance (${data.insurance_provider} - ${data.member_id}).\n\nPlease call our office at (555) 123-4567 to confirm your coverage before your appointment.\n\nYou can still keep your ${data.appointment_date} at ${data.time_slot} appointment, but payment may be required at check-in.`
}
});
}
}
// Check provider availability
const providerId = data.provider_preference!=='any'
? data.provider_preference
:awaitfindAvailableProvider({
appointmentType: data.appointment_type,
date: data.appointment_date,
timeSlot: data.time_slot,
visitType: data.visit_type
});
const providerAvailable =awaitcheckProviderAvailability({
providerId: providerId,
date: data.appointment_date,
timeSlot: data.time_slot
});
if(!providerAvailable){
// Offer alternative times
const alternativeSlots =awaitgetAvailableSlots({
providerId: providerId,
appointmentType: data.appointment_type,
preferredDate: data.appointment_date,
visitType: data.visit_type,
daysAhead:14
});
awaitsendMessage(payload.user.msisdn,{
type:'text',
content:{
text:`Hi ${data.patient_first_name}, unfortunately ${data.time_slot} on ${data.appointment_date} is no longer available.\n\nAlternative times:\n${alternativeSlots.slice(0,5).map(s=>`• ${s.date} at ${s.time}`).join('\n')}\n\nWould you like one of these times? Reply with the number.`
}
});
return;
}
// Create appointment in EMR/scheduling system
const appointment =awaitcreateAppointment({
patientId: patientRecord.id,
providerId: providerId,
appointmentType: data.appointment_type,
visitReasonCategory: data.visit_reason_category,
visitNotes: data.visit_notes,
scheduledDate: data.appointment_date,
scheduledTime: data.time_slot,
visitType: data.visit_type,// in_person or telehealth
insuranceVerified: insuranceVerified,
estimatedCopay: copay,
contactPreferences: data.contact_preferences,
source:'whatsapp_flow',
status:'confirmed'
});
// Get provider details
const provider =awaitgetProviderDetails(providerId);
// Send confirmation message
const appointmentTime =formatTime(data.time_slot);// "10:00 AM"
let confirmationMsg =`✅ Appointment Confirmed!\n\n`;
confirmationMsg +=`Patient: ${data.patient_first_name}${data.patient_last_name}\n`;
confirmationMsg +=`Date: ${data.appointment_date}\n`;
confirmationMsg +=`Time: ${appointmentTime}\n`;
confirmationMsg +=`Provider: ${provider.name}\n`;
confirmationMsg +=`Type: ${data.visit_type==='in_person'?'In-Person Visit':'Telehealth (Video)'}\n`;
confirmationMsg +=`\nAppointment #${appointment.id}\n\n`;
if(data.visit_type==='in_person'){
  confirmationMsg +=`📍 Location:\nHealthCare Clinic\n123 Medical Center Dr\nSan Jose, CA 95110\n\n`;
  confirmationMsg +=`Please arrive 15 minutes early to complete check-in.`;
}else{
  confirmationMsg +=`💻 You'll receive a video call link 1 hour before your appointment.`;
}
if(insuranceVerified && copay >0){
  confirmationMsg +=`\n\nEstimated copay: $${copay}`;
}
confirmationMsg +=`\n\nNeed to reschedule or cancel? Reply to this message.`;
awaitsendMessage(payload.user.msisdn,{
type:'text',
content:{text: confirmationMsg }
});
// Schedule automated reminders
awaitscheduleReminders({
appointmentId: appointment.id,
patientPhone: payload.user.msisdn,
patientEmail: data.patient_email,
appointmentDate: data.appointment_date,
appointmentTime: data.time_slot,
contactPreferences: data.contact_preferences||['whatsapp'],
visitType: data.visit_type,
reminders:[
{timing:'24_hours_before',channels:['whatsapp','email']},
{timing:'2_hours_before',channels:['whatsapp']}
]
});
// Send intake forms if first visit
if(!patientRecord.hasCompletedIntake){
awaitsendMessage(payload.user.msisdn,{
type:'text',
content:{
text:`📋 One more step! Please complete your medical history forms before your visit:\n\n${process.env.INTAKE_FORM_URL}?patient=${patientRecord.id}\n\nThis will save time at check-in.`
}
});
}
// Log for analytics
awaitlogAppointmentBooking({
appointmentType: data.appointment_type,
visitType: data.visit_type,
providerId: providerId,
insuranceStatus: data.insurance_status,
source:'whatsapp_flow',
leadTime:calculateLeadTime(data.appointment_date),// days in advance
newPatient:!patientRecord.hasCompletedIntake,
createdAt:newDate()
});

Best Practices:

HIPAA Compliance: Ensure all patient data is encrypted in transit and at rest
Insurance Verification: Validate coverage in real-time to prevent billing issues
Smart Scheduling: Check provider availability before confirming appointments
Patient Identification: Match patients by name + DOB to avoid duplicate records
Intake Forms: Send pre-visit forms for new patients to streamline check-in
Automated Reminders: Send 24-hour and 2-hour reminders to reduce no-shows
Telehealth Setup: Send video link 1 hour before telehealth appointments with tech check instructions
Cancellation Policy: Clearly communicate 24-hour cancellation requirement
Follow-up: Send post-visit satisfaction survey and care instructions
Analytics: Track no-show rates, appointment types, and booking lead times

Related Resources

WhatsApp Flows in 8x8 Connect - Complete guide for creating Flows using 8x8 Connect portal
WhatsApp Flows API Reference - API documentation for programmatic Flow management
All Flow Examples - Browse examples from other industries

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-examples-healthcare · 8x8 CPaaS Developer Docs. Synced for support deflection.

Financial Services Flow Examples

Loan Application

Loan Application Flow

Business Value: Streamline loan application process, reduce drop-off rates, and collect comprehensive applicant information including ID verification for KYC compliance.

Scenario: A customer needs a loan and completes a WhatsApp Flow that guides them through personal information, ID verification, employment details, and loan requirements. The Flow includes conditional logic, image upload for ID verification, and a comprehensive summary screen before submission.

Tools Used: Interactive Flow (within service window) + Loan processing system integration

Step 1: Create the Flow

Multi-screen Flow with routing: Welcome → [Terms, Personal Info] → ID Verification → Employment → Loan Details → Summary

This Flow demonstrates advanced features including:

Image component with base64 encoding
OptIn component for terms agreement
EmbeddedLink navigation to Terms screen
PhotoPicker for ID card upload
Conditional fields (If component)
RichText with markdown formatting
Complex routing model with multiple paths

Click to view Flow JSON Definition

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows

{
"name":"BankSmart Loan Application",
"categories":["OTHER"],
"flowJson": "{\"version\":\"7.2\",\"routing_model\":{\"WELCOME_SCREEN\":[\"TOC_SCREEN\",\"PERSONAL_INFO_SCREEN\"],\"PERSONAL_INFO_SCREEN\":[\"ID_VERIFICATION_SCREEN\"],\"ID_VERIFICATION_SCREEN\":[\"EMPLOYMENT_INFO_SCREEN\"],\"EMPLOYMENT_INFO_SCREEN\":[\"LOAN_DETAILS_SCREEN\"],\"LOAN_DETAILS_SCREEN\":[\"SUMMARY_SCREEN\"]},\"screens\":[{\"id\":\"WELCOME_SCREEN\",\"title\":\"BankSmart Loan\",\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"Image\",\"src\":\"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
}

Response:

{
"id":"loan_app_flow_123",
"success":true
}

Step 2: Publish the Flow

Click to view Publish Flow Request

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows/loan_app_flow_123/publish

Response: 200 OK (no response body)

Step 3: Send the Flow (Interactive Message)

Click to view Send Interactive Flow Message

Endpoint: POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages

{
"user":{
"msisdn":"+15551234567"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"flow",
"header":{
"type":"text",
"text":"Apply for a Loan"
},
"body":{
"text":"Get approved in minutes. Complete your loan application with BankSmart - fast, secure, and simple."
},
"footer":{
"text":"Secure application process"
},
"action":{
"parameters":{
"flowId":"loan_app_flow_123",
"flowCta":"Apply Now"
}
}
}
}
}

Step 4: Handle the Submission

Click to view Webhook Payload and Processing Logic

Webhook Payload (Flow Submission):

{
"namespace":"ChatApps",
"eventType":"inbound_message_received",
"payload":{
"umid":"abc-123-def-456",
"subAccountId":"your-subaccount-id",
"user":{
"msisdn":"+15551234567"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"nfmReply",
"nfmReply":{
"responseJson":"{\"full_name\":\"Jane Doe\",\"email\":\"jane@example.com\",\"phone\":\"12345678\",\"dob\":\"1990-01-01\",\"id_photo\":\"base64_encoded_image_data\",\"employment_status\":\"Employed\",\"employer_name\":\"TechCorp\",\"monthly_income\":\"6000\",\"loan_amount\":\"20000\",\"loan_term\":\"5\"}"
}
}
}
}
}

Processing Logic:

app.post('/webhook',async(req, res)=>{
const payload = req.body.payload;
// Identify Flow submission
if(payload.type==='Interactive'&&
      payload.content.interactive.type==='nfmReply'){
// Parse submission
const data =JSON.parse(payload.content.interactive.nfmReply.responseJson);
// Extract ID photo (base64 encoded)
const idPhoto = data.id_photo;
// Upload ID photo to secure storage
const idPhotoUrl =awaituploadToSecureStorage(idPhoto,{
userId: payload.user.msisdn,
type:'kyc_document',
timestamp:newDate()
});
// Calculate loan eligibility
const monthlyIncome =parseFloat(data.monthly_income);
const loanAmount =parseFloat(data.loan_amount);
const loanTerm =parseInt(data.loan_term);
// Simple DTI ratio check (30% max)
const monthlyPayment = loanAmount /(loanTerm *12);
const dtiRatio = monthlyPayment / monthlyIncome;
const preliminaryApproval = dtiRatio <=0.3;
// Create loan application in system
const applicationId =awaitcreateLoanApplication({
applicantName: data.full_name,
email: data.email,
phone: data.phone,
dateOfBirth: data.dob,
idPhotoUrl: idPhotoUrl,
employmentStatus: data.employment_status,
employerName: data.employer_name,
monthlyIncome: monthlyIncome,
loanAmount: loanAmount,
loanTerm: loanTerm,
dtiRatio: dtiRatio,
preliminaryStatus: preliminaryApproval ?'approved':'pending_review',
source:'whatsapp_flow',
createdAt:newDate()
});
// Trigger KYC verification workflow
awaittriggerKYCVerification(applicationId, idPhotoUrl);
// Send confirmation message
let responseMessage ='';
if(preliminaryApproval){
      responseMessage =`Great news, ${data.full_name}! Your loan application #${applicationId} has been preliminarily approved. \\n\\nLoan Amount: Rp ${loanAmount}\\nTerm: ${loanTerm} years\\n\\nWe're verifying your documents and will contact you within 24 hours to finalize your loan.`;
}else{
      responseMessage =`Thank you, ${data.full_name}! Your loan application #${applicationId} has been received and is under review. \\n\\nLoan Amount: Rp ${loanAmount}\\nTerm: ${loanTerm} years\\n\\nOur team will contact you within 24-48 hours to discuss your options.`;
}
awaitsendMessage({
user:{msisdn: payload.user.msisdn},
type:'text',
content:{
text: responseMessage
}
});
// Send notification to loan team
awaitnotifyLoanTeam({
applicationId: applicationId,
applicantName: data.full_name,
loanAmount: loanAmount,
status: preliminaryApproval ?'pre_approved':'pending_review'
});
}
  res.status(200).send('OK');
});

Best Practices:

Security: Store ID photos and sensitive data in encrypted storage with proper access controls
KYC Compliance: Implement automated ID verification (OCR, face matching) to streamline processing
Risk Assessment: Use credit scoring APIs and DTI ratio calculations for preliminary approval
Transparency: Clearly communicate loan terms, interest rates, and repayment schedules
Follow-up: Set up automated reminders for document completion and application status updates
Fraud Detection: Cross-reference applicant information with credit bureaus and fraud databases
Customer Experience: Provide real-time application status updates via WhatsApp
Data Retention: Comply with financial regulations for document storage and retention periods

Related Resources

WhatsApp Flows in 8x8 Connect - Complete guide for creating Flows using 8x8 Connect portal
WhatsApp Flows API Reference - API documentation for programmatic Flow management
All Flow Examples - Browse examples from other industries

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-examples-financial · 8x8 CPaaS Developer Docs. Synced for support deflection.

Professional Services Flow Examples

Service Appointment Booking

Service Appointment Booking Flow

Business Value: Reduce scheduling phone calls by 60%, capture structured service requests with property details, enable skill-based technician routing, and improve first-time fix rates.

Scenario: A customer needs a plumbing, electrical, or HVAC service. Instead of making multiple phone calls, they complete a WhatsApp Flow that collects service type, property details, problem description with photo upload, and preferred appointment times. The system automatically routes to qualified technicians based on service type and availability.

Tools Used: Flow Configuration API + Messaging API + Scheduling system integration

Step 1: Create the Flow

Click to view Flow JSON Definition

This Flow collects service request details, property information, and appointment preferences across 4 screens.

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows

{
"name":"Service Appointment Booking",
"categories":["OTHER"],
"flowJson":"{\"version\":\"7.2\",\"routing_model\":{\"SERVICE_TYPE\":[\"PROPERTY_INFO\"],\"PROPERTY_INFO\":[\"PROBLEM_DETAILS\"],\"PROBLEM_DETAILS\":[\"SCHEDULE\"],\"SCHEDULE\":[]},\"screens\":[{\"id\":\"SERVICE_TYPE\",\"title\":\"Service Request\",\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"What service do you need?\"},{\"type\":\"TextBody\",\"text\":\"Select the type of service you require. Our technicians are available 7 days a week.\"},{\"type\":\"Form\",\"name\":\"service_form\",\"children\":[{\"type\":\"RadioButtonsGroup\",\"name\":\"service_type\",\"label\":\"Service Type\",\"required\":true,\"data-source\":[{\"id\":\"plumbing\",\"title\":\"Plumbing\"},{\"id\":\"electrical\",\"title\":\"Electrical\"},{\"id\":\"hvac\",\"title\":\"HVAC/Heating\"},{\"id\":\"appliance\",\"title\":\"Appliance Repair\"}]},{\"type\":\"RadioButtonsGroup\",\"name\":\"urgency\",\"label\":\"Urgency Level\",\"required\":true,\"data-source\":[{\"id\":\"emergency\",\"title\":\"Emergency (Same Day)\",\"description\":\"Water leak, no power, no heat\"},{\"id\":\"urgent\",\"title\":\"Urgent (1-2 days)\",\"description\":\"Issue needs quick attention\"},{\"id\":\"standard\",\"title\":\"Standard (3-5 days)\",\"description\":\"Routine maintenance or non-urgent\"}]},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"PROPERTY_INFO\"},\"payload\":{\"service_type\":\"${form.service_type}\",\"urgency\":\"${form.urgency}\"}}}]}]}},{\"id\":\"PROPERTY_INFO\",\"title\":\"Property Details\",\"data\":{\"service_type\":{\"type\":\"string\",\"__example__\":\"plumbing\"},\"urgency\":{\"type\":\"string\",\"__example__\":\"urgent\"}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Tell us about your property\"},{\"type\":\"Form\",\"name\":\"property_form\",\"children\":[{\"type\":\"TextInput\",\"name\":\"street_address\",\"label\":\"Street Address\",\"input-type\":\"text\",\"required\":true,\"helper-text\":\"Where should the technician visit?\"},{\"type\":\"TextInput\",\"name\":\"apt_unit\",\"label\":\"Apt/Unit Number\",\"input-type\":\"text\",\"required\":false},{\"type\":\"TextInput\",\"name\":\"city\",\"label\":\"City\",\"input-type\":\"text\",\"required\":true},{\"type\":\"TextInput\",\"name\":\"postal_code\",\"label\":\"ZIP/Postal Code\",\"input-type\":\"text\",\"required\":true},{\"type\":\"RadioButtonsGroup\",\"name\":\"property_type\",\"label\":\"Property Type\",\"required\":true,\"data-source\":[{\"id\":\"residential\",\"title\":\"Residential Home\"},{\"id\":\"apartment\",\"title\":\"Apartment/Condo\"},{\"id\":\"commercial\",\"title\":\"Commercial Property\"}]},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"PROBLEM_DETAILS\"},\"payload\":{\"service_type\":\"${data.service_type}\",\"urgency\":\"${data.urgency}\",\"street_address\":\"${form.street_address}\",\"apt_unit\":\"${form.apt_unit}\",\"city\":\"${form.city}\",\"postal_code\":\"${form.postal_code}\",\"property_type\":\"${form.property_type}\"}}}]}]}},{\"id\":\"PROBLEM_DETAILS\",\"title\":\"Problem Description\",\"data\":{\"service_type\":{\"type\":\"string\",\"__example__\":\"plumbing\"},\"urgency\":{\"type\":\"string\",\"__example__\":\"urgent\"},\"street_address\":{\"type\":\"string\",\"__example__\":\"123 Main St\"},\"apt_unit\":{\"type\":\"string\",\"__example__\":\"4B\"},\"city\":{\"type\":\"string\",\"__example__\":\"San Jose\"},\"postal_code\":{\"type\":\"string\",\"__example__\":\"95110\"},\"property_type\":{\"type\":\"string\",\"__example__\":\"apartment\"}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Describe the problem\"},{\"type\":\"TextBody\",\"text\":\"The more details you provide, the better we can prepare.\"},{\"type\":\"Form\",\"name\":\"problem_form\",\"children\":[{\"type\":\"TextArea\",\"name\":\"problem_description\",\"label\":\"What's the issue?\",\"required\":true,\"max-length\":500,\"helper-text\":\"Be specific about symptoms, location, when it started\"},{\"type\":\"PhotoPicker\",\"name\":\"problem_photo\",\"label\":\"Upload Photo (Optional)\",\"description\":\"A photo helps our technicians prepare\",\"required\":false},{\"type\":\"CheckboxGroup\",\"name\":\"access_requirements\",\"label\":\"Special Access Requirements\",\"required\":false,\"data-source\":[{\"id\":\"building_code\",\"title\":\"Building/Gate Code Required\"},{\"id\":\"contact_first\",\"title\":\"Call Before Arrival\"},{\"id\":\"pets\",\"title\":\"Pets On-Site\"}]},{\"type\":\"Footer\",\"label\":\"Continue\",\"on-click-action\":{\"name\":\"navigate\",\"next\":{\"type\":\"screen\",\"name\":\"SCHEDULE\"},\"payload\":{\"service_type\":\"${data.service_type}\",\"urgency\":\"${data.urgency}\",\"street_address\":\"${data.street_address}\",\"apt_unit\":\"${data.apt_unit}\",\"city\":\"${data.city}\",\"postal_code\":\"${data.postal_code}\",\"property_type\":\"${data.property_type}\",\"problem_description\":\"${form.problem_description}\",\"problem_photo\":\"${form.problem_photo}\",\"access_requirements\":\"${form.access_requirements}\"}}}]}]}},{\"id\":\"SCHEDULE\",\"title\":\"Schedule Appointment\",\"terminal\":true,\"data\":{\"service_type\":{\"type\":\"string\",\"__example__\":\"plumbing\"},\"urgency\":{\"type\":\"string\",\"__example__\":\"urgent\"},\"street_address\":{\"type\":\"string\",\"__example__\":\"123 Main St\"},\"apt_unit\":{\"type\":\"string\",\"__example__\":\"4B\"},\"city\":{\"type\":\"string\",\"__example__\":\"San Jose\"},\"postal_code\":{\"type\":\"string\",\"__example__\":\"95110\"},\"property_type\":{\"type\":\"string\",\"__example__\":\"apartment\"},\"problem_description\":{\"type\":\"string\",\"__example__\":\"Kitchen sink dripping constantly\"},\"problem_photo\":{\"type\":\"string\",\"__example__\":\"\"},\"access_requirements\":{\"type\":\"array\",\"items\":{\"type\":\"string\"},\"__example__\":[\"building_code\"]}},\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Preferred Appointment Time\"},{\"type\":\"Form\",\"name\":\"schedule_form\",\"children\":[{\"type\":\"DatePicker\",\"name\":\"preferred_date\",\"label\":\"Preferred Date\",\"required\":true,\"min-date\":\"2026-02-10\",\"max-date\":\"2026-03-10\",\"helper-text\":\"Select your preferred date\"},{\"type\":\"RadioButtonsGroup\",\"name\":\"time_slot\",\"label\":\"Time Preference\",\"required\":true,\"data-source\":[{\"id\":\"morning\",\"title\":\"Morning (8AM-12PM)\"},{\"id\":\"afternoon\",\"title\":\"Afternoon (12PM-4PM)\"},{\"id\":\"evening\",\"title\":\"Evening (4PM-8PM)\"}]},{\"type\":\"TextInput\",\"name\":\"contact_name\",\"label\":\"Contact Name\",\"input-type\":\"text\",\"required\":true},{\"type\":\"TextInput\",\"name\":\"contact_phone\",\"label\":\"Contact Phone\",\"input-type\":\"phone\",\"required\":true},{\"type\":\"TextInput\",\"name\":\"contact_email\",\"label\":\"Email\",\"input-type\":\"email\",\"required\":false,\"helper-text\":\"For appointment confirmation\"},{\"type\":\"Footer\",\"label\":\"Book Appointment\",\"on-click-action\":{\"name\":\"complete\",\"payload\":{\"service_type\":\"${data.service_type}\",\"urgency\":\"${data.urgency}\",\"street_address\":\"${data.street_address}\",\"apt_unit\":\"${data.apt_unit}\",\"city\":\"${data.city}\",\"postal_code\":\"${data.postal_code}\",\"property_type\":\"${data.property_type}\",\"problem_description\":\"${data.problem_description}\",\"problem_photo\":\"${data.problem_photo}\",\"access_requirements\":\"${data.access_requirements}\",\"preferred_date\":\"${form.preferred_date}\",\"time_slot\":\"${form.time_slot}\",\"contact_name\":\"${form.contact_name}\",\"contact_phone\":\"${form.contact_phone}\",\"contact_email\":\"${form.contact_email}\"}}}]}]}}]}"
}

Response:

{
"id":"service_booking_flow_456",
"success":true
}

Step 2: Publish the Flow

Click to view Publish Flow Request

Endpoint: POST https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows/service_booking_flow_456/publish

Response: 200 OK (no response body)

Step 3: Send the Flow (Interactive Message)

This example uses an Interactive Flow message, sent within the 24-hour service window.

Click to view Send Interactive Flow Message

Endpoint: POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages

{
"user":{
"msisdn":"+15551234567"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"flow",
"header":{
"type":"text",
"text":"Book a Service Call"
},
"body":{
"text":"Need plumbing, electrical, or HVAC service? Book a qualified technician in minutes. We're available 7 days a week with same-day emergency service."
},
"action":{
"parameters":{
"flowId":"service_booking_flow_456",
"flowCta":"Book Now"
}
},
"footer":{
"text":"Licensed & Insured Technicians"
}
}
}
}

Step 4: Handle the Submission

Click to view Webhook Payload (Flow Submission)

{
"namespace":"ChatApps",
"eventType":"inbound_message_received",
"payload":{
"umid":"service-abc-123",
"subAccountId":"your-subaccount-id",
"timestamp":"2026-02-10T10:30:00.000Z",
"user":{
"msisdn":"+15551234567",
"channelUserId":"15551234567"
},
"recipient":{
"channel":"whatsapp",
"channelId":"your-channel-id"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"nfmReply",
"nfmReply":{
"responseJson":"{\"service_type\":\"plumbing\",\"urgency\":\"emergency\",\"street_address\":\"456 Oak Avenue\",\"apt_unit\":\"2A\",\"city\":\"San Jose\",\"postal_code\":\"95110\",\"property_type\":\"apartment\",\"problem_description\":\"Kitchen sink pipe burst, water leaking heavily\",\"problem_photo\":\"base64_encoded_photo_data\",\"access_requirements\":[\"building_code\",\"contact_first\"],\"preferred_date\":\"2026-02-10\",\"time_slot\":\"morning\",\"contact_name\":\"Maria Garcia\",\"contact_phone\":\"+15559876543\",\"contact_email\":\"maria@example.com\",\"flow_token\":\"<TOKEN>\"}"
}
}
}
}
}

Processing the Submission:

// Parse the Flow submission
const data =JSON.parse(payload.content.interactive.nfmReply.responseJson);
// Upload problem photo to storage
let problemPhotoUrl =null;
if(data.problem_photo){
  problemPhotoUrl =awaituploadToStorage(data.problem_photo,{
folder:'service-requests',
filename:`${payload.umid}_problem.jpg`
});
}
// Determine service urgency and SLA
const slaTimes ={
emergency:4,// hours
urgent:48,// hours
standard:120// hours (5 days)
};
const slaHours = slaTimes[data.urgency]||120;
// Check technician availability for requested service type
const availableTechs =awaitfindAvailableTechnicians({
serviceType: data.service_type,
postalCode: data.postal_code,
preferredDate: data.preferred_date,
timeSlot: data.time_slot,
urgency: data.urgency
});
if(!availableTechs || availableTechs.length===0){
// No availability - offer alternative times
const alternativeTimes =awaitgetAlternativeTimeSlots({
serviceType: data.service_type,
postalCode: data.postal_code,
urgency: data.urgency
});
awaitsendMessage(payload.user.msisdn,{
type:'text',
content:{
text:`Thank you, ${data.contact_name}! Unfortunately we don't have availability for ${data.time_slot} on ${data.preferred_date}.\n\nAlternative times available:\n${alternativeTimes.map(t=>`• ${t.date}${t.slot}`).join('\n')}\n\nOur team will call you within 1 hour to schedule the best time.`
}
});
// Queue for manual scheduling
awaitqueueForManualScheduling({
requestData: data,
photoUrl: problemPhotoUrl,
customerPhone: payload.user.msisdn,
alternativeTimes: alternativeTimes
});
return;
}
// Assign best-match technician (skill-based routing)
const assignedTech =awaitassignTechnician({
technicians: availableTechs,
serviceType: data.service_type,
problemDescription: data.problem_description,
urgency: data.urgency
});
// Create service appointment in scheduling system
const appointment =awaitcreateServiceAppointment({
customerId: payload.user.msisdn,
technicianId: assignedTech.id,
serviceType: data.service_type,
urgency: data.urgency,
propertyAddress:{
street: data.street_address,
aptUnit: data.apt_unit,
city: data.city,
postalCode: data.postal_code,
type: data.property_type
},
problemDescription: data.problem_description,
problemPhotoUrl: problemPhotoUrl,
accessRequirements: data.access_requirements||[],
scheduledDate: data.preferred_date,
timeSlot: data.time_slot,
contactInfo:{
name: data.contact_name,
phone: data.contact_phone,
email: data.contact_email
},
slaDeadline:newDate(Date.now()+ slaHours *60*60*1000),
source:'whatsapp_flow'
});
// Send confirmation to customer
const confirmationMessage =`✅ Appointment Confirmed!\n\nService: ${data.service_type.toUpperCase()}\nDate: ${data.preferred_date}\nTime: ${data.time_slot}\nTechnician: ${assignedTech.name}\n\nAddress: ${data.street_address}${data.apt_unit?' '+ data.apt_unit:''}, ${data.city}\n\nAppointment #${appointment.id}\n\n${assignedTech.name} will arrive during your ${data.time_slot} window. You'll receive a notification 30 minutes before arrival.\n\nQuestions? Reply here anytime.`;
awaitsendMessage(payload.user.msisdn,{
type:'text',
content:{text: confirmationMessage }
});
// Send appointment details to technician
awaitnotifyTechnician(assignedTech.id,{
appointmentId: appointment.id,
serviceType: data.service_type,
urgency: data.urgency,
address:`${data.street_address}${data.apt_unit?' '+ data.apt_unit:''}, ${data.city}`,
problemDescription: data.problem_description,
problemPhoto: problemPhotoUrl,
accessNotes: data.access_requirements,
customerContact: data.contact_phone,
scheduledTime:`${data.preferred_date}${data.time_slot}`
});
// Log for analytics
awaitlogServiceRequest({
serviceType: data.service_type,
urgency: data.urgency,
propertyType: data.property_type,
postalCode: data.postal_code,
source:'whatsapp_flow',
assignedTechId: assignedTech.id,
createdAt:newDate()
});

Best Practices:

Skill-Based Routing: Match technicians to service type (plumber, electrician, HVAC specialist)
Geographic Optimization: Route to nearest available technician to reduce travel time
Photo Upload: Request problem photos to help technicians prepare proper tools/parts
Access Requirements: Collect building codes, parking info, pet warnings upfront
SLA Tracking: Set and monitor response time commitments based on urgency
Proactive Updates: Send "technician on the way" notifications 30 mins before arrival
First-Time Fix Rate: Use problem descriptions and photos to bring right parts
Follow-up: Send satisfaction survey 24 hours after service completion

Related Resources

WhatsApp Flows in 8x8 Connect - Complete guide for creating Flows using 8x8 Connect portal
WhatsApp Flows API Reference - API documentation for programmatic Flow management
All Flow Examples - Browse examples from other industries

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-examples-professional-services · 8x8 CPaaS Developer Docs. Synced for support deflection.

WhatsApp Flow Best Practices & Governance

Comprehensive guidelines for designing effective, secure, and compliant WhatsApp Flows. Follow these best practices to create Flows that deliver great user experiences while maintaining security and regulatory compliance.

Design Best Practices

Keep Flows Focused

Do:

Limit Flows to 3-5 screens maximum
Collect only essential data for the next action
Use clear, concise field labels
Group related fields on the same screen

Don't:

Create 10+ screen flows (users abandon long forms)
Ask for data you won't immediately use
Mix unrelated topics in one Flow
Overwhelm users with too many fields per screen

Validate Input Appropriately

Use built-in field validation to prevent errors:

Set required: true for mandatory fields
Use input-type: "email" for email fields with automatic validation
Use input-type: "number" for numeric fields
Use input-type: "phone" for phone numbers
Use Dropdown/RadioButton for constrained choices (prevents invalid input)
Set min-chars and max-chars for text length validation
Set min-date and max-date for date restrictions

Example:

{
"type":"TextInput",
"name":"email",
"label":"Email Address",
"input-type":"email",
"required":true,
"helper-text":"We'll send confirmation to this address"
}

Provide Clear Instructions

Use TextHeading and TextBody components to explain each screen's purpose
Set descriptive label attributes on all input fields
Use helper-text to provide examples or clarifications
Include footer text to guide next steps

Example:

{
"type":"TextInput",
"name":"order_number",
"label":"Order Number",
"input-type":"text",
"required":true,
"helper-text":"Example: ORD-12345"
}

Plan for Mobile

Keep text concise - Users are on small screens
Avoid long dropdown lists - Use search or radio buttons for 5+ options
Test on actual WhatsApp - Validate UX on real devices
Optimize images - Ensure images load quickly on mobile data
Use appropriate keyboards - input-type controls mobile keyboard type

Screen-by-Screen Design

Welcome Screen:

Clearly state the Flow's purpose
Set expectations (e.g., "Takes 2 minutes")
Use friendly, conversational tone
Include visual elements (Image, ImageCarousel) if appropriate

Data Collection Screens:

One topic per screen (don't mix personal info with preferences)
Progress indicators if multiple screens (e.g., "Step 2 of 4")
Default values when possible to reduce typing
Logical field ordering (name before email, email before phone)

Terminal Screen:

Summarize what will happen next
Show submitted data for review (optional)
Thank the user for their time
Set expectations for follow-up

Governance and Security

Data Collection Principles

Minimize Data Collection:

Only request data necessary for the immediate next step
Don't collect sensitive data (SSN, full credit card numbers) via Flows
Clearly state why you're requesting each field
Consider privacy implications of each field

Transparency:

Explain how you'll use submitted data
Link to privacy policy if collecting personal information
Allow users to review data before final submission (add summary screen)
Obtain explicit consent for data processing where required

Example:

{
"type":"OptIn",
"name":"privacy_consent",
"label":"I agree to the Privacy Policy",
"required":true,
"on-click-action":{
"name":"navigate",
"next":{
"type":"screen",
"name":"PRIVACY_POLICY_SCREEN"
}
}
}

Input Validation

Server-Side Validation:

Always validate Flow submissions on your backend, even though Flows have client-side validation:

functionvalidateFlowSubmission(data){
// Validate required fields exist
if(!data.email||!isValidEmail(data.email)){
thrownewError('Invalid email');
}
// Validate data types
if(typeof data.age!=='number'|| data.age<0){
thrownewError('Invalid age');
}
// Sanitize inputs before storage
const sanitized ={
email:sanitizeEmail(data.email),
feedback:sanitizeText(data.feedback),
age:parseInt(data.age)
};
return sanitized;
}

Treat Submissions as Untrusted Input:

Validate data types and formats
Sanitize before database insertion
Check for injection attacks (SQL, XSS)
Rate limit submission processing
Log suspicious submissions for review

Sensitive Data Handling

For KYC/Identity Verification:

Use PhotoPicker for ID document upload
Store images in encrypted storage with access controls
Implement automated verification (OCR, face matching) when possible
Set data retention policies compliant with regulations
Log all access to sensitive documents

Example:

// Upload ID photo to secure storage
const idPhotoUrl =awaituploadToSecureStorage(data.id_photo,{
userId: payload.user.msisdn,
type:'kyc_document',
encrypted:true,
retentionDays:90,
timestamp:newDate()
});

Never Collect via Flows:

Full credit card numbers (use payment gateways instead)
Social Security Numbers in full (use last 4 digits if needed)
Passwords or PINs
Biometric data beyond photos for ID verification
Protected health information (unless HIPAA compliant)

Compliance

Template Approval:

Templates with Flow buttons require Meta approval (typically 24-48 hours)
Choose the appropriate category to avoid template rejection:
- UTILITY - For transactional/service Flows (data collection, appointments, customer service, feedback)
- MARKETING - For promotional Flows (offers, campaigns, product announcements)
- AUTHENTICATION - For OTP and verification (special requirements)
See Template Categories for complete guidelines

User Consent:

Ensure users opted in to receive messages
Respect opt-out requests immediately
Maintain opt-in records for compliance audits
Provide easy opt-out mechanism in every message

Data Retention:

Store Flow submissions according to your privacy policy
Implement data deletion on user request (GDPR right to deletion)
Comply with GDPR, CCPA, and local regulations
Document data flows for compliance reporting
Set retention periods and automated deletion

GDPR Considerations:

Obtain explicit consent for data processing
Provide clear privacy notices
Allow users to access their data
Enable data portability
Implement right to be forgotten

Testing and Quality Assurance

Testing Checklist

Before launching a Flow to production:

Preview Testing
- All screens render correctly on mobile layout
- Navigation works as expected (forward and back)
- Conditional logic behaves correctly
- Required fields are enforced
- Field validation works (email, phone, date formats)
End-to-End Testing
- Create test template with Flow button
- Send to test WhatsApp numbers
- Complete Flow with valid data
- Complete Flow with invalid/edge case data
- Verify webhook receives correct payload
- Confirm data parsing works correctly
User Experience Testing
- Text fits on mobile screens without truncation
- Images load quickly
- Helper text is clear and helpful
- Error messages are understandable
- Overall completion time is reasonable (< 5 minutes)
Integration Testing
- Webhook processes submissions successfully
- Data saves to CRM/database correctly
- Confirmation messages send to users
- Error handling works gracefully
- Duplicate submissions are handled (idempotency)
Security Testing
- Input validation catches malicious input
- SQL injection attempts are blocked
- XSS attempts are sanitized
- Rate limiting works
- Sensitive data is encrypted in transit and at rest

Common Issues and Solutions

Issue	Likely Cause	Solution
High abandonment rate	Too long, confusing navigation	Reduce screens, simplify language, add progress indicators
Invalid data submissions	Weak validation, unclear instructions	Add field validation, improve helper-text, use constrained inputs
Webhook timeouts	Slow processing, no async handling	Respond 200 OK immediately, process asynchronously
Duplicate submissions	No idempotency check	Use `umid` to track processed submissions
Low completion rate	Poor mobile UX, too many required fields	Test on real devices, make more fields optional

Monitoring and Analytics

Track these metrics to optimize your Flows:

Completion Metrics:

Start rate - % of users who click the Flow button
Completion rate - % of users who submit the Flow
Abandonment by screen - Where users drop off
Average completion time - How long users take

Quality Metrics:

Invalid submissions - Data that fails validation
Webhook errors - Processing failures
Response time - How quickly webhooks process
User feedback - Complaints or confusion reports

Optimization Actions:

A/B test different Flow designs
Remove or simplify high-abandonment screens
Improve helper text for fields with high error rates
Add more constrained inputs (dropdown vs text)

Error Handling

Client-Side Validation

WhatsApp Flows provide built-in validation:

Required fields prevent submission if empty
Email/phone/number input types validate format
Date pickers constrain to valid dates
Min/max character limits prevent oversized input

Users see validation errors immediately without submitting.

Server-Side Validation

Always validate on your backend:

app.post('/webhook',async(req, res)=>{
const{ payload }= req.body;
// Acknowledge immediately
  res.status(200).send('OK');
try{
// Parse submission
const data =JSON.parse(payload.content.interactive.nfmReply.responseJson);
// Validate
if(!data.email||!isValidEmail(data.email)){
awaitlogInvalidSubmission(payload.umid,'invalid_email', data);
awaitsendMessage(payload.user.msisdn,
"We couldn't process your submission. Please check your email and try again.");
return;
}
// Process valid submission
awaitprocessFlowSubmission(data, payload);
}catch(error){
console.error('Flow processing error:', error);
awaitlogError(payload.umid, error);
awaitsendMessage(payload.user.msisdn,
"We encountered an error. Our team has been notified and will follow up shortly.");
}
});

Graceful Degradation

When errors occur:

Log the error with full context (umid, payload, user)
Notify the user with a helpful message
Alert your team for high-priority issues
Provide alternatives (phone number, email for support)

Example:

awaitsendMessage(payload.user.msisdn,
"We're having trouble processing your request right now. "+
"Please try again in a few minutes, or contact us at support@example.com.");

Accessibility

Text Clarity

Use simple, clear language
Avoid jargon and technical terms
Keep sentences short (< 20 words)
Use active voice ("Enter your email" vs "Email should be entered")

Visual Design

Ensure sufficient contrast for text
Use descriptive alt-text for images
Don't rely solely on color to convey meaning
Test with screen readers if possible

Progressive Enhancement

Design for users with limited literacy
Use visual cues (icons, images) alongside text
Provide examples in helper-text
Use radio buttons with clear labels for complex choices

Performance Optimization

Image Optimization

Compress images before base64 encoding
Use appropriate formats (WebP for photos, PNG for logos)
Limit image sizes (< 500KB recommended)
Consider mobile data - Large images slow Flow loading

Flow JSON Size

Keep Flow JSON concise (< 100KB recommended)
Minimize base64-encoded images in JSON when possible
Use URLs for large images instead of embedding
Remove unnecessary whitespace in production JSON

Webhook Performance

Respond within 5 seconds - Acknowledge receipt immediately
Process asynchronously - Queue long-running tasks
Implement caching - Cache frequently accessed data
Use connection pooling - Reuse database connections
Monitor response times - Alert on slow webhooks

Documentation

Internal Documentation

Document each Flow for your team:

Purpose - What problem does this Flow solve?
Target audience - Who will use this Flow?
Data collected - What fields and why?
Processing logic - What happens to submissions?
Dependencies - What systems does this integrate with?
Owner - Who maintains this Flow?

User-Facing Documentation

Help users understand your Flows:

What to expect - How long will it take?
What you need - What information should users have ready?
Privacy - How will their data be used?
Support - Who to contact with questions?

Troubleshooting Guide

Flow Won't Publish

Symptoms: Error when clicking Publish button

Common Causes:

Invalid JSON structure
Missing required fields
Screen IDs don't match routing model
Invalid component properties

Solution:

Validate JSON syntax (use online validator)
Check all screen IDs exist in routing_model
Verify all required component properties are set
Test in preview before publishing

Users Can't Open Flow

Symptoms: Flow button appears but nothing happens when clicked

Common Causes:

Flow not published
Flow deprecated
Incorrect Flow ID in template
User's WhatsApp version too old

Solution:

Verify Flow status is PUBLISHED
Check Flow ID matches template
Test on updated WhatsApp version
Recreate and republish Flow if needed

Webhook Not Receiving Submissions

Symptoms: Flow completes but webhook never fires

Common Causes:

Webhook URL incorrect
Webhook endpoint not HTTPS
Endpoint not returning 200 OK
Firewall blocking requests

Solution:

Verify webhook URL in portal settings
Ensure endpoint uses HTTPS
Test endpoint responds with 200 OK
Check server logs for incoming requests
Verify firewall/security group allows WhatsApp IPs

Parsing Errors

Symptoms: responseJson won't parse or missing fields

Common Causes:

Not parsing JSON string (it's double-encoded)
Field names don't match Flow definition
Optional fields missing from payload
Unicode/encoding issues

Solution:

try{
// responseJson is a STRING, must parse it
const data =JSON.parse(payload.content.interactive.nfmReply.responseJson);
// Check for required fields
if(!data.email){
console.error('Missing email field');
return;
}
// Handle optional fields safely
const preferences = data.preferences||[];
}catch(error){
console.error('JSON parsing error:', error);
console.log('Raw payload:', payload.content.interactive.nfmReply.responseJson);
}

Next Steps

Additional Resources

WhatsApp Webhooks - Webhook configuration and event types
Template Message API - Template syntax and approval
Meta WhatsApp Flows Documentation - Official WhatsApp guidelines
GDPR Compliance Guide - EU data protection regulations
CCPA Compliance Guide - California privacy regulations

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-best-practices · 8x8 CPaaS Developer Docs. Synced for support deflection.

WhatsApp Flows over 8x8 API

This API reference provides complete technical documentation for developers implementing WhatsApp Flows programmatically.

Overview

The WhatsApp Flows API enables you to create, manage, publish, and send interactive forms within WhatsApp conversations. Use the API when you need:

Automated deployments from CI/CD pipelines
Programmatic flow management across multiple channels
Version control integration for Flow definitions
Custom tooling and workflow automation
Bulk operations at scale

For non-developers: If you prefer a visual, no-code interface, see the WhatsApp Flows in 8x8 Connect.

Prerequisites

Before using the API, ensure you have:

Active WhatsApp Channel in 8x8 Connect
Channel ID - Find in 8x8 Connect Portal under Channels
API Key - Generate in 8x8 Connect Portal under API Keys
Subaccount ID - Required for sending messages
Webhook endpoint - Configured to receive Flow submissions

Authentication

All API requests require Bearer token authentication using your API Key.

Header:

Authorization: Bearer YOUR_API_KEY

Example:

curl -X GET "https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows" \
  -H "Authorization: Bearer YOUR_API_KEY"

Flow Management APIs

Base URL: https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows

API Endpoints Overview

Action	Method	Endpoint	Description
List Flows	GET	`/flows`	Retrieves all Flows for a specified channel
Create Flow	POST	`/flows`	Creates a new Flow in `DRAFT` status
Get Flow	GET	`/flows/{flowId}`	Retrieves Flow details and configuration
Update Flow	PUT	`/flows/{flowId}`	Updates a Flow (DRAFT only)
Delete Flow	DELETE	`/flows/{flowId}`	Deletes a Flow (DRAFT only)
Publish Flow	POST	`/flows/{flowId}/publish`	Publishes Flow for use in messages
Deprecate Flow	POST	`/flows/{flowId}/deprecate`	Marks Flow as deprecated
Preview Flow	GET	`/flows/{flowId}/preview`	Generates preview URL for testing

Create Flow

Upload a new Flow definition to your WhatsApp channel.

Endpoint: POST /config/v1/channels/whatsapp/{channelId}/flows

Request Body:

{
"name":"Appointment Booking Flow",
"categories":["APPOINTMENT_BOOKING"],
"flowJson":"{\"version\":\"7.3\",\"screens\":[{\"id\":\"WELCOME\",\"title\":\"Book Appointment\",\"terminal\":true,\"success\":true,\"layout\":{\"type\":\"SingleColumnLayout\",\"children\":[{\"type\":\"TextHeading\",\"text\":\"Schedule Your Visit\"},{\"type\":\"DatePicker\",\"name\":\"appointment_date\",\"label\":\"Preferred Date\",\"required\":true},{\"type\":\"Footer\",\"label\":\"Confirm\",\"on-click-action\":{\"name\":\"complete\",\"payload\":{\"date\":\"${form.appointment_date}\"}}}]}}]}"
}

Parameters:

name (string, required): Human-readable Flow name for your reference
categories (array, required): Flow categories. Options:
- ["OTHER"] - General purpose
- ["LEAD_GENERATION"] - Lead capture
- ["CONTACT_US"] - Contact forms
- ["CUSTOMER_SUPPORT"] - Support requests
- ["SIGN_UP"] - Registration
- ["APPOINTMENT_BOOKING"] - Appointments
- ["SURVEY"] - Feedback collection
flowJson (string, required): Stringified JSON of your Flow definition

Important: The flowJson field must be a JSON string, not a JSON object. Use JSON.stringify() to properly escape your Flow definition.

Response (201 Created):

{
"id":"1234567890123456",
"name":"Appointment Booking Flow",
"status":"DRAFT",
"categories":["APPOINTMENT_BOOKING"],
"validation_errors":[]
}

Flow Status Values:

DRAFT - Editable, not usable in messages
PUBLISHED - Live, immutable, usable in messages
DEPRECATED - Published but no longer recommended

Example with curl:

curl -X POST "https://chatapps.8x8.com/config/v1/channels/whatsapp/YOUR_CHANNEL_ID/flows" \
  -H "Authorization: Bearer YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "Appointment Booking Flow",
    "categories": ["APPOINTMENT_BOOKING"],
    "flowJson": "{\"version\":\"7.3\",\"screens\":[...]}"
  }'

Update Flow

Modify an existing Flow definition. Only works for Flows in DRAFT status.

Endpoint: PUT /config/v1/channels/whatsapp/{channelId}/flows/{flowId}

Request Body: Same structure as Create Flow

Response (200 OK): Same as Create Flow response

Note Published Flows cannot be updated. To modify a published Flow:

Create a new Flow with the updated definition

Publish the new Flow

Optionally deprecate the old Flow

Update templates to use the new Flow ID

Get Flow

Retrieve details and JSON definition of a specific Flow.

Endpoint: GET /config/v1/channels/whatsapp/{channelId}/flows/{flowId}

Response (200 OK):

{
"id":"1234567890123456",
"name":"Appointment Booking Flow",
"status":"PUBLISHED",
"categories":["APPOINTMENT_BOOKING"],
"validation_errors":[],
"flowJson":"{\"version\":\"7.3\",\"screens\":[...]}"
}

Use Cases:

Verify Flow status before sending
Export Flow JSON for version control
Audit existing Flows

Delete Flow

Permanently delete a Flow. Only works for Flows in DRAFT status.

Endpoint: DELETE /config/v1/channels/whatsapp/{channelId}/flows/{flowId}

Response (204 No Content)

Important:

Cannot delete published Flows
Cannot delete Flows currently in use by templates
Deletion is permanent and cannot be undone

Publish Flow

Publish a Flow to make it available for use in messages. This action is irreversible.

Endpoint: POST /config/v1/channels/whatsapp/{channelId}/flows/{flowId}/publish

Response (200 OK):

{
"id":"1234567890123456",
"name":"Appointment Booking Flow",
"status":"PUBLISHED"
}

After Publishing:

Flow becomes immutable - no edits allowed
Flow can be used in templates and interactive messages
Flow status changes from DRAFT to PUBLISHED

Deprecate Flow

Mark a Flow as deprecated. It remains functional but is flagged as no longer recommended.

Endpoint: POST /config/v1/channels/whatsapp/{channelId}/flows/{flowId}/deprecate

Response (200 OK):

{
"id":"1234567890123456",
"name":"Appointment Booking Flow",
"status":"DEPRECATED"
}

Use Cases:

Phasing out old Flow versions
Migrating users to improved Flows
Maintaining backward compatibility while promoting new versions

Preview Flow

Generate a preview URL to test the Flow before publishing.

Endpoint: GET /config/v1/channels/whatsapp/{channelId}/flows/{flowId}/preview?refresh=false

Query Parameters:

refresh (boolean):
- false - Use cached preview (faster)
- true - Generate new preview with latest changes

Response (200 OK):

{
"preview_url":"https://business.facebook.com/wa/manage/flows/1234567890123456/preview/",
"expires_at":"2026-02-05T18:00:00Z"
}

Preview URL:

Opens WhatsApp Business Manager
Shows interactive Flow preview
Expires after set period (usually 48 hours)
Use refresh=true to generate new URL after expiry

Sending Flow Messages

Flows can be sent via two methods:

Template messages - Business-initiated (proactive outreach)
Interactive messages - User-initiated (within 24-hour window)

Via Template Message (Business-Initiated)

Template messages with Flow buttons allow you to initiate conversations or re-open closed service windows.

Use Cases:

Proactive appointment reminders
Feedback request campaigns
Re-engagement after window closes
Marketing with data collection

Step 1: Create Template with Flow Button

Template Structure:

Templates must be created and approved by WhatsApp before use. See Template Message API Library for complete documentation.

Flow Button in Template:

{
"language":"en_US",
"name":"appointment_reminder",
"category":"UTILITY",
"components":[
{
"type":"BODY",
"text":"Hi {{1}}, your appointment is coming up. Need to reschedule?"
},
{
"type":"BUTTONS",
"buttons":[
{
"type":"FLOW",
"text":"Reschedule",
"flowId":"1234567890123456"
}
]
}
]
}

Step 2: Send Template Message

Endpoint: POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages

Request:

{
"user":{
"msisdn":"+15551234567"
},
"type":"template",
"content":{
"template":{
"language":"en_US",
"name":"appointment_reminder",
"components":[
{
"type":"body",
"parameters":[
{
"type":"text",
"text":"John"
}
]
},
{
"type":"button",
"subType":"flow",
"index":0,
"parameters":[
{
"type":"action"
}
]
}
]
}
}
}

Key Points:

flowId is configured in the template, not in the send request
Flow button uses subType: "flow" in the button component
User taps button to open the Flow

Via Interactive Message (User-Initiated)

Interactive Flow messages are used within the 24-hour customer service window after a user sends you a message.

Use Cases:

Response to customer inquiry
Agent-initiated data collection during support chat
Follow-up after template interaction

Endpoint: POST https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages

Interactive Flow Structure:

{
"user":{
"msisdn":"+15551234567"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"flow",
"header":{
"type":"text",
"text":"Schedule Your Appointment"
},
"body":{
"text":"Please select your preferred date and time for your visit."
},
"footer":{
"text":"Available Mon-Fri 9AM-5PM"
},
"action":{
"parameters":{
"flowId":"1234567890123456",
"flowCta":"Book Now"
}
}
}
}
}

Parameters:

flowId (required): The published Flow ID
flowCta (required): Button text (max 20 characters)
flowToken (optional): Custom token passed to webhook
mode (optional): "draft" for testing unpublished flows
flowMessageVersion (optional): "3" for latest features

flowActionData (optional): Pre-populate Flow data

"flowActionData":{
"screen":"SCREEN_ID",
"data":{
"field_name":"pre-filled value"
}
}

Service Window Requirement:

Can only send within 24 hours after user's last message
Outside window, use Template message instead
See WhatsApp Conversation Windows

Complete Example:

curl -X POST "https://chatapps.8x8.com/api/v1/subaccounts/YOUR_SUBACCOUNT_ID/messages" \
  -H "Authorization: Bearer YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "user": {
      "msisdn": "+15551234567"
    },
    "type": "Interactive",
    "content": {
      "interactive": {
        "type": "flow",
        "body": {
          "text": "Complete our quick survey to help us improve."
        },
        "action": {
          "parameters": {
            "flowId": "1234567890123456",
            "flowCta": "Start Survey"
          }
        }
      }
    }
  }'

Webhook Integration

When users complete a Flow, submissions are delivered to your webhook as inbound messages.

Webhook Configuration

Setup in 8x8 Connect Portal:

Navigate to Messaging Apps > Webhooks
Add your endpoint URL (must be HTTPS)
Select event type: inbound_message_received
Save configuration

Complete webhook setup guide: WhatsApp Webhooks Documentation

Flow Submission Payload

Flow submissions arrive as inbound_message_received events with type nfmReply.

Identifying Flow Submissions:

if(payload.type==="Interactive"&&
    payload.content.interactive.type==="nfmReply"){
// This is a Flow submission
}

Complete Payload Structure:

{
"namespace":"ChatApps",
"eventType":"inbound_message_received",
"payload":{
"umid":"unique-message-id-abc123",
"subAccountId":"your-subaccount-id",
"timestamp":"2026-02-03T10:30:00.000Z",
"user":{
"msisdn":"+15551234567",
"channelUserId":"15551234567"
},
"recipient":{
"channel":"whatsapp",
"channelId":"your-channel-id"
},
"type":"Interactive",
"content":{
"interactive":{
"type":"nfmReply",
"nfmReply":{
"responseJson":"{\"appointment_date\":\"2026-03-15\",\"service_type\":\"plumbing\",\"flow_token\":\"<TOKEN>\"}"
}
}
}
}
}

Parsing Submission Data

The responseJson field contains a JSON string (not a parsed object). You must parse it to access form data.

Step 1: Extract the JSON String

const responseJsonString = payload.content.interactive.nfmReply.responseJson;

Step 2: Parse to Object

const submissionData =JSON.parse(responseJsonString);

Step 3: Validate and Process

// Validate required fields
if(!submissionData.appointment_date||!submissionData.service_type){
console.error('Missing required fields');
return res.status(200).send('OK');// Always return 200 to acknowledge receipt
}
// Process the data
awaitcreateAppointment({
customerPhone: payload.user.msisdn,
appointmentDate: submissionData.appointment_date,
serviceType: submissionData.service_type,
flowToken: submissionData.flow_token,
umid: payload.umid// For idempotency tracking
});
// Send confirmation message
awaitsendMessage({
user:{msisdn: payload.user.msisdn},
type:'text',
content:{
text:`Appointment confirmed for ${submissionData.appointment_date}. We'll send a reminder 24 hours before your visit.`
}
});
// Return 200 OK within 5 seconds
res.status(200).send('OK');

Webhook Response Requirements

Your webhook endpoint must:

Respond with 200 OK within 5 seconds
Process asynchronously if operations take longer
Handle duplicates using umid for idempotency
Validate input before processing
Log errors without throwing exceptions

Example Webhook Handler:

const express =require('express');
const app =express();
app.post('/webhook', express.json(),async(req, res)=>{
const{ payload }= req.body;
// Acknowledge receipt immediately
  res.status(200).send('OK');
// Process asynchronously
try{
if(payload.type==='Interactive'&&
        payload.content.interactive.type==='nfmReply'){
// Parse Flow submission
const data =JSON.parse(payload.content.interactive.nfmReply.responseJson);
// Check for duplicate using umid
if(awaitisProcessed(payload.umid)){
console.log('Duplicate submission, skipping');
return;
}
// Mark as processed
awaitmarkProcessed(payload.umid);
// Process submission
awaithandleFlowSubmission(data, payload);
}
}catch(error){
console.error('Error processing webhook:', error);
// Log error but don't throw - webhook already acknowledged
}
});
app.listen(3000);

Response Handling Best Practices

Validate input: Always validate submission data schema
Handle errors gracefully: Log parsing errors without crashing
Respond quickly: Acknowledge within 5 seconds
Store metadata: Save umid, subAccountId, flow_token for traceability
Implement idempotency: Check umid to prevent duplicate processing
Send confirmation: Reply to user confirming successful submission
Monitor performance: Track webhook response times and error rates

Error Handling

HTTP Error Codes

Code	Meaning	Common Causes
400 Bad Request	Invalid request format	Malformed JSON, missing required fields, invalid `flowJson` structure
401 Unauthorized	Authentication failed	Invalid or expired API key
404 Not Found	Resource doesn't exist	Invalid `channelId` or `flowId`
409 Conflict	Operation not allowed	Trying to update/delete published Flow
422 Unprocessable Entity	Validation failed	Invalid Flow JSON schema, unsupported components
429 Too Many Requests	Rate limit exceeded	Slow down request rate
500 Internal Server Error	Server error	Temporary issue, retry with exponential backoff

Common API Issues

Error Message	Cause	Solution
`Flow not found`	Invalid or deleted Flow ID	Verify Flow exists with GET /flows/{flowId}
`Flow must be in DRAFT status`	Attempting to modify published Flow	Create new Flow version instead
`Invalid flowJson`	JSON structure doesn't match schema	Validate against WhatsApp Flows schema
`flowJson must be a string`	Passed JSON object instead of string	Use `JSON.stringify()` to escape
`Flow is not published`	Trying to send unpublished Flow	Publish Flow first with POST /publish
`Outside service window`	Interactive message sent >24hrs	Use Template message instead

Debugging API Errors

1. Validate Flow JSON Structure

Before uploading, validate your Flow definition:

// Validate structure
const flowDef ={
version:"7.3",
screens:[
{
id:"SCREEN1",
title:"Welcome",
terminal:true,
success:true,
layout:{/* ... */}
}
]
};
// Test parsing
try{
const flowJson =JSON.stringify(flowDef);
JSON.parse(flowJson);// Should succeed
console.log('Flow JSON is valid');
}catch(error){
console.error('Invalid JSON:', error);
}

2. Check Flow Status

Verify Flow is in correct state:

curl -X GET "https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows/{flowId}" \
  -H "Authorization: Bearer YOUR_API_KEY"

Expected status progression: DRAFT → PUBLISHED

3. Test with Preview URL

Use preview endpoint to test before publishing:

curl -X GET "https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows/{flowId}/preview?refresh=true" \
  -H "Authorization: Bearer YOUR_API_KEY"

4. Log Complete Request/Response

When debugging, log full API interactions:

const axios =require('axios');
try{
const response =await axios.post(
`https://chatapps.8x8.com/config/v1/channels/whatsapp/${channelId}/flows`,
{
name:'Test Flow',
categories:['OTHER'],
flowJson: flowJsonString
},
{
headers:{
'Authorization':`Bearer ${apiKey}`,
'Content-Type':'application/json'
}
}
);
console.log('Success:', response.data);
}catch(error){
console.error('Error:',{
status: error.response?.status,
statusText: error.response?.statusText,
data: error.response?.data,
request: error.config
});
}

Rate Limits

Flow Configuration API:

100 requests per minute per API key
Applies to all Flow management endpoints (create, update, delete, publish)

Messaging API:

1000 messages per second per WhatsApp Business Account
Applies to both template and interactive messages

Best Practices:

Implement exponential backoff on 429 errors
Batch operations where possible
Cache Flow IDs to avoid repeated GET requests
Use webhooks instead of polling for submission status

Testing

Testing Checklist

Complete end-to-end API testing:

Create Flow: POST /flows returns 201 with Flow ID
Verify Status: GET /flows/{flowId} shows DRAFT status
Generate Preview: GET /preview returns valid URL
Test Flow: Open preview URL and complete Flow
Publish Flow: POST /publish changes status to PUBLISHED
Send Message: Interactive or Template message delivers successfully
Webhook Received: Webhook endpoint receives nfmReply payload
Parse Data: All submitted fields parse correctly from responseJson
Send Confirmation: Confirmation message sent back to user

Testing Tools

Postman Collection:

Import 8x8 Connect API collection
Set environment variables (channelId, API key)
Test all Flow endpoints

cURL Examples:

# Create Flow
curl -X POST "https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows" \
  -H "Authorization: Bearer $API_KEY" \
  -H "Content-Type: application/json" \
  -d @flow-definition.json
# Publish Flow
curl -X POST "https://chatapps.8x8.com/config/v1/channels/whatsapp/{channelId}/flows/{flowId}/publish" \
  -H "Authorization: Bearer $API_KEY"
# Send Interactive Message
curl -X POST "https://chatapps.8x8.com/api/v1/subaccounts/{subAccountId}/messages" \
  -H "Authorization: Bearer $API_KEY" \
  -H "Content-Type: application/json" \
  -d @interactive-message.json

Webhook Testing:

Use tools like ngrok to expose local endpoint
Use RequestBin to inspect webhook payloads
Monitor webhook logs for nfmReply events

Code Examples

Complete end-to-end examples are available in the WhatsApp Flows Examples documentation, including:

Product Return & Exchange Flow
Loan Application with KYC
Service Appointment Booking
Healthcare Appointment Scheduling
CPaaS Lead Generation

Each example includes:

Complete Flow JSON definition
API requests for creating and publishing
Template creation
Webhook handling code
Best practices

Related Resources

WhatsApp Flows in 8x8 Connect - No-code Flow creation interface
WhatsApp Flows Examples - Industry-specific Flow templates
WhatsApp Webhooks - Webhook setup and event types
Template Message API - Complete template syntax
Interactive Message API - Interactive message reference
WhatsApp Official Docs - Meta's Flow documentation

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-api · 8x8 CPaaS Developer Docs. Synced for support deflection.

WhatsApp Flow Examples
WhatsApp Flow Examples

This library provides production-ready WhatsApp Flow implementations for common industry use cases. Each example includes the complete Flow JSON definition, API implementation steps, webhook handling guidance, and industry-specific best practices.

These examples demonstrate real-world patterns you can adapt to your specific business needs. All payloads are tested and match the 8x8 Connect API specifications.

Available Examples by Industry

Retail & eCommerce

Product Return & Exchange - Automate returns processing, reduce support tickets by 40%, and capture structured data for quality insights.

Financial Services

Loan Application - Streamline loan applications with KYC document upload, employment verification, and automated eligibility checks.

Professional Services

Service Appointment Booking - Collect service requests, property details, and schedule technician appointments with skill-based routing.

Healthcare

Appointment Scheduling - Reduce phone volume and scheduling errors with structured appointment data collection.

Sales & Marketing

CPaaS Lead Generation - Capture qualified leads with product showcases, multi-select interests, and demo scheduling.

How to Use These Examples

Each example provides complete Flow JSON and implementation guidance. You can use them in two ways:

Option 1: 8x8 Connect UI (Recommended for Getting Started)

Use the visual interface to create and deploy Flows without code:

Copy the Flow JSON from Step 1 of any example

Navigate to 8x8 Connect > Messaging Apps > WhatsApp flows at https://connect.8x8.com/chat/flows

Click + Create a WhatsApp Flow or go directly to https://connect.8x8.com/chat/flows/create

Paste the JSON into the editor

Use the preview to test the Flow interactively

Click Publish when ready

Create a template with Flow button (or use Interactive messages within service window)

Send via Campaigns for bulk sends, or directly to individual customers

Full walkthrough: WhatsApp Flows in 8x8 Connect

Option 2: API Integration (For Developers)

Use programmatic API calls for automation and CI/CD:

Use the complete API calls shown in each step of the examples

Authenticate with your API key (Bearer token)

Create Flow via POST request (Step 1 in each example)

Publish via POST request (Step 2 in each example)

Send Flow via Template or Interactive message (Step 3)

Handle webhook submissions in your backend (Step 4)

Full API reference: WhatsApp Flows API Documentation

Example Structure

Each example follows this consistent format:

Scenario Overview: Business problem and solution approach

Flow JSON: Complete Flow definition with screens and validation

Template Creation: API payload for creating the template (if using business-initiated approach)

Sending the Flow: Complete request payloads for template or interactive messages

Webhook Handling: Expected submission payload and processing guidance

Tips:

Adapt field names and labels to match your business requirements

Test Flows in preview mode before publishing to production

Start with a similar example and customize from there

Note: Meta's WhatsApp Flows Playground is a one-way tool for building flows visually and exporting to JSON. It does not support importing/pasting JSON.

Best Practices Across All Examples

Flow Design

Keep it focused: Limit Flows to 3-5 screens maximum for better completion rates

Mobile-first: Design for small screens, keep text concise

Progressive disclosure: Ask for basic info first, complex details later

Clear CTAs: Use action-oriented button labels ("Book Now" vs "Submit")

Error Handling

Validate early: Check order numbers, emails, phone formats before submission

Graceful failures: If validation fails, explain clearly and offer alternatives

Idempotency: Use umid to prevent duplicate processing

Timeout handling: Webhook must respond within 5 seconds

Retry logic: Implement exponential backoff for downstream API calls

Implementation Tips

Keep it Short: Limit to 3-5 screens maximum

Show Progress: Use screen titles like "Step 1 of 3"

Pre-populate When Possible: Pass known data via flowActionData

Validate Appropriately: Use required: true and appropriate input-type

// Wrap parsing in try-catch try{ const data =JSON.parse(payload.content.interactive.nfmReply.responseJson); awaitprocessSubmission(data); }catch(error){ console.error('Flow submission parsing error:', error); // Log for debugging but don't crash }

Testing

Test all Flows with preview URL before publishing

Send to test numbers and complete full journey

Verify webhook receives correct payload structure

Test error scenarios (missing fields, invalid data)

Track Flow completion rates

A/B test different Flow designs

Monitoring

Track completion rates: Identify where users abandon Flows

Response times: Monitor webhook processing duration

Error rates: Alert on parsing failures

A/B testing: Test different Flow designs and button labels to optimize conversion

Additional Resources

WhatsApp Flows in 8x8 Connect - Complete guide for creating Flows using 8x8 Connect portal

WhatsApp Flows API Reference - API documentation for programmatic Flow management

Meta WhatsApp Flows Playground - Visual Flow design tool

WhatsApp Webhooks - Webhook setup and all event types

Template Message API - Complete template syntax reference
Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-examples · 8x8 CPaaS Developer Docs. Synced for support deflection.

WhatsApp Flows

WhatsApp Flows enable you to collect structured input from customers using guided UI forms within the WhatsApp conversation. Instead of exchanging multiple back-and-forth text messages, Flows present users with an interactive, multi-step form that guides them through data entry with built-in validation and a polished user experience.

Overview

What are WhatsApp Flows?

WhatsApp Flows are interactive, form-based experiences that run directly inside WhatsApp. They allow you to:

Collect structured data through form fields (text input, dropdowns, radio buttons, checkboxes, date pickers)
Validate input in real-time before submission reaches your backend
Guide users through multi-screen journeys with branching logic and conditional navigation
Reduce conversation friction by replacing 10+ message exchanges with a single, intuitive form

When to Use Flows

Flows are ideal when you need to:

Capture consistent, structured information for downstream automation (CRM, booking systems, ticketing)
Reduce data entry errors with built-in validation and constrained inputs
Improve user experience by providing a guided, mobile-optimized form interface
Automate multi-step processes like appointment booking, lead qualification, or feedback collection

Flows vs. Automation Builder

Both tools help create interactive experiences, but serve different purposes:

Feature	WhatsApp Flows	8x8 Automation Builder
Best for	Structured form data collection	Conversational workflows and branching logic
User Experience	Native WhatsApp form UI	Text messages with buttons/lists
Data Collection	Single submission with all fields	Multiple message exchanges
Validation	Built-in field validation	Custom logic via branches
Integration	Both UI and API	Portal-based (visual workflow builder)
Use Case Example	Appointment booking form with date/time/service fields	Restaurant reservation bot with menu selection and confirmation

Recommendation: Use Flows for data capture and Automation Builder for conversational workflows. You can combine both: use Automation Builder to trigger a Flow, then process the submission.

Common Use Cases

Industry	Use Case	What Flows Collect	Next Action
Retail & eCommerce	Product finder / preferences	Size, style, budget, category	Product recommendations
Healthcare	Appointment scheduling	Location, specialty, preferred date/time	Create booking
Financial Services	Account onboarding	Identity fields, consent	Trigger KYC workflow
Logistics	Delivery rescheduling	New time window, address details	Update delivery system
Customer Support	Feedback collection	NPS score, satisfaction ratings, comments	Store in CRM
Real Estate	Property inquiry	Location, budget, bedrooms, move-in date	Agent assignment
Travel	Booking request	Destination, dates, travelers, preferences	Check availability

Choosing Your Approach

8x8 provides two ways to work with WhatsApp Flows:

8x8 Connect UI (Recommended for Getting Started)

Visual, no-code interface for creating and managing Flows through the 8x8 Connect portal.

Benefits:

No coding required
Live preview while building
Direct integration with Templates and Campaigns
Export Flow JSON for version control

Best for:

Business users and marketers
Quick prototyping and testing
Teams without developer resources
One-off campaigns and promotions

→ Get Started with UI Guide

API Integration (Advanced)

Programmatic control for automation and CI/CD workflows.

Benefits:

Scriptable deployments
Version control friendly
Automated testing
Integration with existing DevOps pipelines

Best for:

Development teams
Large-scale deployments
Automated Flow management
Complex integration requirements

→ See API Reference

Before You Begin

To implement WhatsApp Flows, you need:

Active WhatsApp Channel in 8x8 Connect
Webhook endpoint configured to receive Flow submissions (see WhatsApp Webhooks)
For UI Approach: Access to 8x8 Connect portal
For API Approach: Channel ID, Subaccount ID, and API Key

Note Flow submission data is delivered via webhooks as inbound messages. See WhatsApp Webhooks for webhook configuration.

How Flows Work

Flow Lifecycle

A typical Flow implementation follows this sequence:

1. Design       → Build Flow JSON definition (screens, fields, validation)
2. Create       → Upload Flow via 8x8 Connect UI or API
3. Preview      → Validate rendering and user experience
4. Publish      → Make Flow available for use in messages
5. Send         → Trigger Flow via Template or Interactive message
6. Submit       → User completes Flow; submission sent to webhook
7. Process      → Your system handles submission and responds

Key Concepts

Screens: Individual pages within a Flow. Users navigate between screens using footer buttons.

Navigation Modes:

navigate: Opens the Flow to a specific screen, optionally passing data
data_exchange: (Advanced) Enables dynamic data fetching from your server during Flow interaction

Terminal Screens: The final screen of a Flow, marked with "terminal": true. When users complete this screen, their submission is sent to your webhook.

Flow JSON: The complete definition of your Flow's structure, validation rules, and navigation logic. Can be created visually or coded manually.

Integration with Conversation Windows

Flows work within WhatsApp's conversation window rules:

Business-Initiated (Template with Flow button): Use to start new conversations or re-open closed windows
User-Initiated (Interactive Flow message): Use within the 24-hour customer service window

See Concepts & Fundamentals for complete conversation window rules.

Documentation Structure

This documentation is organized into focused guides for different needs:

For Business Users & Marketers

Creating Flows with 8x8 Connect UI - Step-by-step guide for creating, testing, and deploying Flows using the visual interface
Flow Examples - Industry-specific, production-ready Flow implementations you can adapt

For Developers

Flow API Reference - Complete API documentation for programmatic Flow management
Flow Component Reference - Technical reference for all UI components and their properties

For Everyone

Best Practices & Governance - Design guidelines, security, testing, and troubleshooting

Quick Start Guides

Option 1: Build Your First Flow (UI)

Review Flow Examples to find a similar use case
Copy the Flow JSON from the example
Follow the UI Guide to create and publish
Send to test users via Templates or Interactive messages
Monitor submissions in the 8x8 Connect portal

Time: 15-30 minutes

Option 2: Integrate via API

Review API Reference for authentication and endpoints
Create Flow programmatically with POST request
Publish the Flow
Configure webhook to receive submissions
Send Flow via Template or Interactive message API

Time: 1-2 hours (including webhook setup)

Next Steps

Choose your path based on your role and needs:

For Business Users: → Creating Flows with 8x8 Connect UI

For Developers: → Flow API Reference

For Everyone: → Flow Examples - See production-ready examples

Need Help with Components? → Flow Component Reference

Want Best Practices? → Best Practices & Governance

Additional Resources

WhatsApp Webhooks - Configure webhooks to receive Flow submissions
Template Message API - Send Flows via business-initiated messages
Interactive Message API - Send Flows within service window
Meta WhatsApp Flows Official Documentation - WhatsApp's official Flow documentation
8x8 Automation Builder - Combine Flows with conversational workflows

Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows · 8x8 CPaaS Developer Docs. Synced for support deflection.

WhatsApp Flow Component Reference
WhatsApp Flow Component Reference

Complete technical reference for all UI components available in WhatsApp Flows. Use this guide when building Flow JSON definitions to understand component properties, validation rules, and usage patterns.

Overview

WhatsApp Flows support a rich set of UI components for data collection and user interaction. Each component is defined in JSON format within your Flow definition.

Component Categories:

Layout Components - Container structures

Text Components - Headings, body text, captions

Input Components - Form fields for data entry

Navigation Components - Buttons and actions

Advanced Components - Conditional logic, carousels, rich text

Usage:

All components are defined within a screen's layout property

Most components go inside a Form wrapper

Use the exact type values shown below

All field name values must be unique within a screen

Layout Components

SingleColumnLayout

Container for vertically stacked components. This is the primary layout type for Flow screens.

Properties:

type (required): "SingleColumnLayout"

children (required): Array of component objects

Example:

{ "type":"SingleColumnLayout", "children":[ { "type":"TextHeading", "text":"Welcome" }, { "type":"TextBody", "text":"Please complete the form below." } ] }

Text Components

TextHeading

Large, bold text for screen titles and section headers.

Properties:

type (required): "TextHeading"

text (required): String content

Example:

{ "type":"TextHeading", "text":"Contact Information" }

TextBody

Regular text for descriptions and instructions.

Properties:

type (required): "TextBody"

text (required): String content

Example:

{ "type":"TextBody", "text":"Please provide your contact details so we can reach you." }

TextCaption

Small text for hints, footnotes, or disclaimers.

Properties:

type (required): "TextCaption"

text (required): String content

Example:

{ "type":"TextCaption", "text":"Your information is kept confidential." }

Input Components

TextInput

Single-line or multi-line text entry field.

Properties:

type (required): "TextInput"

name (required): Unique field identifier

label (required): Display label

input-type (required): One of: "text", "email", "number", "phone", "password", "passcode"

required (optional): Boolean, default false

helper-text (optional): Help text shown below field

min-chars (optional): Minimum character count

max-chars (optional): Maximum character count

Example:

{ "type":"TextInput", "name":"customer_name", "label":"Full Name", "input-type":"text", "required":true, "helper-text":"Enter your first and last name", "min-chars":2, "max-chars":100 }

Input Types:

text - General text input

email - Email with built-in validation

number - Numeric keyboard, validates numbers

phone - Phone number input

password - Masked text input

passcode - Numeric passcode input

TextArea

Multi-line text input for longer responses.

Properties:

type (required): "TextArea"

name (required): Unique field identifier

label (required): Display label

required (optional): Boolean, default false

helper-text (optional): Help text shown below field

max-length (optional): Maximum character count

Example:

{ "type":"TextArea", "name":"feedback", "label":"Your Feedback", "required":false, "helper-text":"Share your thoughts (optional)", "max-length":500 }

Dropdown

Select one option from a dropdown list.

Properties:

type (required): "Dropdown"

name (required): Unique field identifier

label (required): Display label

required (optional): Boolean, default false

data-source (required): Array of option objects with id and title

Example:

{ "type":"Dropdown", "name":"preferred_location", "label":"Preferred Location", "required":true, "data-source":[ {"id":"loc1","title":"Downtown Office"}, {"id":"loc2","title":"Westside Clinic"}, {"id":"loc3","title":"Northside Branch"} ] }

RadioButtonsGroup

Select one option from a vertical list of radio buttons.

Properties:

type (required): "RadioButtonsGroup"

name (required): Unique field identifier

label (required): Display label

required (optional): Boolean, default false

data-source (required): Array of option objects with id and title

Example:

{ "type":"RadioButtonsGroup", "name":"appointment_type", "label":"Appointment Type", "required":true, "data-source":[ {"id":"consultation","title":"Consultation"}, {"id":"followup","title":"Follow-up"}, {"id":"emergency","title":"Emergency"} ] }

When to use RadioButtons vs Dropdown:

Use RadioButtons for 2-5 options that users should see at a glance

Use Dropdown for 5+ options or when space is limited

CheckboxGroup

Select multiple options from a list.

Properties:

type (required): "CheckboxGroup"

name (required): Unique field identifier

label (required): Display label

required (optional): Boolean, default false

data-source (required): Array of option objects with id and title

Example:

{ "type":"CheckboxGroup", "name":"services", "label":"Services Needed", "required":false, "data-source":[ {"id":"cleaning","title":"Cleaning"}, {"id":"repair","title":"Repair"}, {"id":"maintenance","title":"Maintenance"} ] }

Note: The submitted value will be an array of selected IDs.

DatePicker

Select a date from a calendar interface.

Properties:

type (required): "DatePicker"

name (required): Unique field identifier

label (required): Display label

required (optional): Boolean, default false

helper-text (optional): Help text shown below field

min-date (optional): Minimum selectable date (ISO 8601 format)

max-date (optional): Maximum selectable date (ISO 8601 format)

Example:

{ "type":"DatePicker", "name":"appointment_date", "label":"Preferred Date", "required":true, "helper-text":"Select your preferred appointment date", "min-date":"2026-02-01", "max-date":"2026-12-31" }

Note: Submitted date format is YYYY-MM-DD.

OptIn

Checkbox for terms, consent, or agreements.

Properties:

type (required): "OptIn"

name (required): Unique field identifier

label (required): Display text for checkbox

required (optional): Boolean, default false

on-click-action (optional): Navigation action when clicked

Example:

{ "type":"OptIn", "name":"terms_accepted", "label":"I agree to the terms and conditions", "required":true, "on-click-action":{ "name":"navigate", "next":{ "type":"screen", "name":"TERMS_SCREEN" } } }

Use Cases:

Terms and conditions acceptance

Privacy policy consent

Marketing opt-ins

Legal disclaimers

PhotoPicker

Upload a photo from device camera or gallery.

Properties:

type (required): "PhotoPicker"

name (required): Unique field identifier

label (required): Display label

description (optional): Additional context text

required (optional): Boolean, default false

Example:

{ "type":"PhotoPicker", "name":"id_photo", "label":"Upload ID Photo", "description":"Take a photo of your ID document", "required":true }

Important:

Photo is base64-encoded in submission

Maximum file size varies by WhatsApp limits

Useful for KYC, verification, proof of purchase, damage reports

Navigation Components

Footer

Action button at the bottom of each screen for navigation or submission.

Properties:

type (required): "Footer"

label (required): Button text

on-click-action (required): Action object (see below)

Action Types:

1. Navigate to Another Screen:

{ "type":"Footer", "label":"Continue", "on-click-action":{ "name":"navigate", "next":{ "type":"screen", "name":"NEXT_SCREEN" }, "payload":{ "field_name":"${form.field_name}" } } }

2. Complete Flow (Terminal Screen):

{ "type":"Footer", "label":"Submit", "on-click-action":{ "name":"complete", "payload":{ "customer_name":"${form.customer_name}", "email":"${form.email}" } } }

Payload Syntax:

Use ${form.field_name} to reference current screen's form fields

Use ${data.field_name} to reference data passed from previous screens

Advanced Components

If (Conditional Logic)

Show components conditionally based on form values.

Properties:

type (required): "If"

condition (required): Expression to evaluate

then (required): Array of components to show if true

else (optional): Array of components to show if false

Example:

{ "type":"If", "condition":"${form.appointment_type} == 'emergency'", "then":[ { "type":"TextBody", "text":"For emergencies, please call our hotline: 1-800-URGENT" } ], "else":[ { "type":"TextBody", "text":"Standard appointments available within 48 hours." } ] }

Supported Operators:

== (equals)

!= (not equals)

>, <, >=, <= (comparison)

&& (and), || (or)


Display a static image using base64 encoding or URL.

Properties:

type (required): "Image"

src (required): Base64-encoded image data or URL

alt-text (optional): Alternative text for accessibility

scale-type (optional): "cover" or "contain"

Example (Base64):


Example (URL):

{ "type":"Image", "src":"https://example.com/banner.jpg", "alt-text":"Promotional Banner" }

ImageCarousel

Display multiple images in a horizontal scrollable carousel.

Properties:

type (required): "ImageCarousel"

images (required): Array of image objects with src and alt-text

Example:

{ "type":"ImageCarousel", "images":[ { "src":"https://example.com/image1.jpg", "alt-text":"Product Image 1" }, { "src":"https://example.com/image2.jpg", "alt-text":"Product Image 2" }, { "src":"https://example.com/image3.jpg", "alt-text":"Product Image 3" } ] }

Use Cases:

Product galleries

Before/after photos

Multi-angle views

Feature showcases

RichText

Formatted text with markdown support.

Properties:

type (required): "RichText"

text (required): Markdown-formatted text

Example:

{ "type":"RichText", "text":"**Bold text**, *italic text*, and [links](https://example.com)\n\n- Bullet point 1\n- Bullet point 2\n\n1. Numbered item\n2. Another item" }

Supported Markdown:

**bold** → bold

*italic* → italic

[link text](url) → clickable links

Bullet lists with - or *

Numbered lists with 1., 2., etc.

Line breaks with \n

EmbeddedLink

Inline link within text that navigates to another screen.

Properties:

type (required): "EmbeddedLink"

text (required): Link text

on-click-action (required): Navigation action

Example:

{ "type":"EmbeddedLink", "text":"Read our Terms of Service", "on-click-action":{ "name":"navigate", "next":{ "type":"screen", "name":"TERMS_SCREEN" } } }

Use Cases:

Link to terms/privacy screens

Show additional information screens

Navigate to help/FAQ screens

Form Wrapper

Most input components must be wrapped in a Form component.

Properties:

type (required): "Form"

name (required): Unique form identifier

children (required): Array of input components and Footer

Example:

{ "type":"Form", "name":"contact_form", "children":[ { "type":"TextInput", "name":"name", "label":"Your Name", "input-type":"text", "required":true }, { "type":"TextInput", "name":"email", "label":"Email Address", "input-type":"email", "required":true }, { "type":"Footer", "label":"Submit", "on-click-action":{ "name":"complete", "payload":{ "name":"${form.name}", "email":"${form.email}" } } } ] }

Data Passing Between Screens

Using Payload

When navigating between screens, pass data via the payload property:

{ "type":"Footer", "label":"Continue", "on-click-action":{ "name":"navigate", "next":{ "type":"screen", "name":"SCREEN_2" }, "payload":{ "first_name":"${form.first_name}", "last_name":"${form.last_name}" } } }

Accessing Data on Next Screen

Define data schema on receiving screen and reference with ${data.field_name}:

{ "id":"SCREEN_2", "title":"Confirm Details", "data":{ "first_name":{ "type":"string", "__example__":"John" }, "last_name":{ "type":"string", "__example__":"Doe" } }, "layout":{ "type":"SingleColumnLayout", "children":[ { "type":"TextBody", "text":"Hello ${data.first_name} ${data.last_name}!" } ] } }

Best Practices

Field Naming

Use descriptive, lowercase names with underscores: customer_email, preferred_date

Avoid special characters except underscores

Keep names consistent across similar Flows

Use meaningful names that indicate the data type

Validation

Set required: true for mandatory fields

Use appropriate input-type for built-in validation (email, number, phone)

Add helper-text to clarify expected format

Use min-chars and max-chars for text length validation

Use min-date and max-date for date restrictions

User Experience

Keep screens focused (5-7 fields maximum per screen)

Use clear, concise labels

Provide helpful helper-text for complex fields

Group related fields on the same screen

Use RadioButtons for 2-5 options, Dropdown for more

Show progress indicators in screen titles ("Step 1 of 3")

Mobile Optimization

Keep text concise (small screens)

Test all Flows in mobile preview

Ensure images are optimized for mobile data

Avoid very long dropdown lists

Use appropriate keyboard types via input-type

Complete Example

Here's a complete two-screen Flow demonstrating multiple components:

{ "version":"7.3", "screens":[ { "id":"CONTACT_INFO", "title":"Contact Information", "layout":{ "type":"SingleColumnLayout", "children":[ { "type":"TextHeading", "text":"Let's Get Started" }, { "type":"TextBody", "text":"Please provide your contact details." }, { "type":"Form", "name":"contact_form", "children":[ { "type":"TextInput", "name":"full_name", "label":"Full Name", "input-type":"text", "required":true, "helper-text":"First and last name" }, { "type":"TextInput", "name":"email", "label":"Email Address", "input-type":"email", "required":true }, { "type":"TextInput", "name":"phone", "label":"Phone Number", "input-type":"phone", "required":true }, { "type":"Footer", "label":"Continue", "on-click-action":{ "name":"navigate", "next":{ "type":"screen", "name":"PREFERENCES" }, "payload":{ "full_name":"${form.full_name}", "email":"${form.email}", "phone":"${form.phone}" } } } ] } ] } }, { "id":"PREFERENCES", "title":"Your Preferences", "terminal":true, "data":{ "full_name":{"type":"string","__example__":"John Doe"}, "email":{"type":"string","__example__":"john@example.com"}, "phone":{"type":"string","__example__":"+15551234567"} }, "layout":{ "type":"SingleColumnLayout", "children":[ { "type":"TextHeading", "text":"Almost Done, ${data.full_name}!" }, { "type":"Form", "name":"preferences_form", "children":[ { "type":"RadioButtonsGroup", "name":"contact_method", "label":"Preferred Contact Method", "required":true, "data-source":[ {"id":"email","title":"Email"}, {"id":"phone","title":"Phone"}, {"id":"whatsapp","title":"WhatsApp"} ] }, { "type":"CheckboxGroup", "name":"interests", "label":"Areas of Interest", "data-source":[ {"id":"products","title":"New Products"}, {"id":"promotions","title":"Promotions"}, {"id":"events","title":"Events"} ] }, { "type":"OptIn", "name":"newsletter", "label":"Subscribe to newsletter", "required":false }, { "type":"Footer", "label":"Submit", "on-click-action":{ "name":"complete", "payload":{ "full_name":"${data.full_name}", "email":"${data.email}", "phone":"${data.phone}", "contact_method":"${form.contact_method}", "interests":"${form.interests}", "newsletter":"${form.newsletter}" } } } ] } ] } } ] }

Next Steps

Flow Examples - See these components in action

Creating Flows with Connect UI - Build Flows using the visual editor

Flow API Reference - Create Flows programmatically

Best Practices - Design and validation guidelines
Source: https://developer.8x8.com/connect/docs/whatsapp/whatsapp-flows-components · 8x8 CPaaS Developer Docs. Synced for support deflection.

Update WhatsApp Flow

Request

Path Parameters

Body

Schema

validationErrors object[]

pointers object[]

Schema

Schema

Schema

Submit WhatsApp Direct Send Sample

Request

Path Parameters

Bodyrequired

text object

interactive object

header object

body objectrequired

footer object

action objectrequired

parameters object

buttons object[]

reply objectrequired

Schema

Schema

Schema

Schema

Schema

Remove WhatsApp template

Request

Path Parameters

Schema

Schema

Schema

Schema

Publish WhatsApp Flow

Request

Path Parameters

Schema

Schema

Schema

Preview WhatsApp Flow

Request

Path Parameters

Query Parameters

Schema

Schema

Schema

Schema

Get WhatsApp templates

Request

Path Parameters

Schema

templates object[]

components object[]

buttons object[]

example object

Schema

Schema

Get WhatsApp Flows

Request

Path Parameters

Query Parameters

Schema

flows object[]

Schema

Schema

Get WhatsApp Flow details

Request

Path Parameters

Schema

validationErrors object[]

pointers object[]

Schema

Schema

Schema

Retrieve message details

API Rate Limiting

Request

Path Parameters
